1E4
Local 1E4
PALO DURO
PublicPUB

3 miles S of AMARILLO, TX, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
35° 08' 37"N 101° 50' 21"W
Elevation
3639' MSL
Pattern Alt
4639' MSL
Mag Variation
6°E
Declination
9°E
Fuel
None Listed
FSS
FORT WORTH (FTW)
Sectional
DALLAS-FT WORTH
ARTCC
ALBUQUERQUE (ZAB)
Data Effective
6/11/26-7/9/26
KAMA (8nm) VFR
3:53 PM CDT
Clear
10sm
97°F
58°F
29.87"Hg
210° 19kts
Gusts 29kts
AO2 PK WND 20030/2043 SLP053 T03610144 58029
METAR KAMA 252053Z 21019G29KT 10SM CLR 36/14 A2987 RMK AO2 PK WND 20030/2043 SLP053 T03610144 58029
+ Add Your Business

1E4 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

KAMA (8nm)
Thu, 6/25 12:20 PM CDT
Thu, 6/25 1:00 PM CDT - Fri, 6/26 1:00 PM CDT
VFR
1:00 PM CDT - 7:00 PM CDT
Sky Clear
6sm
210° 14kts
Gusts 23kts
MVFR
7:00 PM CDT - 11:00 PM CDT
Thunderstorm and Rain and Mist
Overcast 2,500'
4sm
Calm
VFR
7:00 PM CDT - 3:00 AM CDT
Scattered 10,000'
6sm
180° 15kts
Gusts 23kts
VFR
3:00 AM CDT - 5:00 AM CDT
Scattered 25,000'
6sm
210° 9kts
VFR
5:00 AM CDT - 1:00 PM CDT
Scattered 25,000'
6sm
330° 9kts
TAF KAMA 251720Z 2518/2618 21014G23KT P6SM SKC
   FM260000 18015G23KT P6SM SCT100
   PROB30 2600/2604 4SM TSRA BR OVC025CB
   FM260800 21009KT P6SM SCT250
   FM261000 33009KT P6SM SCT250
1E4
EffectiveExpiresCategoryNOTAM
Domestic
6/5/26
2129Z
9/5/26
2359Z
!FTW 06/149 1E4 OBST TOWER LGT (ASR 1063987) 350722.00N1014812.00W (2.2NM SE 1E4) 3974.1FT (367.1FT AGL) U/S 2606052129-2609052359
No
UNATNDD
DONALD CONLEY
PO BOX 32811
AMARILLO, TX 79120
Phone: 806-376-5853
DONALD CONLEY
PO BOX 32811
AMARILLO, TX 79120
Phone: 806-376-5853
FORT WORTH FSS (FTW)
Toll Free: 1-800-WX-BRIEF
FTW
--
--
N/A
Yes
No
No
None
No
None
None
None
None
None

Runway 17/35

3700 ft. x 50 ft.
TURF GRVL
Poor
NONE


--
--
--
--
  Runway 17 Runway 35
True Heading 181°0°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 35° 08' 56"N 35° 08' 19"N
Longitude 101° 50' 21"W 101° 50' 21"W
Elevation 3,639' 3,622'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1ARPT HAZARDOUS FOR TSNTS; RWY NOT MKD OR DEFINED; 63 FT MKD/LGTD TRANSMISSION LINE ACRS RWY 17 END.
A110-2FOR CD CTC ALBUQUERQUE ARTCC AT 505-856-4861.
A110-3ARPT FENCED, GATES LOCKED, NO ACES.
A110-4RWY NOT SUITABLE FOR ACFT.
A33-17/35_SURFSOFT WHEN WET ON S END; LOOSE GRVL ON RWY, VEGETATION ON RWY.
PALO DURO (IATA: 1E4) is a public airport located in AMARILLO, TX, US.
