12G
SHELBY COMMUNITY
PublicPUB

2 miles W of SHELBY, OH
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
40° 52' 22"N 82° 41' 51"W
1120' MSL
2120' MSL
06W
None Listed
CLEVELAND (CLE)
DETROIT
CLEVELAND (ZOB)
5/16/24-6/13/24
KMFD (9nm) VFR
3:08 PM EDT
Overcast 3,400'
Scattered 1,300'
Scattered 900'
10sm
68°F
62°F
29.98"Hg
200° 6kts
AO2 T02000167
KMFD 021908Z 20006KT 10SM SCT009 SCT013 OVC034 20/17 A2998 RMK AO2 T02000167
Add Your Business

12G FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KMFD (9nm)
Sun, 6/2 1:50 PM EDT
Sun, 6/2 2:00 PM EDT - Mon, 6/3 2:00 PM EDT
IFR
2:00 PM EDT - 3:00 PM EDT
Overcast 800'
6sm
220° 9kts
MVFR
3:00 PM EDT - 5:00 PM EDT
Broken 1,800'
6sm
220° 8kts
MVFR
5:00 PM EDT - 1:00 AM EDT
Showers in vicinity
Broken 2,500'
6sm
210° 7kts
MVFR
Temporary 5:00 PM EDT - 7:00 PM EDT
Light Showers and Rain
Broken 1,500'
5sm
Calm
MVFR
1:00 AM EDT - 4:00 AM EDT
Mist
Broken 2,500'
4sm
VRB° 3kts
IFR
4:00 AM EDT - 10:00 AM EDT
Mist
Broken 500'
2sm
VRB° 2kts
LIFR
Temporary 6:00 AM EDT - 9:00 AM EDT
Fog
Overcast 200'
0.25sm
Calm
IFR
10:00 AM EDT - 12:00 PM EDT
Mist
Broken 800'
4sm
200° 4kts
MVFR
12:00 PM EDT - 2:00 PM EDT
Broken 3,000'
6sm
230° 4kts
KMFD 021750Z 0218/0318 22009KT P6SM OVC008
   FM021900 22008KT P6SM BKN018
   FM022100 21007KT P6SM VCSH BKN025
   TEMPO 0221/0223 5SM -SHRA BKN015
   FM030500 VRB03KT 4SM BR BKN025
   FM030800 VRB02KT 2SM BR BKN005
   TEMPO 0310/0313 1/4SM FG OVC002
   FM031400 20004KT 4SM BR BKN008
   FM031600 23004KT P6SM BKN030
12G
Domestic
5/21/240800Z !CLE 05/625 12G OBST TOWER LGT (ASR 1019795) 405642.00N0823942.00W (4.7NM NNE 12G) 1376.6FT (264.8FT AGL) U/S 2405210800-2406200001
No
0600-1700
SHELBY AIRPORT LLC
PO BOX 29
SHELBY, OH 44875-0029
Phone: 419-347-1185
DOUG SCHMIDT
5085 STATE ROUTE 39 W
SHELBY, OH 44875-9061
Phone: 419-347-1185
CLEVELAND FSS (CLE)
Toll Free: 1-800-WX-BRIEF
CLE
Sunset to Sunrise
--
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
11
0
0
0
0
1
None
None
None
None
None

Runway 03/21

1890 ft. x 125 ft.
TURF
Good
NONE


--
--
--
--
  Runway 03 Runway 21
True Heading 25°205°
Traffic Pattern Left Left
Markings NONE NONE
Markings Condition
Latitude 40° 52' 20"N 40° 52' 37"N
Longitude 82° 41' 59"W 82° 41' 49"W
Elevation 1,120' 1,118'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No

Runway 18/36

3174 ft. x 50 ft.
ASPH
Fair
NONE
NSTD

5,000lbs
--
--
--
  Runway 18 Runway 36
True Heading 179°359°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 40° 52' 34"N 40° 52' 03"N
Longitude 82° 41' 49"W 82° 41' 48"W
Elevation 1,118' 1,119'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1FOR CD CTC CLEVELAND APCH AT 216-352-2323, WHEN APCH CLSD CTC CLEVELAND ARTCC AT 440-774-0223.
A110-2RWY 18/36: 35 FT PLINE, 975 FT NORTH OF RWY END 18, NOT MKD; 95 FT PLINE, 1810 FT SOUTH OF RWY END 36, NOT MKD.
SHELBY COMMUNITY (IATA: 12G) is a public airport located in SHELBY, OH.
