5/9/26 0847Z | 5/9/28 0847Z | | !FDC 6/9098 35A PART 1 OF 3 ODP UNION COUNTY, TROY SHELTON FLD, UNION, SC. TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1... TAKEOFF MINIMUMS: RWY 5: 300-1 3/8 OR STANDARD WITH MINIMUM CLIMB OF 210 FT/NM TO 900. TAKEOFF OBSTACLE NOTES: RWY 5: LIGHT POLES 7 FT FROM DER, 69 FT RIGHT OF CENTERLINE, 4 FT AGL/611 FT MSL. LIGHT POLES 8 FT FROM DER, 69 FT LEFT OF CENTERLINE, 4 FT AGL/611 FT MSL. TREES BEGINNING 15 FT FROM DER, 321 FT LEFT OF CENTERLINE, UP TO 618 FT MSL. TREE 155 FT FROM DER, 493 FT LEFT OF CENTERLINE, 56 FT AGL/629 FT MSL. TREES BEGINNING 249 FT FROM DER, 181 FT LEFT OF CENTERLINE, UP TO 634 FT MSL. TREES BEGINNING 372 FT FROM DER, 267 FT LEFT OF CENTERLINE, UP TO 643 FT MSL. TREE 505 FT FROM DER, 628 FT LEFT OF CENTERLINE, 652 FT MSL. TREE 540 FT FROM DER, 455 FT LEFT OF CENTERLINE, 660 FT MSL. TREES BEGINNING 605 FT FROM DER, 374 FT LEFT OF CENTERLINE, UP TO 672 FT MSL. TREE 738 FT FROM DER, 609 FT LEFT OF CENTERLINE, 675 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED. UNION COUNTY, TROY SHELTON FLD, UNION, SC. VEGETATION 770 FT FROM DER, 473 FT RIGHT OF CENTERLINE, 634 FT MSL. TREES BEGINNING 787 FT FROM DER, 342 FT LEFT OF CENTERLINE, UP TO 690 FT MSL. VEHICLES ON ROAD 804 FT FROM 2605090847-2805090847EST END PART 1 OF 3
!FDC 6/9098 35A PART 2 OF 3 DER, 617 FT RIGHT OF CENTERLINE, 652 FT MSL. TREES, VEGETATION BEGINNING 883 FT FROM DER, 343 FT RIGHT OF CENTERLINE, UP TO 654 FT MSL. TREES, TERRAIN BEGINNING 895 FT FROM DER, 22 FT LEFT OF CENTERLINE, UP TO 698 FT MSL. TREES, TERRAIN, VEGETATION BEGINNING 948 FT FROM DER, 340 FT RIGHT OF CENTERLINE, UP TO 711 FT MSL. TREES, POLE, VEHICLE ON ROAD, TERRAIN BEGINNING 1089 FT FROM DER, 7 FT RIGHT OF CENTERLINE, UP TO 717 FT MSL. TREES, TERRAIN BEGINNING 1269 FT FROM DER, 6 FT RIGHT OF CENTERLINE, UP TO 62 FT AGL/726 FT MSL. TREES, TERRAIN BEGINNING 1332 FT FROM DER, 4 FT RIGHT OF CENTERLINE, UP TO 60 FT AGL/728 FT MSL. TREES, TERRAIN, VEGETATION BEGINNING 1471 FT FROM DER, 86 FT RIGHT OF CENTERLINE, UP TO 731 FT MSL. TREES, POLE:UTILITY BEGINNING 1660 FT FROM DER, 298 FT LEFT OF ALL OTHER DATA REMAINS AS PUBLISHED. UNION COUNTY, TROY SHELTON FLD, UNION, SC. CENTERLINE, UP TO 722 FT MSL. TREES, TERRAIN, VEHICLES ON ROAD, VEGETATION, POLE:UTILITY, BUILDING, ELECTRICAL SYSTEM BEGINNING 1685 FT FROM DER, 178 FT RIGHT OF CENTERLINE, UP TO 83 FT AGL/737 FT MSL. TREE, TRANSMISSION LINES BEGINNING 2403 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP TO 731 FT MSL. TRANSMISSION LINE, ELECTRICAL 2605090847-2805090847EST END PART 2 OF 3
!FDC 6/9098 35A PART 3 OF 3 SYSTEM, TREES BEGINNING 2845 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO 110 FT AGL/738 FT MSL. TANK 1.1 NM FROM DER, 631 FT LEFT OF CENTERLINE, 203 FT AGL/786 FT MSL. RWY 23: TREE 3 FT FROM DER, 122 FT LEFT OF CENTERLINE, 17 FT AGL/583 FT MSL. TREES BEGINNING 41 FT FROM DER, 105 FT RIGHT OF CENTERLINE, UP TO 585 FT MSL. TREE 62 FT FROM DER, 515 FT LEFT OF CENTERLINE, 619 FT MSL. TREES BEGINNING 110 FT FROM DER, 394 FT LEFT OF CENTERLINE, UP TO 92 FT AGL/623 FT MSL. TREES BEGINNING 773 FT FROM DER, 418 FT LEFT OF CENTERLINE, UP TO 626 FT MSL. TREES BEGINNING 1489 FT FROM DER, 665 FT LEFT OF CENTERLINE, UP TO 642 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED. UNION COUNTY, TROY SHELTON FLD, UNION, SC. TREES BEGINNING 1596 FT FROM DER, 682 FT LEFT OF CENTERLINE, UP TO 657 FT MSL. TREE 1684 FT FROM DER, 926 FT RIGHT OF CENTERLINE, 626 FT MSL. TREE 1781 FT FROM DER, 863 FT RIGHT OF CENTERLINE, 71 FT AGL/631 FT MSL. TREES BEGINNING 1789 FT FROM DER, 802 FT LEFT OF CENTERLINE, UP TO 658 FT MSL. TREES BEGINNING 1894 FT FROM DER, 720 FT LEFT OF CENTERLINE, UP TO 670 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED. 2605090847-2805090847EST END PART 3 OF 3
|
