11/3/221224Z
|
!FDC 2/6379 VCV PART 1 OF 4 ODP SOUTHERN CALIFORNIA LOGISTICS,
VICTORVILLE, CA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 3, TERRAIN 5 FT FROM DER, 114 FT RIGHT
OF CENTERLINE, 2845 FT MSL.
TREES BEGINNING 16 FT FROM DER, 101 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/2955 FT MSL.
TREES BEGINNING 152 FT FROM DER, 77 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/2958 FT MSL.
TREES BEGINNING 544 FT FROM DER, 43 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/2965 FT MSL.
POLE 408 FT FROM DER, 511 FT RIGHT OF CENTERLINE, 29 FT AGL/2873 FT
MSL.
TERRAIN BEGINNING 153 FT FROM DER, 41 FT RIGHT OF CENTERLINE, UP TO
3196 FT MSL.
TERRAIN BEGINNING 17 FT FROM DER, 104 FT LEFT OF CENTERLINE UP TO
2855 FT MSL.
TREE 2.1 NM FROM DER, 3735 FT RIGHT OF CENTERLINE, 50 FT AGL/3269'
MSL.
RWY 17, LIGHT POLES 11 FT FROM DER, 113 FT RIGHT OF CENTERLINE, 2
FT AGL/2886 FT MSL.
TREES BEGINNING 108 FT FROM DER, 91 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2211031224-2411031224EST
END PART 1 OF 4
!FDC 2/6379 VCV PART 2 OF 4 ODP SOUTHERN CALIFORNIA LOGISTICS,
VICTORVILLE, CA.
100 FT AGL/2994 FT MSL.
TREES 113 FT FROM DER, 159 FT LEFT OF CENTERLINE, 100 FT AGL/2997
FT MSL.
TREES 115 FT FROM DER, 410 FT LEFT OF CENTERLINE, 100 FT AGL/3001
FT MSL.
TREES BEGINNING 410 FT FROM DER, 93 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/3004 FT MSL.
TREES BEGINNING 416 FT FROM DER, 146 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/3004 FT MSL.
SIGN 248 FT FROM DER, 20 FT LEFT OF CENTERLINE, 14 FT AGL/2896 FT
MSL.
ANT ON BLDG 701 FT FROM DER, 203 FT LEFT OF CENTERLINE, 20 FT AGL
2902 FT MSL.
RWY 21, TREES BEGINNING 0 FT FROM DER, 107 FT LEFT OF CENTERLINE,
UP TO 100 FT AGL/2991 FT MSL.
TREES 135 FT FROM DER, 462 FT RIGHT OF CENTERLINE, 100 FT AGL/2984
FT MSL.
TREES BEGINNING 176 FT FROM DER, 71 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/2988 FT MSL.
TREES BEGINNING 432 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2211031224-2411031224EST
END PART 2 OF 4
!FDC 2/6379 VCV PART 3 OF 4 ODP SOUTHERN CALIFORNIA LOGISTICS,
VICTORVILLE, CA.
100 FT AGL/3004 FT MSL.
TREES BEGINNING 568 FT FROM DER, 37 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/2991 FT MSL.
TREES BEGINNING 919 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/2994 FT MSL.
TREES BEGINNING 1095 FT FROM DER, 182 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/2997 FT MSL.
TREES BEGINNING 1271 FT FROM DER, 81 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/3001 FT MSL.
TREES BEGINNING 2488 FT FROM DER, 13 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/3004 FT MSL.
TREES BEGINNING 2825 FT FROM DER, 19 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/3007 FT MSL.
TREES BEGINNING 4434 FT FROM DER, 300 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/3011 FT MSL.
TREES BEGINNING 4610 FT FROM DER, 121 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/3014 FT MSL.
TREES BEGINNING 4625 FT FROM DER, 270 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/3007 FT MSL.
TREES BEGINNING 4841 FT FROM DER, 57 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2211031224-2411031224EST
END PART 3 OF 4
!FDC 2/6379 VCV PART 4 OF 4 ODP SOUTHERN CALIFORNIA LOGISTICS,
VICTORVILLE, CA.
100 FT AGL/3011 FT MSL.
TREES BEGINNING 4962 FT FROM DER, 154 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/3017 FT MSL.
TREES BEGINNING 5395 FT FROM DER, 401 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/3020 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2211031224-2411031224EST
END PART 4 OF 4
|
