BANNOCK - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

2D6
Local 2D6
BANNOCK
PublicPUB

0 miles N of BANNOCK, OH, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
40° 06' 25"N 80° 58' 31"W
Elevation
1100' MSL
Pattern Alt
2100' MSL
Mag Variation
9°W
Declination
7°W
Fuel
None Listed
FSS
CLEVELAND (CLE)
Sectional
DETROIT
ARTCC
CLEVELAND (ZOB)
Data Effective
3/19/26-4/16/26
KHLG (16nm) VFR
9:53 PM EDT
Few 12,000'
10sm
74°F
54°F
29.87"Hg
230° 10kts
AO2 SLP108 T02330122
METAR KHLG 050153Z AUTO 23010KT 10SM FEW120 23/12 A2987 RMK AO2 SLP108 T02330122
+ Add Your Business

2D6 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

Center

CLEVELAND CENTER 126.95
LOW, APCH/DEP SVC PRVDD BY CLEVELAND ARTCC (ZOB) 126.95/239.3 (BELMONT RCAG).

FAA A/FD Pages

Terminal Area Forecast

KHLG (16nm)
Sat, 4/4 9:32 PM EDT
Sat, 4/4 10:00 PM EDT - Sun, 4/5 8:00 PM EDT
VFR
10:00 PM EDT - 12:00 AM EDT
Overcast 20,000'
Scattered 10,000'
6sm
230° 12kts
Gusts 22kts
MVFR
Temporary 12:00 AM EDT - 2:00 AM EDT
Light Showers and Rain
No Clouds
5sm
Calm
VFR
12:00 AM EDT - 2:00 AM EDT
Light Showers and Rain
Overcast 4,000'
6sm
220° 10kts
Gusts 20kts
MVFR
2:00 AM EDT - 8:00 AM EDT
Light Showers and Rain
Overcast 1,500'
6sm
250° 12kts
Gusts 22kts
MVFR
8:00 AM EDT - 1:00 PM EDT
Broken 2,000'
6sm
270° 10kts
Gusts 20kts
VFR
1:00 PM EDT - 8:00 PM EDT
Broken 3,500'
6sm
270° 12kts
Gusts 22kts
TAF KHLG 050132Z 0502/0524 23012G22KT P6SM SCT100 OVC200
   FM050400 22010G20KT 6SM -SHRA OVC040
   TEMPO 0504/0506 5SM -SHRA
   FM050600 25012G22KT 6SM -SHRA OVC015
   FM051200 27010G20KT P6SM BKN020
   FM051700 27012G22KT P6SM BKN035
2D6
No NOTAM Available
No
MON-FRI 0800-1600
OHIO RIVER COLLIERIES CO
70245 BANNOCK-UNIONTOWN RD
SAINT CLAIRSVILLE, OH 43950
Phone: 740-391-5925
MARK WESTLAKE
70245 BANNOCK-UNIONTOWN RD
SAINT CLAIRSVILLE, OH 43950
Phone: 740-391-5925
CLEVELAND FSS (CLE)
Toll Free: 1-800-WX-BRIEF
CLE
--
--
N/A
No
No
No
None
No
None
None
None
None
None

Runway H1

20 ft. x 20 ft.
CONC
Fair
NONE


--
--
--
--
  Runway H1 Runway
True Heading Not ListedNot Listed
Traffic Pattern
Markings
Markings Condition GOOD
Latitude 40° 06' 25"N N/A
Longitude 80° 58' 31"W N/A
Elevation 1,100' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-2FOR CD CTC CLEVELAND ARTCC AT 440-774-0226/0490.
A52-H136 FT POLES, 66 FT NW; 35 FT PLINE, 240 FT NW.
E111PRVDD INGRESS/EGRESS 195-190 DEGS CLKWS USING PAD AS CNTR OF A COMPASS ROSE.
BANNOCK (IATA: 2D6) is a public heliport located in BANNOCK, OH, US.
