| Domestic |
|
5/12/242245Z
|
!LOT 05/003 LOT OBST TOWER LGT (ASR 1011738) 413301.00N0880528.00W (3.5NM S LOT) 846.1FT (216.2FT AGL) U/S 2405122245-2405272245
|
|
5/10/240126Z
|
!LOT 05/002 LOT OBST TOWER LGT (ASR 1018598) 413913.50N0875619.30W (7.6NM ENE LOT) 1020.0FT (302.8FT AGL) U/S 2405100126-2406092359
|
|
4/28/231207Z
|
!LOT 04/022 LOT NAV ILS RWY 09 LOC/DME U/S 2304281207-2412312100
|
| FDC |
|
3/18/241518Z
|
!FDC 4/8329 LOT IAP LEWIS UNIVERSITY, CHICAGO/ROMEOVILLE, IL.
LOC RWY 2, AMDT 1B...
PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
JOT VOR/DME OUT OF SERVICE. 2403181518-2410281518EST
|
|
5/18/231056Z
|
!FDC 3/8136 LOT IAP LEWIS UNIVERSITY, CHICAGO/ROMEOVILLE, IL.
RNAV (GPS) RWY 20, AMDT 1A...
CIRCLING CAT C AND D MDA 1480/HAA 801.
VDP NA.
VISUAL SEGMENT - OBSTACLES.
2305181056-2505181056EST
|
|
5/18/231056Z
|
!FDC 3/8135 LOT IAP LEWIS UNIVERSITY, CHICAGO/ROMEOVILLE, IL.
LOC/DME RWY 9, AMDT 1B...
RNAV (GPS) RWY 2, AMDT 2B...
RNAV (GPS) RWY 27, ORIG-B...
RNAV (GPS) RWY 9, ORIG-A...
CIRCLING CAT C AND D MDA 1480/HAA 801.
2305181056-2505181056EST
|
|
5/18/231056Z
|
!FDC 3/8133 LOT IAP LEWIS UNIVERSITY, CHICAGO/ROMEOVILLE, IL.
LOC RWY 2, AMDT 1B...
CIRCLING AND TURRK FIX MINIMUMS CIRCLING CAT C AND D MDA 1480/HAA 801.
2305181056-2505181056EST
|
|
5/17/231502Z
|
!FDC 3/7655 LOT PART 1 OF 3 ODP LEWIS UNIVERSITY,
CHICAGO/ROMEOVILLE, IL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 2: LIGHT POLES BEGINNING 9 FT FROM DER, 29 FT LEFT OF
CENTERLINE, 2 FT AGL/668 FT MSL.
LIGHT POLES BEGINNING 10 FT FROM DER, 30 FT RIGHT OF CENTERLINE, 2
FT AGL/668 FT MSL.
TREE 1195 FT FROM DER, 49 FT LEFT OF CENTERLINE, 701 FT MSL.
ANTENNA, TOWER, TRANSMISSION LINES BEGINNING 4983 FT FROM DER, 361
FT LEFT OF CENTERLINE, UP TO 203 FT AGL/845 FT MSL.
ELECTRICAL SYSTEM, TRANSMISSION LINES BEGINNING 5280 FT FROM DER,
1102 FT LEFT OF CENTERLINE, UP TO 189 FT AGL/851 FT MSL.
ELECTRICAL SYSTEM 5431 FT FROM DER, 1293 FT LEFT OF CENTERLINE, 204
FT AGL/866 FT MSL.
TOWER, TRANSMISSION LINE BEGINNING 5480 FT FROM DER, 1133 FT LEFT
OF CENTERLINE, UP TO 210 FT AGL/875 FT MSL.
TRANSMISSION LINE 5570 FT FROM DER, 1235 FT LEFT OF CENTERLINE, 212
FT AGL/876 FT MSL.
NOTE: RWY 9: BUILDING, TERRAIN BEGINNING 0 FT FROM DER, 488 FT LEFT
OF CENTERLINE, UP TO 689 FT MSL.
POLE 473 FT FROM DER, 452 FT RIGHT OF CENTERLINE, 26 FT AGL/687 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2305171502-2505171502EST
END PART 1 OF 3
!FDC 3/7655 LOT PART 2 OF 3 ODP LEWIS UNIVERSITY,
CHICAGO/ROMEOVILLE, IL.
MSL.
TREES BEGINNING 559 FT FROM DER, 520 FT LEFT OF CENTERLINE, UP TO
707 FT MSL.
TREE 804 FT FROM DER, 655 FT LEFT OF CENTERLINE, 716 FT MSL.
TREES BEGINNING 811 FT FROM DER, 105 FT RIGHT OF CENTERLINE, UP TO
721 FT MSL.
TREE 865 FT FROM DER, 515 FT LEFT OF CENTERLINE, 722 FT MSL.
TREES BEGINNING 964 FT FROM DER, 626 FT LEFT OF CENTERLINE, UP TO
733 FT MSL.
TREES BEGINNING 1052 FT FROM DER, 259 FT LEFT OF CENTERLINE, UP TO
735 FT MSL.
NOTE: RWY 20: LIGHTING 9 FT FROM DER, 29 FT RIGHT OF CENTERLINE, 2
FT AGL/681 FT MSL.
LIGHTING 10 FT FROM DER, 29 FT LEFT OF CENTERLINE, 2 FT AGL/681 FT
MSL.
NOTE: RWY 27: LIGHT POLES BEGINNING 10 FT FROM DER, 16 FT LEFT OF
CENTERLINE, 2 FT AGL/675 FT MSL.
LIGHT POLES BEGINNING 10 FT FROM DER, 17 FT RIGHT OF CENTERLINE, 2
FT AGL/675 FT MSL.
TREES BEGINNING 1143 FT FROM DER, 689 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2305171502-2505171502EST
END PART 2 OF 3
!FDC 3/7655 LOT PART 3 OF 3 ODP LEWIS UNIVERSITY,
CHICAGO/ROMEOVILLE, IL.
708 FT MSL.
TREE 1303 FT FROM DER, 640 FT RIGHT OF CENTERLINE, 725 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2305171502-2505171502EST
END PART 3 OF 3
|
