05S
Local 05S
VERNONIA MUNI
PublicPUB

2 miles W of VERNONIA, OR, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
45° 51' 08"N 123° 14' 34"W
Elevation
650' MSL
Pattern Alt
1650' MSL
Mag Variation
15°E
Declination
20°E
Fuel
None Listed
FSS
MC MINNVILLE (MMV)
Sectional
SEATTLE
ARTCC
SEATTLE (ZSE)
Data Effective
9/3/26-10/1/26
KSPB (17nm) MVFR
8:36 PM PDT
Overcast 7,000'
Broken 2,400'
10sm
61°F
58°F
30.06"Hg
Calm
AO2 T01610144 $
SPECI KSPB 070336Z AUTO 00000KT 10SM BKN024 OVC070 16/14 A3006 RMK AO2 T01610144 $
+ Add Your Business

05S FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

KHIO (22nm)
Sun, 9/6 6:16 PM PDT
Sun, 9/6 6:00 PM PDT - Mon, 9/7 5:00 PM PDT
IFR
Temporary 6:00 PM PDT - 8:00 PM PDT
Rain and Mist
Broken 1,500'
2sm
Calm
VFR
6:00 PM PDT - 8:00 PM PDT
Broken 8,000'
Scattered 1,500'
6sm
VRB° 6kts
VFR
8:00 PM PDT - 6:00 AM PDT
Broken 6,000'
Scattered 3,500'
6sm
VRB° 3kts
MVFR
6:00 AM PDT - 1:00 PM PDT
Overcast 3,500'
Broken 2,500'
Scattered 1,500'
6sm
VRB° 1kts
VFR
1:00 PM PDT - 5:00 PM PDT
Overcast 4,500'
Scattered 2,500'
6sm
VRB° 4kts
TAF KHIO 070116Z 0701/0724 VRB06KT P6SM SCT015 BKN080
   TEMPO 0701/0703 2SM RA BR BKN015
   FM070300 VRB03KT P6SM SCT035 BKN060
   FM071300 VRB01KT P6SM SCT015 BKN025 OVC035
   FM072000 VRB04KT P6SM SCT025 OVC045
05S
EffectiveExpiresCategoryNOTAM
Domestic
9/3/26
1243Z
1/1/27
1243Z
!MMV 09/017 05S OBST TOWER LGT (ASR 1216214) 455122.00N1233343.10W (13.2NM W 05S) 1169.9FT (187.0FT AGL) U/S 2609031243-2701011243
No
UNATNDD
CITY OF VERNONIA
1001 BRIDGE AVE
VERNONIA, OR 97064
Phone: 503-429-5291
MICHAEL SEAGER
536 1ST AVE.
VERNONIA, OR 97064
Phone: 503-709-4075
MC MINNVILLE FSS (MMV)
Toll Free: 1-800-WX-BRIEF
MMV
--
--
N/A
No
No
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
None

Runway 09/27

2940 ft. x 45 ft.
TURF
Good
NONE


--
--
--
--
  Runway 09 Runway 27
True Heading 116°296°
Traffic Pattern Right Left
Markings NONE NONE
Markings Condition
Latitude 45° 51' 14"N 45° 51' 01"N
Longitude 123° 14' 53"W 123° 14' 16"W
Elevation 647' 650'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1HANGARS 100 FT RIGHT OF CNTRLN ON AER 27.
A110-2RY 27 HAS MULTIPLE OBSTRUCTIONS WITHIN 1000 FT E. CURVED APCH FM THE SOUTHEAST RECOMMENDED.
A110-3RY 09 4FT FENCE AT RY END MARKED BY ORANGE PYLONS.
A110-4RY 27 10 FT ROAD 10 FT FROM RY END.
A110-5DEER AND ELK ON AND IN VICINITY OF AIRPORT
A110-6FOR CD CTC PORTLAND APCH AT 503-493-7545.
A42-09_MARKRWY EDGE MKD WITH W MATS.
A42-27_MARKRWY EDGE MKD WITH W MATS.
A50-09BEYOND FENCE, OBSTRUCTION CLEARANCE SLOPE IS 9:1.
E111EXISTED PRIOR TO 1959.
VERNONIA MUNI (IATA: 05S) is a public airport located in VERNONIA, OR, US.
