12A
Local 12A
ARKAVALLEY
PublicPUB

5 miles SE of GREENBRIER, AR, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
35° 10' 39"N 92° 20' 06"W
Elevation
329' MSL
Pattern Alt
1329' MSL
Mag Variation
0°
Declination
2°E
Fuel
None Listed
FSS
JONESBORO (JBR)
Sectional
MEMPHIS
ARTCC
MEMPHIS (ZME)
Data Effective
9/3/26-10/1/26
KCXW (14nm) VFR
7:50 AM CDT
Clear
10sm
68°F
66°F
30.04"Hg
Calm
A01
METAR KCXW 271250Z AUTO 00000KT 10SM CLR 20/19 A3004 RMK A01
+ Add Your Business

12A FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.8
ACTVT MIRL RY 18/36 - CTAF.
UNICOM 122.8

FAA A/FD Pages

Terminal Area Forecast

KLRF (18nm)
Sun, 9/27 7:10 AM CDT
Sun, 9/27 7:00 AM CDT - Mon, 9/28 8:00 AM CDT
VFR
7:00 AM CDT - 9:00 AM CDT
Broken 11,000'
Scattered 7,000'
6sm
29.97"Hg
VRB° 6kts
MVFR
Becoming 9:00 AM CDT - 2:00 PM CDT
Light Showers and Rain
Overcast 8,000'
Broken 5,000'
Scattered 3,500'
3.73sm
29.88"Hg
320° 8kts
VFR
Becoming 2:00 PM CDT - 9:00 PM CDT
Broken 12,000'
6sm
29.91"Hg
050° 6kts
VFR
Becoming 9:00 PM CDT - 1:00 AM CDT
Broken 7,000'
6sm
29.94"Hg
VRB° 6kts
VFR
Becoming 1:00 AM CDT - 8:00 AM CDT
Broken 9,000'
6sm
30.00"Hg
060° 9kts
TAF AMD KLRF 271210Z 2712/2813 VRB06KT 9999 SCT070 BKN110 QNH2997INS
   BECMG 2714/2715 32008KT 6000 -SHRA SCT035 BKN050 OVC080 QNH2989INS
   BECMG 2719/2719 05006KT 9999 NSW BKN120 QNH2990INS
   BECMG 2802/2803 VRB06KT 9999 BKN070 QNH2995INS
   BECMG 2806/2807 06009KT 9999 BKN090 QNH3000INS TX32/2722Z TN17/2713Z
12A
EffectiveExpiresCategoryNOTAM
Domestic
9/14/26
1632Z
11/14/26
1226Z
!JBR 09/205 12A OBST TOWER LGT (ASR 1319315) 351133.90N0922543.65W (4.7NM W 12A) 719FT (290FT AGL) U/S 2609141632-2611141226
8/17/26
2111Z
11/15/26
2211Z
!JBR 08/203 12A OBST TOWER LGT (ASR 1228702) 350639.40N0920510.10W (12.9NM ESE 12A) 552.8FT (259.8FT AGL) U/S 2608172111-2611152211
7/21/26
1933Z
10/19/26
1933Z
!JBR 07/299 12A OBST TOWER LGT (ASR 1275784) 350547.40N0922505.50W (6.4NM SW 12A) 453.1FT (149.9FT AGL) U/S 2607211933-2610191933
No
UNATNDD
ARKAVALLEY AIRPORT PROP. OWN. ASSO
39 DOWNWIND AVENUE
GREENBRIER, AR 72058
Phone: 501-470-5444
BILL HOOTEN
52 CESSNA AVE.
GREENBRIER, AR 72058
Phone: 501-514-0204
JONESBORO FSS (JBR)
Toll Free: 1-800-WX-BRIEF
JBR
--
ACTVT MIRL RY 18/36 - CTAF.
N/A
Yes
No
No
Hanger, Tie-Down
No
None
None
None
None
None

Runway 18/36

3133 ft. x 40 ft.
ASPH
Good
NONE
MED

--
--
--
--
  Runway 18 Runway 36
True Heading 181°1°
Traffic Pattern
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 35° 10' 55"N 35° 10' 24"N
Longitude 92° 20' 06"W 92° 20' 07"W
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1RISING TERRAIN NORTH END.
A110-2FOR CD CTC LITTLE ROCK APCH 501-379-2908 OR LITTLE ROCK ATCT 501-379-2911.
A58-364 FT FENCE 100 FT FM THLD 50 FT L&R.
A75-HCONTACT WAYNE JAQUES 501 681 4858
A81-APTACTVT MIRL RY 18/36 - CTAF.
E111PRVDD CLEAR 20:1 APCH FOR 5000 FT; CLEAR PRIMARY SURFACE; SUBMIT FORM 7460-1 FOR ANY FUTURE CONSTRUCTION.
ARKAVALLEY (IATA: 12A) is a public airport located in GREENBRIER, AR, US.
