1/12/26 1746Z | | | !FDC 6/2458 3K3 PART 1 OF 3 ODP SYRACUSE-HAMILTON COUNTY MUNI,
SYRACUSE, KS.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
RWY 13: TREES BEGINNING 2 FT FROM DER, 11 FT LEFT OF CENTERLINE, UP
TO 40 FT AGL/3344 FT MSL.
TREES BEGINNING 92 FT FROM DER, 32 FT RIGHT OF CENTERLINE, UP TO 40
FT AGL/3341 FT MSL.
TOWER 1.4 NM FROM DER, 668 FT LEFT OF CENTERLINE, 303 FT AGL/3533
FT MSL.
RWY 18: TREES BEGINNING 128 FT FROM DER, 18 FT LEFT OF CENTERLINE,
UP TO 40 FT AGL/3357 FT MSL.
TREES, ELEVATOR BEGINNING 249 FT FROM DER, 64 FT RIGHT OF
CENTERLINE, UP TO 40 FT AGL/3354 FT MSL.
TANK 1898 FT FROM DER, 393 FT LEFT OF CENTERLINE, 99 FT AGL/3399 FT
MSL.
RWY 31: TREES BEGINNING 28 FT FROM DER, 117 FT RIGHT OF CENTERLINE,
UP TO 40 FT AGL/3357 FT MSL.
TREES 108 FT FROM DER, 481 FT LEFT OF CENTERLINE, 40 FT AGL/3351 FT
MSL.
TREES BEGINNING 152 FT FROM DER, 7 FT LEFT OF CENTERLINE, UP TO 40
FT AGL/3354 FT MSL.
1A. 2601121746-PERM
END PART 1 OF 3
!FDC 6/2458 3K3 PART 2 OF 3 ODP SYRACUSE-HAMILTON COUNTY MUNI,
SYRACUSE, KS.
RWY 36: TREES 57 FT FROM DER, 328 FT LEFT OF CENTERLINE, 40 FT
AGL/3341 FT MSL.
TREES BEGINNING 98 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP TO 40
FT AGL/3364 FT MSL.
TREES BEGINNING 138 FT FROM DER, 42 FT RIGHT OF CENTERLINE, UP TO
40 FT AGL/3364 FT MSL.
TREES BEGINNING 818 FT FROM DER, 227 FT RIGHT OF CENTERLINE, UP TO
40 FT AGL/3367 FT MSL.
TREES BEGINNING 1157 FT FROM DER, 176 FT RIGHT OF CENTERLINE, UP TO
40 FT AGL/3371 FT MSL.
VERTICALSTRUCTURE, TRANSMISSION LINE TOWER BEGINNING 1596 FT FROM
DER, 127 FT LEFT OF CENTERLINE, UP TO 52 FT AGL/3367 FT
MSL.
TREES BEGINNING 1756 FT FROM DER, 310 FT RIGHT OF CENTERLINE, UP TO
40 FT AGL/3377 FT MSL.
TREES 2055 FT FROM DER, 547 FT RIGHT OF CENTERLINE, 40 FT AGL/3384
FT MSL.
TREES BEGINNING 2095 FT FROM DER, 783 FT RIGHT OF CENTERLINE, UP TO
40 FT AGL/3387 FT MSL.
TREES 2394 FT FROM DER, 732 FT RIGHT OF CENTERLINE, 40 FT AGL/3390
1A. 2601121746-PERM
END PART 2 OF 3
!FDC 6/2458 3K3 PART 3 OF 3 ODP SYRACUSE-HAMILTON COUNTY MUNI,
SYRACUSE, KS.
FT MSL.
TREES 2435 FT FROM DER, 969 FT RIGHT OF CENTERLINE, 40 FT AGL/3394
FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED.
THIS IS TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES, AMDT
1A. 2601121746-PERM
END PART 3 OF 3
|
