LAKE WENATCHEE STATE - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

27W
LAKE WENATCHEE STATE
PublicPUB

14 miles NW of LEAVENWORTH, WA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
47° 49' 10"N 120° 43' 12"W
1939' MSL
2939' MSL
20E
None Listed
SEATTLE (SEA)
SEATTLE
SEATTLE (ZSE)
4/18/24-5/16/24
KEAT (33nm) VFR
3:55 AM PDT
Few 12,000'
10sm
45°F
36°F
29.87"Hg
Calm
AO2 SLP115 T00720022 $
KEAT 251055Z AUTO 00000KT 10SM FEW120 07/02 A2987 RMK AO2 SLP115 T00720022 $
List Your Business

27W FBOs, Flight Schools and Ground Support

No FBOs, flight schools or aircraft ground support businesses are listed for this airport.

27W Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

27W Hotels

No hotels are listed for this airport.

27W Restaurants

No restaurants are listed for this airport.

27W Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KEAT (33nm)
Wed, 4/24 10:20 PM PDT
Wed, 4/24 11:00 PM PDT - Thu, 4/25 11:00 PM PDT
VFR
11:00 PM PDT - 12:00 PM PDT
Broken 10,000'
6sm
300° 11kts
VFR
12:00 PM PDT - 6:00 PM PDT
Overcast 5,000'
Scattered 3,000'
6sm
140° 8kts
MVFR
12:00 PM PDT - 6:00 PM PDT
Light Rain
Overcast 3,000'
5sm
Calm
VFR
6:00 PM PDT - 11:00 PM PDT
Overcast 9,000'
Broken 4,000'
6sm
320° 8kts
KEAT 250520Z 2506/2606 30011KT P6SM BKN100
   FM251900 14008KT P6SM SCT030 OVC050
   PROB30 2519/2601 5SM -RA OVC030
   FM260100 32008KT P6SM BKN040 OVC090
27W
Domestic
4/19/242252Z !SEA 04/238 27W AD AP OPN 2404192252-2406012359
No
UNATNDD
WSDOT AVIATION DIVISION
7702 TERMINAL STREET SW
TUMWATER, WA 98501-7264
Phone: (800) 552-0666
G. PAUL WOLF
7702 TERMINAL STREET SW
TUMWATER, WA 98501-7264
Phone: (360) 618-2477
SEATTLE FSS (SEA)
Toll Free: 1-800-WX-BRIEF
SEA
--
--
N/A
Yes
No
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 09/27

2473 ft. x 100 ft.
TURF
Fair
NONE


--
--
--
--
  Runway 09 Runway 27
True Heading 109°289°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 47° 49' 14"N 47° 49' 06"N
Longitude 120° 43' 29"W 120° 42' 55"W
Elevation 1,936' 1,927'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1ARPT CLSD 1 OCT-1 JUN.
A110-2DENSITY ALTITUDE.
A110-3PEDESTRIANS; VEHICLES AND ANIMALS ON & INVOF RY.
A110-4CTC WA STATE AVIATION DIVISION 360-709-8015 OR 1-800-552-0666 WA AREA FOR FACILITY INFO PRIOR TO USE.
A110-5RY MARKED WITH REFLECTORS DURING DATES AIRPORT IS OPEN.
A110-6FOR ACFT ACCIDENTS/INCIDENTS CTC WA STATE EMERGENCY OPERATIONS CENTER 800-258-5990.
A110-7FOR CD CTC SEATTLE ARTCC AT 253-351-3694.
LAKE WENATCHEE STATE (IATA: 27W) is a public airport located in LEAVENWORTH, WA.
