LAKEVIEW - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

30F
LAKEVIEW
PublicPUB

1 miles NE of LAKE DALLAS, TX
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
33° 07' 53"N 97° 00' 51"W
535' MSL
1535' MSL
07E
None Listed
FORT WORTH (FTW)
DALLAS-FT WORTH
FORT WORTH (ZFW)
5/16/24-6/13/24
KDTO (10nm) VFR
6:22 PM CDT
Clear
10sm
69°F
67°F
29.81"Hg
150° 12kts
AO2 LTG DSNT SE-SW RAE02 P0001 T02060194
KDTO 022322Z 15012KT 10SM CLR 21/19 A2981 RMK AO2 LTG DSNT SE-SW RAE02 P0001 T02060194
Add Your Business

30F FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KDFW (14nm)
Sun, 6/2 6:20 PM CDT
Sun, 6/2 7:00 PM CDT - Tue, 6/4 1:00 AM CDT
VFR
7:00 PM CDT - 8:30 PM CDT
Thunderstorm in vicinity
Broken 3,500'
6sm
020° 11kts
MVFR
Temporary 7:00 PM CDT - 8:00 PM CDT
Thunderstorm and Rain
Broken 2,000'
3sm
360° 15kts
Gusts 30kts
VFR
8:30 PM CDT - 3:00 AM CDT
Broken 3,500'
Scattered 1,500'
6sm
110° 10kts
VFR
3:00 AM CDT - 5:00 AM CDT
Thunderstorm in vicinity
Broken 3,500'
6sm
160° 14kts
MVFR
5:00 AM CDT - 12:00 PM CDT
Broken 1,400'
6sm
150° 9kts
VFR
12:00 PM CDT - 1:00 AM CDT
Scattered 2,500'
6sm
180° 16kts
KDFW 022320Z 0300/0406 02011KT P6SM VCTS BKN035CB
   TEMPO 0300/0301 36015G30KT 3SM TSRA BKN020CB
   FM030130 11010KT P6SM SCT015 BKN035
   FM030800 16014KT P6SM VCTS BKN035CB
   FM031000 15009KT P6SM BKN014
   FM031700 18016KT P6SM SCT025
30F
Domestic
5/30/241300Z !FTW 05/082 30F OBST TOWER LGT (ASR 1051510) 331202.70N0970459.80W (5.4NM NW 30F) 1048.9FT (463.9FT AGL) U/S 2405301300-2408280400
5/21/240513Z !FTW 05/606 30F OBST TOWER LGT (ASR 1209701) 331407.80N0965830.60W (6.5NM NNE 30F) 838.9FT (249.0FT AGL) U/S 2405210513-2406050413
5/3/241549Z !FTW 05/121 30F OBST TOWER LGT (ASR 1256650) 330751.60N0970604.60W (4.4NM W 30F) 1045.9FT (469.8FT AGL) U/S 2405031549-2406032359
3/24/241500Z !FTW 03/613 30F AIRSPACE SEE CVE 03/610 UAS DLY 1500-0100 2403241500-2409250100
3/10/241244Z !FTW 03/200 30F AIRSPACE SEE TTT 03/199 UAS DLY SR-SS
2403101244-2411032334
3/10/241243Z !FTW 03/204 30F AIRSPACE SEE CVE 03/201 UAS DLY SR-SS
2403101243-2411032333
3/10/241243Z !FTW 03/197 30F AIRSPACE SEE CVE 03/195 UAS DLY SR-SS
2403101243-2411032333
No
UNATNDD
U S GOVT & SQUIER FAMILY
PO BOX 1026
LAKE DALLAS, TX 75065
Phone: 214-850-8180
RANDY SQUIER
PO BOX 356
LAKE DALLAS, TX 75065
Phone: 214-850-8180
FORT WORTH FSS (FTW)
Toll Free: 1-800-WX-BRIEF
FTW
--
--
N/A
Yes
No
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
63
0
0
0
0
1
None
None
None
None
None

Runway 18L/36R

2815 ft. x 30 ft.
ASPH
Poor
NONE


4,000lbs
--
--
--
  Runway 18L Runway 36R
True Heading Not ListedNot Listed
Traffic Pattern Left Left
Markings
Markings Condition
Latitude N/A N/A
Longitude N/A N/A
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 18R/36L

2600 ft. x 75 ft.
TURF
Fair
NONE


--
--
--
--
  Runway 18R Runway 36L
True Heading 184°4°
Traffic Pattern
Markings
Markings Condition
Latitude 33° 08' 06"N 33° 07' 40"N
Longitude 97° 00' 50"W 97° 00' 52"W
Elevation 534' 531'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1NO TGL PERMITTED.
A110-10RWY 18R/36L BOATS & TRAILERS PARKED ALONG WEST EDGE OF RWY.
A110-11RWY 18R/36L DEFINED BY MOWING. UNA TO DTRM LCTN OF RWY, NOT INSPD.
A110-2ARPT CLSD TO TSNT STUDENTS.
A110-3BIRDS ON AND INVOF ARPT.
A110-5POWERED PARACHUTES AND BALLOONS PROHIBITED.
A110-6RWY 18L/36R LAKE 350 FT FM NORTH END OF RWY, 170 FT FM SOUTH END. PORTIONS OF RWY MAY BE UNDER WATER DURING HEAVY RAINS.
A110-7GATE LOCKED 24 HRS.
A110-8FOR CD CTC REGIONAL APCH AT 972-615-2799.
A110-9RWY 36 30 FT TREES, 30-65 FT R, PARALLEL TO RWY.
LAKEVIEW (IATA: 30F) is a public airport located in LAKE DALLAS, TX.
