| Domestic |
|
5/8/240432Z
|
!STL 05/146 PJY OBST TOWER LGT (ASR 1284646) 375436.90N0891453.20W (6.7NM SE PJY) 642.7FT (219.8FT AGL) U/S 2405080432-2406220431
|
|
5/4/242258Z
|
!STL 05/095 PJY SVC PCL RWY 18/36 NOT STD KEY FREQ 122.8 7 TIMES HIGH, 5 TIMES MEDIUM, 3 TIME LOW INTST 2405042258-2407252359
|
|
3/6/240116Z
|
!STL 03/092 PJY OBST TOWER LGT (ASR 1062973) 380611.00N0891440.00W (9.3NM NE PJY) 1388.8FT (902.9FT AGL) U/S 2403060116-2406072359
|
| FDC |
|
8/16/231442Z
|
!FDC 3/5639 PJY PART 1 OF 2 ODP PINCKNEYVILLE/DU QUOIN,
PINCKNEYVILLE, IL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 18: TRAVERSE WAYS BEGINNING 68 FT FROM
DER, 333 FT LEFT OF CENTERLINE, UP TO 15 FT AGL/404 FT MSL.
TREE, POLES BEGINNING 403 FT FROM DER, 87 FT LEFT OF CENTERLINE, UP
TO 73 FT AGL/456 FT MSL.
TRAVERSE WAY 551 FT FROM DER, 246 FT RIGHT OF CENTERLINE, 29 FT
AGL/410 FT MSL.
TREE 2169 FT FROM DER, 898 FT RIGHT OF CENTERLINE, 62 FT AGL/455 FT
MSL.
TREE 2197 FT FROM DER, 731 FT RIGHT OF CENTERLINE, 66 FT AGL/459 FT
MSL.
TREES BEGINNING 2203 FT FROM DER, 290 FT LEFT OF CENTERLINE, UP TO
80 FT AGL/478 FT MSL.
TREES BEGINNING 2251 FT FROM DER, 237 FT RIGHT OF CENTERLINE, UP TO
77 FT AGL/471 FT MSL.
TREE 2295 FT FROM DER, 398 FT LEFT OF CENTERLINE, 84 FT AGL/481 FT
MSL.
TREE 2335 FT FROM DER, 629 FT LEFT OF CENTERLINE, 87 FT AGL/484 FT
MSL.
TREE 3268 FT FROM DER, 1264 FT RIGHT OF CENTERLINE, 83 FT AGL/479
82 FT AGL/470 FT MSL. 2308161442-2508161442EST
END PART 1 OF 2
!FDC 3/5639 PJY PART 2 OF 2 ODP PINCKNEYVILLE/DU QUOIN,
PINCKNEYVILLE, IL.
FT MSL.
TREES BEGINNING 3718 FT FROM DER, 1270 FT LEFT OF CENTERLINE, UP TO
98 FT AGL/489 FT MSL.
RWY 36: TREE, FENCES BEGINNING 77 FT FROM DER, 324 FT RIGHT OF
CENTERLINE, UP TO 25 FT AGL/413 FT MSL.
TREE 1740 FT FROM DER, 725 FT RIGHT OF CENTERLINE, 58 FT AGL/446 FT
MSL.
TREES BEGINNING 1838 FT FROM DER, 705 FT RIGHT OF CENTERLINE, UP TO
82 FT AGL/470 FT MSL. 2308161442-2508161442EST
END PART 2 OF 2
|
