8/29/231237Z
|
!FDC 3/2768 AJG PART 1 OF 3 ODP MOUNT CARMEL MUNI,
MOUNT CARMEL, IL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKE-OFF MINIMUMS: RWY 31, 300-1 1/8 OR STANDARD WITH MINIMUM CLIMB
OF 225 FT/NM TO 700, OR ALTERNATIVELY, WITH STANDARD TAKEOFF
MINIMUMS AND NORMAL 200 FT/NM CLIMB GRADIENT, TAKEOFF MUST OCCUR NO
LATER THAN 1600 FT PRIOR TO DER.
CHANGE TAKEOFF OBSTACLE NOTES TO READ: NOTE: RWY 4, VEHICLES ON
ROAD BEGINNING 408 FT FROM DER, 247 FT LEFT OF CENTERLINE, UP TO
443 FT MSL. TREE 3717 FT FROM DER, 129 FT RIGHT OF CENTERLINE, 525
FT MSL. NOTE: RWY 13, VEHICLES ON ROAD BEGINNING 7 FT FROM DER, 189
FT RIGHT OF CENTERLINE, UP TO 443 FT MSL. UTILITY BUILDING 40 FT
FROM DER, 112 FT LEFT OF CENTERLINE, 3 FT AGL/431 FT MSL. VEHICLES
ON ROAD BEGINNING 347 FT FROM DER, 447 FT RIGHT OF CENTERLINE, UP
TO 445 FT MSL. TREE 2437 FT FROM DER, 838 FT RIGHT OF CENTERLINE,
491 FT MSL. TREES BEGINNING 2508 FT FROM DER, 1017 FT RIGHT OF
CENTERLINE, UP TO 519 FT MSL. TREES BEGINNING 2699 FT FROM DER,
1050 FT RIGHT OF CENTERLINE, UP TO 95 FT AGL/542 FT MSL. NOTE: RWY
22, TREES BEGINNING 80 FT FROM DER, 294 FT LEFT OF CENTERLINE, UP
TO 448 FT MSL. TREE 2611 FT FROM DER, 784 FT RIGHT OF CENTERLINE,
534 FT MSL. TREE 2633 FT FROM DER, 662 FT RIGHT OF CENTERLINE, 535
FT MSL. TREE 4335 FT FROM DER, 493 FT RIGHT OF CENTERLINE, 556 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2308291237-2508291237EST
END PART 1 OF 3
!FDC 3/2768 AJG PART 2 OF 3 ODP MOUNT CARMEL MUNI,
MOUNT CARMEL, IL.
MSL. TREES BEGINNING 4391 FT FROM DER, 392 FT RIGHT OF CENTERLINE,
UP TO 562 FT MSL. ELEVATOR 4403 FT FROM DER, 851 FT LEFT OF
CENTERLINE, 148 FT AGL/606 FT MSL. TREES BEGINNING 4436 FT FROM
DER, 486 FT RIGHT OF CENTERLINE, UP TO 565 FT MSL. TREE 4717 FT
FROM DER, 757 FT RIGHT OF CENTERLINE, 567 FT MSL. TREES BEGINNING
4723 FT FROM DER, 424 FT RIGHT OF CENTERLINE, UP TO 587 FT MSL.
TREES BEGINNING 4912 FT FROM DER, 568 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/596 FT MSL. TREES 5838 FT FROM DER, 1924 FT RIGHT OF
CENTERLINE, 100 FT AGL/599 FT MSL. TREES 5994 FT FROM DER, 2105 FT
RIGHT OF CENTERLINE, 100 FT AGL/609 FT MSL. NOTE: RWY 31, POLE,
TRANSMISSION LINE BEGINNING 1811 FT FROM DER, 317 FT LEFT OF
CENTERLINE, UP TO 57 FT AGL/484 FT MSL. TREES BEGINNING 2886 FT
FROM DER, 111 FT LEFT OF CENTERLINE, UP TO 91 FT AGL/516 FT MSL.
TREES BEGINNING 3027 FT FROM DER, 270 FT LEFT OF CENTERLINE, UP TO
104 FT AGL/527 FT MSL. TREE 3653 FT FROM DER, 217 FT RIGHT OF
CENTERLINE, 519 FT MSL. TREES BEGINNING 4845 FT FROM DER, 1793 FT
LEFT OF CENTERLINE, UP TO 100 FT AGL/550 FT MSL. TREE 4862 FT FROM
DER, 808 FT RIGHT OF CENTERLINE, 551 FT MSL. TREE 4923 FT FROM DER,
506 FT RIGHT OF CENTERLINE, 556 FT MSL. TREES BEGINNING 5068 FT
FROM DER, 824 FT RIGHT OF CENTERLINE, UP TO 566 FT MSL. TREES
ALL OTHER DATA REMAINS AS PUBLISHED. 2308291237-2508291237EST
END PART 2 OF 3
!FDC 3/2768 AJG PART 3 OF 3 ODP MOUNT CARMEL MUNI,
MOUNT CARMEL, IL.
BEGINNING 5242 FT FROM DER, 510 FT RIGHT OF CENTERLINE, UP TO 99 FT
AGL/576 FT MSL. TREES BEGINNING 5388 FT FROM DER, 838 FT RIGHT OF
CENTERLINE, UP TO 578 FT MSL. TREE 5491 FT FROM DER, 854 FT RIGHT
OF CENTERLINE, 101 FT AGL/580 FT MSL. TREES BEGINNING 5579 FT FROM
DER, 934 FT RIGHT OF CENTERLINE, UP TO 100 FT AGL/580 FT MSL..
ALL OTHER DATA REMAINS AS PUBLISHED. 2308291237-2508291237EST
END PART 3 OF 3
|
