iFlightPlanner



...
PLATTE VALLEY AIRPARK - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

18V
Local 18V
PLATTE VALLEY AIRPARK
PublicPUB

3 miles NW of HUDSON, CO, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
40° 06' 10"N 104° 42' 04"W
Elevation
4965' MSL
Pattern Alt
5965' MSL
Mag Variation
8°E
Declination
11°E
Fuel
100LL
FSS
DENVER (DEN)
Sectional
CHEYENNE
ARTCC
DENVER (ZDV)
Data Effective
10/1/26-10/29/26
KDEN (16nm) VFR
12:53 AM MDT
Clear
10sm
41°F
25°F
30.50"Hg
230° 9kts
AO2 SLP309 T00501039 401391022
METAR KDEN 170653Z 23009KT 10SM CLR 05/M04 A3050 RMK AO2 SLP309 T00501039 401391022
+ Add Your Business

18V FBOs

Promote Listing
Platte Valley Airpark
UNICOM: 122.9
Phone: (720) 914-3854
No Rating Available
0 Reviews (Read | Sign In To Write)
Phillips 66
As of 10/13
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 6.89
Full Serve
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9
CODE FOR FBO - CTAF.

FAA A/FD Pages

Terminal Area Forecast

KDEN (16nm)
Fri, 10/16 11:32 PM MDT
Sat, 10/17 12:00 AM MDT - Sun, 10/18 6:00 AM MDT
VFR
12:00 AM MDT - 11:00 AM MDT
Sky Clear
6sm
210° 9kts
VFR
11:00 AM MDT - 1:00 PM MDT
Sky Clear
6sm
VRB° 6kts
VFR
1:00 PM MDT - 8:00 PM MDT
Sky Clear
6sm
130° 7kts
VFR
8:00 PM MDT - 6:00 AM MDT
Few 22,000'
6sm
210° 8kts
TAF KDEN 170532Z 1706/1812 21009KT P6SM SKC
   FM171700 VRB06KT P6SM SKC
   FM171900 13007KT P6SM SKC
   FM180200 21008KT P6SM FEW220
18V
EffectiveExpiresCategoryNOTAM
Domestic
9/4/26
1827Z
11/6/26
2359Z
!DEN 09/127 18V OBST TOWER LGT (ASR 1052975) 400425.10N1041703.40W (19.2NM E 18V) 5188.0FT (249.0FT AGL) U/S 2609041827-2611062359
8/20/26
1807Z
11/20/26
2359Z
Runway!DEN 08/569 18V RWY 15/33 REDL U/S 2608201807-2611202359
No
SR-SS

18V MANAGEMENT
7507 WELD COUNTY RD 39
FORT LUPTON, CO 80621
Phone: 720-914-3854
ERIN SHOFFIT
7507 CO RD 39
FORT LUPTON, CO 80621
Phone: 720-914-3854
DENVER FSS (DEN)
Toll Free: 1-800-WX-BRIEF
DEN
--
--
N/A
Yes
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Minor
Minor
None
None
Pilot Instruction

Runway 09/27

2500 ft. x 90 ft.
TURF GRVL
Fair
NONE


--
--
--
--
  Runway 09 Runway 27
True Heading 105°285°
Traffic Pattern
Markings
Markings Condition
Latitude 40° 06' 31"N 40° 06' 25"N
Longitude 104° 42' 22"W 104° 41' 51"W
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 15/33

4100 ft. x 40 ft.
ASPH
Poor
NONE


--
--
--
--
  Runway 15 Runway 33
True Heading 165°345°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 40° 06' 18"N 40° 05' 39"N
Longitude 104° 42' 10"W 104° 41' 57"W
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1DIRT TWY SOFT WHEN WET.
A110-10POLE APPROX 221 FT FM RY 15 APCH END, 1 FT ABV RY END PRODUCES 21:1 CLNC SLOPE.
A110-1133 FT TREE APPROX 48 FT RIGHT OF RY EDGE, 200FT WEST OF RY THLD.
A110-12CODE FOR FBO - CTAF.
A110-5TWY INT RWY 09/27 MID FIELD.
A110-8FOR CD CTC DENVER APCH AT 303-342-1916.
A110-9RWY'S UNLGTD; RWY'S MAY NOT BE MNTND IN WINTER, VFY COND PRIOR TO USE.
A30-09/27-3 FT DITCH 45 FT N FULL LEN.
A30A-27+20 FT POLE & +15 FT TANK 185 FT FM THR 90 FT L OF CNTRLN; +30 FT POLE 30 FT FM THR 90 FT L & R OF CNTRLN; +15 FT HNGR 155 FT W OF THR 75 FT N OF CNTRLN.
A33-15/33_CONDCRACKS & UNEVEN.
A57-15RISING GND APPROX 555 FT FM RY APPCH END 16 FT ABV RY END PRODUCES 22:1 CLNC SLOPE.
A70-100LL24 HR CREDIT CARD SVC AVBL.
PLATTE VALLEY AIRPARK (IATA: 18V) is a public airport located in HUDSON, CO, US.
