KENT COUNTY - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

22F
Local 22F
KENT COUNTY
PublicPUB

1 miles S of JAYTON, TX, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
33° 13' 45"N 100° 34' 09"W
Elevation
2008' MSL
Pattern Alt
3008' MSL
Mag Variation
5°E
Declination
8°E
Fuel
None Listed
FSS
FORT WORTH (FTW)
Sectional
DALLAS-FT WORTH
ARTCC
FORT WORTH (ZFW)
Data Effective
9/3/26-10/1/26
KSNK (38nm) VFR
7:15 AM CDT
Clear
10sm
68°F
67°F
30.01"Hg
230° 4kts
AO2 T02000195
METAR KSNK 271215Z AUTO 23004KT 10SM CLR 20/20 A3001 RMK AO2 T02000195
+ Add Your Business

22F FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

KABI (66nm)
Sun, 9/27 6:20 AM CDT
Sun, 9/27 7:00 AM CDT - Mon, 9/28 7:00 AM CDT
VFR
7:00 AM CDT - 9:00 AM CDT
Broken 25,000'
Scattered 10,000'
6sm
170° 7kts
VFR
9:00 AM CDT - 1:00 PM CDT
Scattered 25,000'
6sm
240° 10kts
Gusts 16kts
VFR
1:00 PM CDT - 6:00 PM CDT
Scattered 25,000'
Scattered 7,000'
6sm
270° 9kts
VFR
6:00 PM CDT - 7:00 AM CDT
Few 25,000'
6sm
120° 7kts
TAF KABI 271120Z 2712/2812 17007KT P6SM SCT100 BKN250
   FM271400 24010G16KT P6SM SCT250
   FM271800 27009KT P6SM SCT070 SCT250
   FM272300 12007KT P6SM FEW250
22F
EffectiveExpiresCategoryNOTAM
Domestic
7/6/26
2343Z
10/6/26
2359Z
!FTW 07/203 22F OBST WIND TURBINE LGT (ASN 2019-WTW-5169-OE) 330333N1002956W (10.7NM SSE 22F) 2572FT (499FT AGL) U/S 2607062343-2610062359
No
UNATNDD
KENT COUNTY
PO BOX 6
JAYTON, TX 79528
Phone: 806-237-3373
JIM WHITE
P.O. BOX 6
JAYTON, TX 79528
Phone: 806-237-3373
FORT WORTH FSS (FTW)
Toll Free: 1-800-WX-BRIEF
FTW
Sunset to Sunrise
--
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
None

Runway 17/35

3300 ft. x 50 ft.
ASPH
Good
NONE
LOW

12,000lbs
--
--
--
  Runway 17 Runway 35
True Heading 181°1°
Traffic Pattern
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 33° 14' 01"N 33° 13' 28"N
Longitude 100° 34' 08"W 100° 34' 09"W
Elevation 2,008' 1,987'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1AGRICULTURAL ACTIVITY ON ARPT MAY-SEPT.
A110-2FOR CD CTC FORT WORTH ARTCC AT 817-858-7584.
A16EMERG CTC PHONE: 806-237-3801 (SHERIFF OFFICE)
KENT COUNTY (IATA: 22F) is a public airport located in JAYTON, TX, US.
