KVAY
SOUTH JERSEY RGNL
PublicPUB

4 miles SW of MOUNT HOLLY, NJ
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
39° 56' 34"N 74° 50' 45"W
53' MSL
853' MSL
12W
JET A, 100LL
MILLVILLE (MIV)
WASHINGTON
WASHINGTON (ZDC)
5/16/24-6/13/24
KVAY VFR
6:54 PM EDT
Clear
10sm
81°F
54°F
29.96"Hg
230° 7kts
AO2 SLP144 T02720122
KVAY 022254Z AUTO 23007KT 10SM CLR 27/12 A2996 RMK AO2 SLP144 T02720122
Add Your Business

KVAY FBOs

Promote Listing
South Jersey Airport
UNICOM: 122.8
Phone: (609) 267-3131
No Rating Available
0 Reviews (Read | Sign In To Write)
Avfuel
As of 5/17
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 7.50 6.75
Fuel Notes
Prices include tax

KVAY Other Businesses

Joy of Flight
UNICOM: 122.8
Phone: (609) 755-5867
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

ASOS

ASOS
609-267-1176
 119.325

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

Instrument Approach

Terminal Area Forecast

KPNE (11nm)
Sun, 6/2 1:28 PM EDT
Sun, 6/2 2:00 PM EDT - Mon, 6/3 2:00 PM EDT
VFR
2:00 PM EDT - 9:00 PM EDT
Broken 25,000'
6sm
220° 9kts
VFR
9:00 PM EDT - 8:00 AM EDT
Showers in vicinity
Overcast 7,000'
6sm
VRB° 4kts
VFR
8:00 AM EDT - 2:00 PM EDT
Scattered 7,000'
6sm
VRB° 3kts
KPNE 021728Z 0218/0318 22009KT P6SM BKN250
   FM030100 VRB04KT P6SM VCSH OVC070
   FM031200 VRB03KT P6SM SCT070
KVAY
No NOTAM Available
No
APR-OCT 0800-2000
NOV-MAR 0800-1800
ARPT UNATNDD THANKSGIVING & CHRISTMAS DAY. CHRISTMAS & THANKSGIVING EVE HRS 0800-1200. NEW YEARS DAY HRS 1100-1800.
N.J. DEPT. OF TRANSPORTATION
1035 PARKWAY AVE., P.O. BOX 600
TRENTON, NJ 08625-0600
Phone: 609-530-2900
MINDY KIMBALL
68 STACY HAINES RD.
LUMBERTON, NJ 08048
Phone: 609-267-3131
MILLVILLE FSS (MIV)
Toll Free: 1-800-WX-BRIEF
VAY
--
ACTVT MIRL RY 08/26 AND REIL RY 08 & 26 -123.3.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
71
5
0
1
0
0
Major
Major
None
None
Air Ambulance
Pilot Instruction

Runway 08/26

3881 ft. x 50 ft.
ASPH
Good
NONE
MED

30,000lbs
--
--
--
  Runway 08 Runway 26
True Heading 70°250°
Traffic Pattern Left Right
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 39° 56' 28"N 39° 56' 41"N
Longitude 74° 51' 08"W 74° 50' 21"W
Elevation 44' 52'
Threshold Crossing Height 45 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3.25° 3°
Visual Slope Indicator P2R P2R
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes
A110-1TREES ALONG SIDES OF RY PRIMARILY NW.
A110-2BALLS MKG PLINES ON APH TO RY 08 FADED.
A110-3DEER ON & INVOF ARPT.
A110-4HELICOPTER TAKEOFFS AND LANDINGS RESTRICTED TO RY 08/26 ONLY.
A110-7PARALLEL TAXIWAY NON-STANDARD WIDTH, 18 FT ASP.
A110-8AVOID OVERFLYING HOUSING AREA WNW OF ARPT BELOW 300 FT WHEN IN THE TRAFFIC PATTERN FOR RWY 8.
A110-9FOR CD CTC MC GUIRE APCH AT 609-754-2767.
SOUTH JERSEY RGNL (ICAO: KVAY, IATA: VAY) is a public airport located in MOUNT HOLLY, NJ.
