GREAT BEND MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KGBD
GREAT BEND MUNI
PublicPUB

4 miles W of GREAT BEND, KS
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 20' 39"N 98° 51' 33"W
1887' MSL
2887' MSL
08E
Jet A, 100LL
WICHITA (ICT)
WICHITA
KANSAS CITY (ZKC)
5/16/24-6/13/24
KGBD VFR
2:56 AM CDT
Clear
10sm
64°F
60°F
29.73"Hg
190° 10kts
AO2 SLP052 T01780156
KGBD 180756Z AUTO 19010KT 10SM CLR 18/16 A2973 RMK AO2 SLP052 T01780156
List Your Business

KGBD FBOs, Flight Schools and Ground Support

Promote Listing
Coulson Aviation
Freq: 122.8
Phone: (620) 796-2130
No Rating Available
0 Reviews (Read | Sign In To Write)
EPIC
As of 5/1
 100LL Jet A Jet A+ Mogas UL94
Self Serve 6.02 5.46
Full Serve 6.45 5.67

KGBD Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

KGBD Hotels

No hotels are listed for this airport.

KGBD Restaurants

No restaurants are listed for this airport.

KGBD Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3PT

AWOS-3PT
620-792-5019
 119.275

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KGBD
Sat, 5/18 12:20 AM CDT
Sat, 5/18 1:00 AM CDT - Sun, 5/19 1:00 AM CDT
VFR
1:00 AM CDT - 5:00 AM CDT
Sky Clear
6sm
170° 9kts
VFR
5:00 AM CDT - 11:00 AM CDT
Few 25,000'
6sm
200° 11kts
VFR
11:00 AM CDT - 2:00 PM CDT
Scattered 25,000'
6sm
260° 13kts
VFR
2:00 PM CDT - 6:00 PM CDT
Scattered 12,000'
6sm
360° 16kts
Gusts 25kts
VFR
6:00 PM CDT - 1:00 AM CDT
Scattered 12,000'
6sm
040° 13kts
KGBD 180520Z 1806/1906 17009KT P6SM SKC
   FM181000 20011KT P6SM FEW250
   FM181600 26013KT P6SM SCT250
   FM181900 36016G25KT P6SM SCT120
   FM182300 04013KT P6SM SCT120
KGBD
Domestic
5/16/241506Z !GBD 05/010 GBD OBST TOWER LGT (ASN 2023-ACE-2272-OE) 382727N0984651W (7.7NM NNE GBD) 2270FT (385FT AGL) U/S 2405161506-2406301506
5/13/240321Z !GBD 05/003 GBD OBST TOWER LGT (ASR 1044222) 382653.00N0984610.00W (7.5NM NE GBD) 2315.0FT (415.0FT AGL) U/S 2405130321-2406270321
4/22/241838Z !GBD 04/005 GBD OBST TOWER LGT (ASR 1218768) 382305.70N0984544.00W (5.2NM ENE GBD) 2162.1FT (313.0FT AGL) U/S 2404221838-2406061837
FDC
5/2/241238Z !FDC 4/7669 GBD IAP GREAT BEND MUNI, GREAT BEND, KS.
ILS OR LOC RWY 35, ORIG-E...
PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
HUT VOR/DME OUT OF SERVICE. 2405021238-2406021238EST
6/27/231818Z !FDC 3/7214 GBD ODP GREAT BEND MUNI, GREAT BEND, KS.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 11: TREE 898 FT FROM DER, 721 FT LEFT OF CENTERLINE, 1920 FT MSL. RWY 29: TERRAIN 158 FT FROM DER, 382 FT LEFT OF CENTERLINE, 1891 FT MSL. RWY 35: LIGHTING 22 FT FROM DER, 89 FT LEFT OF CENTERLINE, 4 FT AGL/1884 FT MSL. LIGHTING 22 FT FROM DER, 90 FT RIGHT OF CENTERLINE, 4 FT AGL/1884 FT MSL. TREE 1316 FT FROM DER, 823 FT LEFT OF CENTERLINE, 1947 FT MSL. 2306271818-2506271818EST
No
0630-1800
AFTER 1800 BY REQUEST.
CITY OF GREAT BEND
CITY HALL, BOX 1168
GREAT BEND, KS 67530
Phone: 620-793-4111
MR. MARTIN MILLER
CITY HALL, BOX 1168
GREAT BEND, KS 67530
Phone: 620-793-4168
WICHITA FSS (ICT)
Toll Free: 1-800-WX-BRIEF
GBD
--
ACTVT MALSR RWY 35; REIL RWY 17; PAPI RWY 11, 17 & 29; VASI RWY 35; MIRL 11/29 & 17/35 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
33
4
2
1
0
0
Major
Major
None
Low Pressure
Crop Dusting
Air Ambulance
Pilot Instruction

Runway 11/29

4706 ft. x 75 ft.
ASPH
Fair
NONE
MED
9 /R/C/X/U
28,000lbs
35,000lbs
86,000lbs
--
  Runway 11 Runway 29
True Heading 120°300°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 38° 20' 34"N 38° 20' 11"N
Longitude 98° 52' 10"W 98° 51' 19"W
Elevation 1,887' 1,883'
Threshold Crossing Height 38 ft. AGL 43 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 17/35

7852 ft. x 100 ft.
CONC
Fair
AFSC
MED
19 /R/C/X/U
28,000lbs
35,000lbs
86,000lbs
--
  Runway 17 Runway 35
True Heading 180°360°
Traffic Pattern Left Left
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 38° 21' 28"N 38° 20' 11"N
Longitude 98° 51' 26"W 98° 51' 26"W
Elevation 1,881' 1,882'
Threshold Crossing Height 38 ft. AGL 50 ft. AGL
Visual Glide Path Angle 3.5° 3°
Visual Slope Indicator P4L V4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes
A110-1CALM WIND RY DESIGNATED AS RY 17.
A110-3100LL AND JET A SELF-SERVE FUEL AVBL N END OF TRML APRON. CALL FBO 620-796-2130 FOR FUEL PRICES.
A110-4FOR CD IF UNA TO CTC ON FSS FREQ, CTC KANSAS CITY ARTCC AT 913-254-8508.
GREAT BEND MUNI (ICAO: KGBD, IATA: GBD) is a public airport located in GREAT BEND, KS.
