PLATEAU SKY RANCH - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

1F2
Local 1F2
PLATEAU SKY RANCH
PublicPUB

1 miles NW of EDINBURG, NY, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
43° 13' 32"N 74° 06' 52"W
Elevation
1070' MSL
Pattern Alt
2070' MSL
Mag Variation
13°W
Declination
14°W
Fuel
None Listed
FSS
BURLINGTON (BTV)
Sectional
NEW YORK
ARTCC
BOSTON (ZBW)
Data Effective
2/19/26-3/19/26
KNY0 (17nm) IFR
1:35 PM EST
Overcast 2,300'
Scattered 1,400'
Scattered 700'
1.25sm
29°F
25°F
30.02"Hg
090° 6kts
AO2 T10161038
METAR KNY0 221835Z AUTO 09006KT 1 1/4SM SCT007 SCT014 OVC023 M02/M04 A3002 RMK AO2 T10161038
+ Add Your Business

1F2 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.8
UNICOM 122.8

FAA A/FD Pages

Terminal Area Forecast

KGFL (23nm)
Sun, 2/22 12:20 PM EST
Sun, 2/22 1:00 PM EST - Mon, 2/23 1:00 PM EST
VFR
1:00 PM EST - 5:00 PM EST
Showers in vicinity
Overcast 3,500'
Scattered 1,200'
6sm
070° 6kts
VFR
5:00 PM EST - 10:00 PM EST
Overcast 4,000'
Scattered 2,500'
6sm
050° 7kts
VFR
10:00 PM EST - 3:00 AM EST
Overcast 6,000'
Scattered 3,000'
6sm
030° 5kts
MVFR
12:00 AM EST - 3:00 AM EST
Light Snow and Mist
Broken 2,500'
4sm
Calm
IFR
3:00 AM EST - 1:00 PM EST
Light Snow and Mist
Overcast 2,500'
Scattered 1,500'
2sm
010° 11kts
Gusts 20kts
TAF KGFL 221720Z 2218/2318 07006KT P6SM VCSH SCT012 OVC035
   FM222200 05007KT P6SM SCT025 OVC040
   FM230300 03005KT P6SM SCT030 OVC060
   PROB30 2305/2308 4SM -SN BR BKN025
   FM230800 01011G20KT 2SM -SN BR SCT015 OVC025 WS020/02035KT
1F2
No NOTAM Available
No
UNATNDD
ELAYNE WADE
23 WHEELER RD
EDINBURG, NY 12134
Phone: 518-775-7431
MR BILL DEE WADE
23 WHEELER RD
EDINBURG, NY 12134
Phone: 518-863-2725
BURLINGTON FSS (BTV)
Toll Free: 1-800-WX-BRIEF
BTV
--
--
N/A
Yes
Yes
No
Tie-Down
No
None
None
None
None
Pilot Instruction

Runway 01/19

2000 ft. x 100 ft.
TURF
Good
NONE


--
--
--
--
  Runway 01 Runway 19
True Heading 1°181°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 43° 13' 22"N 43° 13' 42"N
Longitude 74° 06' 54"W 74° 06' 53"W
Elevation 1,048' 1,067'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 06/24

2400 ft. x 100 ft.
TURF
Good
NONE


--
--
--
--
  Runway 06 Runway 24
True Heading 47°227°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 43° 13' 24"N 43° 13' 40"N
Longitude 74° 07' 02"W 74° 06' 39"W
Elevation 1,047' 1,060'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1ULTRALGT ACFT ON & INVOF ARPT.
A110-104 FT GRAVEL PILE AT END OF RWY 01.
A110-3ACFT PARKED/HANGARED ON NON ARPT LAND. CROSS PUBLIC ROAD TO/FM ARPT.
A110-4RWY 24; +35 - 50 FT TREES, 90 - 250 FT FROM THLD, 0 - 125 FT R OF CNTRLN AND +50 FT TREES, 350 - 425 FT FROM THLD 110 - 150 FT L OF CNTRLN.
A110-5RWY 19; +17 - 52 FT TREES, 0 - 230 FT FROM THLD, 50 - 100 FT R OF CNTRLN.
A110-6RWY 1; +30 - 60 FT TREES, 0 - 240 FROM THLD, 15 - 100 FT L AND R OF CNTRLN.
A110-7RWY 6; +20 - 65 FT TREES, 0 - 500 FT FROM THLD, 30 - 150 L AND R OF CNTRLN.
A110-8FOR CD CTC ALBANY APCH AT 518-862-2299.
A110-9ARPT NOT PLOWED OR MNTND DURG WINTER MONTHS; RWY SFC CAN BE SOFT AS FROST LEAVES THE GND IN SPRING.
A32-01/19RWY WIDTH EDGE MARKED WITH RED CONES ALL SEASONS EXCEPT WINTER
A32-06/24RWY WIDTH EDGE MARKED WITH RED CONES ALL SEASONS EXCEPT WINTER
A52-01ROAD ON BOTH SIDES OF CTRLN RY 01.
A52-06ROAD ON BOTH SIDES OF CTRLN AT AN ANGLE TO RY 06.
A52-19ROAD ON BOTH SIDES OF CTRLN AT AN ANGLE TO RY 19.
A52-24ROAD ON BOTH SIDES OF CTRLN RY 24.
A57-06CTLNG OBSTN EXCEEDS 45 DEG SLP.
E111ESTABD PRIOR TO 1959
PLATEAU SKY RANCH (IATA: 1F2) is a public airport located in EDINBURG, NY, US.
