| Domestic |
|
5/14/241924Z
|
!OEB 05/002 OEB OBST TOWER LGT (ASR 1006584) 420122.00N0845202.00W (9.9NM ENE OEB) 1337.6FT (267.7FT AGL) U/S 2405141924-2409111924
|
| FDC |
|
1/6/232004Z
|
!FDC 3/1889 OEB PART 1 OF 2 ODP BRANCH COUNTY MEML, COLDWATER, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 4...
IN ADDITION TO PUBLISHED TAKEOFF OBSTACLE NOTES, ADD THE FOLLOWING:
RWY 7: LIGHT POLES, NAVAID BEGINNING 10 FT FROM DER, 16 FT RIGHT OF
CENTERLINE, UP TO 2 FT AGL/956 FT MSL.
LIGHT POLES, NAVAID BEGINNING 10 FT FROM DER, 18 FT LEFT OF
CENTERLINE, UP TO 2 FT AGL/956 FT MSL. RWY 22: LIGHT POLES 9 FT
FROM DER, 27 FT RIGHT OF CENTERLINE, 3 FT AGL/959 FT MSL.
LIGHT POLES 10 FT FROM DER, 27 FT LEFT OF CENTERLINE, 3 FT AGL/959
FT MSL.
VERTICALSTRUCTURE 451 FT FROM DER, 565 FT RIGHT OF CENTERLINE, 30
FT AGL/987 FT MSL.
TREE 752 FT FROM DER, 619 FT LEFT OF CENTERLINE, 1004 FT MSL. RWY
25: LIGHT POLES, NAVAID BEGINNING 9 FT FROM DER, 17 FT RIGHT OF
CENTERLINE, UP TO 2 FT AGL/959 FT MSL.
LIGHT POLES, NAVAID BEGINNING 9 FT FROM DER, 18 FT LEFT OF
CENTERLINE, UP TO 3 FT AGL/959 FT MSL.
TREE 721 FT FROM DER, 637 FT LEFT OF CENTERLINE, 977 FT MSL. TREES
BEGINNING 762 FT FROM DER, 516 FT LEFT OF CENTERLINE, UP TO 1019 FT
MSL. TREES BEGINNING 944 FT FROM DER, 26 FT LEFT OF CENTERLINE, UP
TO 1028 FT MSL. TREES BEGINNING 1083 FT FROM DER, 9 FT LEFT OF
1039 FT MSL. 2301062004-2501062004EST
END PART 1 OF 2
!FDC 3/1889 OEB PART 2 OF 2 ODP BRANCH COUNTY MEML, COLDWATER, MI.
CENTERLINE, UP TO 1035 FT MSL.
TREES BEGINNING 1521 FT FROM DER, 86 FT LEFT OF CENTERLINE, UP TO
1039 FT MSL. 2301062004-2501062004EST
END PART 2 OF 2
|
