SIMSBURY - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

4B9
Local 4B9
SIMSBURY
PublicPUB

3 miles NE of SIMSBURY, CT, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
41° 54' 58"N 72° 46' 37"W
Elevation
195' MSL
Pattern Alt
1195' MSL
Mag Variation
13°W
Declination
14°W
Fuel
100LL
FSS
BRIDGEPORT (BDR)
Sectional
NEW YORK
ARTCC
BOSTON (ZBW)
Data Effective
8/6/26-9/3/26
KBDL (4nm) IFR
10:51 AM EDT
Light Rain and Mist
Overcast 900'
Broken 600'
6sm
67°F
66°F
29.84"Hg
200° 4kts
AO2 SLP105 P0005 60015 T01940189 57002 $
METAR KBDL 231451Z 20004KT 6SM -RA BR BKN006 OVC009 19/19 A2984 RMK AO2 SLP105 P0005 60015 T01940189 57002 $
+ Add Your Business

4B9 FBOs

Promote Listing
Simsbury Airport
UNICOM: 122.7
Phone: (860) 459-1575
No Rating Available
1 Review (Read | Sign In To Write)
1 out of 1 Recommend
Phillips 66
As of 8/18
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 8.50
Full Serve
Fuel Notes
Prices include tax
Call ahead for availability and pricing of fuel.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.7
DUSK-DAWN. ACTVT MIRL RWY 03/21 - CTAF.
UNICOM 122.7

FAA A/FD Pages

Terminal Area Forecast

KBDL (4nm)
Sun, 8/23 10:00 AM EDT
Sun, 8/23 10:00 AM EDT - Mon, 8/24 2:00 PM EDT
MVFR
10:00 AM EDT - 11:30 AM EDT
Showers and Rain
Broken 1,500'
Scattered 800'
4sm
100° 5kts
MVFR
11:30 AM EDT - 2:00 PM EDT
Broken 1,500'
6sm
090° 5kts
MVFR
2:00 PM EDT - 6:00 PM EDT
Light Thunderstorm and Rain
Overcast 2,500'
4sm
Calm
MVFR
2:00 PM EDT - 6:00 PM EDT
Broken 2,500'
6sm
200° 6kts
VFR
6:00 PM EDT - 11:00 PM EDT
Broken 4,000'
6sm
190° 6kts
VFR
11:00 PM EDT - 2:00 PM EDT
Scattered 6,000'
6sm
210° 4kts
TAF KBDL 231400Z 2314/2418 10005KT 4SM SHRA SCT008 BKN015
   FM231530 09005KT P6SM BKN015
   FM231800 20006KT P6SM BKN025
   PROB30 2318/2322 4SM -TSRA OVC025CB
   FM232200 19006KT P6SM BKN040
   FM240300 21004KT P6SM SCT060
4B9
EffectiveExpiresCategoryNOTAM
Domestic
8/21/26
0253Z
9/5/26
0253Z
!BDR 08/184 4B9 OBST TOWER LGT (ASR 1296711) 415332.80N0724610.30W (1.5NM SSE 4B9) 583.0FT (120.1FT AGL) U/S 2608210253-2609050253
No
0830-1700
AIRPORT REALTY ASSOC. LLC
37 SUNSET FARMS RD
WEST HARTFORD, CT 06107
Phone: 860-236-3301
BRAD GRISWOLD
119 PARK RD
PLEASANT VALLEY, CT 06063
Phone: 860-459-1575
BRIDGEPORT FSS (BDR)
Toll Free: 1-800-WX-BRIEF
BDR
--
DUSK-DAWN. ACTVT MIRL RWY 03/21 - CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
None
Pilot Instruction

Runway 03/21

2205 ft. x 50 ft.
ASPH
Fair
NONE
NSTD

25,000lbs
--
--
--
  Runway 03 Runway 21
True Heading 15°195°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 41° 54' 48"N 41° 55' 09"N
Longitude 72° 46' 41"W 72° 46' 33"W
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1DEER & BIRDS ON & INVOF ARPT - BIRDS PARTICULARLY IN APCH TO RWY 03.
A110-3RWY 03 HAS AN UP-HILL GRADE.
A110-4FOR CD CTC BRADLEY APCH AT 860-386-3597.
A30-03/21RWY 3/21 SAFETY BARRIER 15 FT NE THR BARRICADE NOT LGTD.
A40-03/21NSTD THLD LIGHTS GREEN/GREEN.
A57-21APCH RATIO 21:1 TO DTHR.
A58-0370 FT TREES, 25-50 FT DSTC, 123 FT R.
A58-2140 FT TREES, 0 FT DSTC, 123 FT L.
A81-APTDUSK-DAWN. ACTVT MIRL RWY 03/21 - CTAF.
E111EXISTED PRIOR TO 1959.
SIMSBURY (IATA: 4B9) is a public airport located in SIMSBURY, CT, US.
