4/12/231516Z
|
!FDC 3/0688 43A PART 1 OF 2 ODP MONTGOMERY COUNTY, STAR, NC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 3: TREES, POLES, CATENARY WIRES
BEGINNING 29 FT FROM DER, 25 FT LEFT OF CENTERLINE, UP TO 724 FT
MSL.
TRANSMISSION LINE 120 FT FROM DER, 277 FT RIGHT OF CENTERLINE, 43
FT AGL/666 FT MSL.
TREE 133 FT FROM DER, 463 FT RIGHT OF CENTERLINE, 705 FT MSL.
TREES, CATENARY WIRES, TRANSMISSION LINES, POLE BEGINNING 260 FT
FROM DER, 10 FT RIGHT OF CENTERLINE, UP TO 708 FT MSL.
ANTENNA, TREES BEGINNING 1460 FT FROM DER, 16 FT RIGHT OF
CENTERLINE, UP TO 90 FT AGL/719 FT MSL.
TREES BEGINNING 1757 FT FROM DER, 23 FT LEFT OF CENTERLINE, UP TO
733 FT MSL.
TREES BEGINNING 1767 FT FROM DER, 472 FT RIGHT OF CENTERLINE, UP TO
724 FT MSL.
TREES BEGINNING 1784 FT FROM DER, 303 FT RIGHT OF CENTERLINE, UP TO
725 FT MSL.
TREES BEGINNING 1808 FT FROM DER, 254 FT RIGHT OF CENTERLINE, UP TO
730 FT MSL.
TREES, BUILDING SPIRE BEGINNING 1928 FT FROM DER, 4 FT RIGHT OF
FT AGL/713 FT MSL. 2304121516-2504121516EST
END PART 1 OF 2
!FDC 3/0688 43A PART 2 OF 2 ODP MONTGOMERY COUNTY, STAR, NC.
CENTERLINE, UP TO 747 FT MSL.
TREES BEGINNING 2683 FT FROM DER, 298 FT LEFT OF CENTERLINE, UP TO
734 FT MSL.
TREE 2828 FT FROM DER, 629 FT LEFT OF CENTERLINE, 735 FT MSL.
TREES BEGINNING 2891 FT FROM DER, 315 FT LEFT OF CENTERLINE, UP TO
749 FT MSL.
TREES BEGINNING 3557 FT FROM DER, 192 FT RIGHT OF CENTERLINE, UP TO
753 FT MSL.
TREE 4904 FT FROM DER, 1740 FT LEFT OF CENTERLINE, 762 FT MSL.
WATER TOWER 1 NM FROM DER, 1649 FT LEFT OF CENTERLINE, 145 FT
AGL/793 FT MSL.
TANK 1 NM FROM DER, 1619 FT LEFT OF CENTERLINE, 145 FT AGL/793 FT
MSL.
RWY 21: TREES, BUILDING BEGINNING 103 FT FROM DER, 279 FT LEFT OF
CENTERLINE, UP TO 641 FT MSL.
TREES BEGINNING 1304 FT FROM DER, 173 FT LEFT OF CENTERLINE, UP TO
645 FT MSL.
TREES BEGINNING 2448 FT FROM DER, 922 FT LEFT OF CENTERLINE, UP TO
649 FT MSL.
TRANSMISSION LINE 5196 FT FROM DER, 1124 FT LEFT OF CENTERLINE, 101
FT AGL/713 FT MSL. 2304121516-2504121516EST
END PART 2 OF 2
|
