WESTFIELD - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

I72
WESTFIELD
PublicPUB

2 miles W of WESTFIELD, IN
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
40° 02' 56"N 86° 09' 28"W
932' MSL
1932' MSL
02W
None Listed
TERRE HAUTE (HUF)
CHICAGO
CHICAGO (ZAU)
5/16/24-6/13/24
KTYQ (4nm) IFR
2:55 AM EDT
Mist
Obscured
1.5sm
59°F
59°F
29.86"Hg
Calm
AO2 T01510149
KTYQ 180655Z AUTO 00000KT 1 1/2SM BR VV007 15/15 A2986 RMK AO2 T01510149
List Your Business

I72 FBOs, Flight Schools and Ground Support

No FBOs, flight schools or aircraft ground support businesses are listed for this airport.

I72 Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

I72 Hotels

No hotels are listed for this airport.

I72 Restaurants

No restaurants are listed for this airport.

I72 Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KIND (20nm)
Sat, 5/18 1:24 AM EDT
Sat, 5/18 2:00 AM EDT - Sun, 5/19 8:00 AM EDT
VFR
2:00 AM EDT - 5:00 AM EDT
Scattered 25,000'
6sm
160° 4kts
MVFR
5:00 AM EDT - 10:00 AM EDT
Mist
Scattered 400'
4sm
Calm
IFR
Temporary 6:00 AM EDT - 9:00 AM EDT
Mist
No Clouds
1sm
Calm
VFR
10:00 AM EDT - 2:00 PM EDT
Scattered 1,000'
6sm
160° 5kts
VFR
2:00 PM EDT - 8:00 PM EDT
Scattered 4,000'
6sm
170° 6kts
VFR
8:00 PM EDT - 8:00 AM EDT
Scattered 25,000'
6sm
160° 3kts
KIND 180524Z 1806/1912 16004KT P6SM SCT250
   FM180900 00000KT 4SM BR SCT004
   TEMPO 1810/1813 1SM BR
   FM181400 16005KT P6SM SCT010
   FM181800 17006KT P6SM SCT040
   FM190000 16003KT P6SM SCT250
I72
Domestic
5/17/240300Z !HUF 05/441 I72 OBST TOWER LGT (ASR 1016644) 400215.00N0860703.00W (2.0NM ESE I72) 1114.8FT (254.9FT AGL) U/S 2405170300-2408140400
No
IREG
WESTFIELD AIRPORT LLC
18206 KINSEY AVE.
WESTFIELD, IN 46074
Phone: 317-846-6060
ANDY WHEELER
18206 KINSEY AVE
WESTFIELD, IN 46074
Phone: 317-507-8281
TERRE HAUTE FSS (HUF)
Toll Free: 1-800-WX-BRIEF
HUF
--
ON REQ - AMGR.
N/A
Yes
No
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
7
0
0
0
0
10
None
None
None
None
None

Runway 18/36

3000 ft. x 100 ft.
TURF
Good
NONE
LOW

--
--
--
--
  Runway 18 Runway 36
True Heading 181°1°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 40° 03' 12"N 40° 02' 42"N
Longitude 86° 09' 37"W 86° 09' 38"W
Elevation 930' 930'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1SNOW REMOVAL NA.
A110-2CROPS 50 FT EACH SIDE OF RWY CNTRLN.
A110-3TREES, BUSHES & FENCE 100 FT W OF CNTRLN; PENETRATE PRIM SFC AREA.
A110-4FOR CD CTC INDIANAPOLIS APCH AT 317-227-5743.
WESTFIELD (IATA: I72) is a public airport located in WESTFIELD, IN.
