5/20/222053Z
|
!FDC 2/7688 MTJ PART 1 OF 3 ODP MONTROSE RGNL, MONTROSE, CO.
MONTROSE TWO DEPARTURE ...
CHANGE TAKEOFF OBSTACLE NOTES TO READ: NOTE: RWY 13, TREE, FENCE
BEGINNING 397 FT FROM DER, 428 FT LEFT OF CENTERLINE, UP TO 5816 FT
MSL. TREES, BUILDING, POLE BEGINNING 517 FT FROM DER, 296 FT LEFT
OF CENTERLINE, UP TO 5817 FT MSL. TREES, TRAVERSE_WAY, BUILDINGS
BEGINNING 769 FT FROM DER, 348 FT LEFT OF CENTERLINE, UP TO 5821 FT
MSL. POLES BEGINNING 1012 FT FROM DER, 657 FT RIGHT OF CENTERLINE,
UP TO 27 FT AGL/5791 FT MSL. TREES, BUILDING, POLE BEGINNING 1079
FT FROM DER, 11 FT LEFT OF CENTERLINE, UP TO 76 FT AGL/5842 FT MSL.
POLES BEGINNING 1285 FT FROM DER, 762 FT RIGHT OF CENTERLINE, UP TO
5795 FT MSL. TREE 1481 FT FROM DER, 857 FT RIGHT OF CENTERLINE,
5798 FT MSL. POLE 1651 FT FROM DER, 613 FT RIGHT OF CENTERLINE,
5802 FT MSL. TREE 1769 FT FROM DER, 526 FT RIGHT OF CENTERLINE,
5804 FT MSL. TREES BEGINNING 1946 FT FROM DER, 489 FT RIGHT OF
CENTERLINE, UP TO 5833 FT MSL. TREES BEGINNING 2382 FT FROM DER,
217 FT RIGHT OF CENTERLINE, UP TO 5835 FT MSL. TREES BEGINNING 2455
FT FROM DER, 358 FT RIGHT OF CENTERLINE, UP TO 5836 FT MSL. TREES
BEGINNING 2480 FT FROM DER, 36 FT RIGHT OF CENTERLINE, UP TO 64 FT
AGL/5837 FT MSL. TREES BEGINNING 2939 FT FROM DER, 391 FT LEFT OF
CENTERLINE, UP TO 5849 FT MSL. TREE 3170 FT FROM DER, 520 FT RIGHT
ALL OTHER DATA REMAINS AS PUBLISHED. 2205202053-2405202053EST
END PART 1 OF 3
!FDC 2/7688 MTJ PART 2 OF 3 ODP MONTROSE RGNL, MONTROSE, CO.
OF CENTERLINE, 5841 FT MSL. TREES BEGINNING 3281 FT FROM DER, 613
FT LEFT OF CENTERLINE, UP TO 5854 FT MSL. TREES BEGINNING 3528 FT
FROM DER, 525 FT LEFT OF CENTERLINE, UP TO 5859 FT MSL. TREES
BEGINNING 3849 FT FROM DER, 476 FT LEFT OF CENTERLINE, UP TO 5867
FT MSL. TREE 4445 FT FROM DER, 569 FT LEFT OF CENTERLINE, 5870 FT
MSL. TREE 4554 FT FROM DER, 1040 FT LEFT OF CENTERLINE, 5874 FT
MSL. TREE 4745 FT FROM DER, 231 FT LEFT OF CENTERLINE, 89 FT
AGL/5883 FT MSL. ANTENNA 4963 FT FROM DER, 1479 FT LEFT OF
CENTERLINE, 5884 FT MSL. TOWER, BUILDING BEGINNING 5662 FT FROM
DER, RIGHT OF CENTERLINE, UP TO 111 FT AGL/5912 FT MSL. BUILDING
5665 FT FROM DER, 13 FT LEFT OF CENTERLINE, 111 FT AGL/5912 FT MSL.
NOTE: RWY 17, FENCE, TERRAIN BEGINNING 7 FT FROM DER, 337 FT LEFT
OF CENTERLINE, UP TO 6 FT AGL/5741 FT MSL. ELECTRICAL SYSTEM 10 FT
FROM DER, 55 FT RIGHT OF CENTERLINE, 7 FT AGL/5735 FT MSL. SIGN 23
FT FROM DER, 308 FT RIGHT OF CENTERLINE, 13 FT AGL/5736 FT MSL.
NOTE: RWY 31, ELECTRICAL_SYSTEM 5 FT FROM DER, 30 FT RIGHT OF
CENTERLINE, 12 FT AGL/5700 FT MSL. GENERAL UTILITY 15 FT FROM DER,
124 FT LEFT OF CENTERLINE, 15 FT AGL/5699 FT MSL. VEGETATION 34 FT
FROM DER, 454 FT RIGHT OF CENTERLINE, 11 FT AGL/5705 FT MSL. TREE
150 FT FROM DER, 511 FT LEFT OF CENTERLINE, 5706 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2205202053-2405202053EST
END PART 2 OF 3
!FDC 2/7688 MTJ PART 3 OF 3 ODP MONTROSE RGNL, MONTROSE, CO.
TRANSMISSION LINE 212 FT FROM DER, 504 FT LEFT OF CENTERLINE, 30 FT
AGL/5718 FT MSL. TRAVERSE WAYS BEGINNING 239 FT FROM DER, 334 FT
RIGHT OF CENTERLINE, UP TO 5713 FT MSL. POLES, BUILDING BEGINNING
273 FT FROM DER, 151 FT LEFT OF CENTERLINE, UP TO 38 FT AGL/5724 FT
MSL. TREE 960 FT FROM DER, 399 FT LEFT OF CENTERLINE, 5727 FT MSL.
TREE 994 FT FROM DER, 572 FT LEFT OF CENTERLINE, 5734 FT MSL. TREE
4829 FT FROM DER, 1786 FT RIGHT OF CENTERLINE, 5820 FT MSL. NOTE:
RWY 35, ELECTRICAL_SYSTEM 7 FT FROM DER, 55 FT RIGHT OF CENTERLINE,
31 FT AGL/5695 FT MSL. ELECTRICAL SYSTEM 7 FT FROM DER, 55 FT LEFT
OF CENTERLINE, 29 FT AGL/5695 FT MSL. TREE 1385 FT FROM DER, 862 FT
RIGHT OF CENTERLINE, 64 FT AGL/5735 FT MSL. TREE 2429 FT FROM DER,
625 FT RIGHT OF CENTERLINE, 94 FT AGL/5755 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2205202053-2405202053EST
END PART 3 OF 3
|
