4Z5
Local 4Z5
HORSFELD
PublicPUB

28 miles SSE of HORSFELD, AK, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
62° 00' 26"N 141° 10' 56"W
Elevation
3620' MSL
Pattern Alt
4620' MSL
Mag Variation
18°E
Declination
29°E
Fuel
None Listed
FSS
NORTHWAY (ORT)
Sectional
ANCHORAGE
ARTCC
ANCHORAGE (ZAN)
Data Effective
6/11/26-7/9/26
PAOR (61nm) VFR
4:53 AM AKDT
Broken 8,000'
10sm
48°F
41°F
30.09"Hg
310° 4kts
AO2 SLP193 T00890050
METAR PAOR 171253Z 31004KT 10SM BKN080 09/05 A3009 RMK AO2 SLP193 T00890050
+ Add Your Business

4Z5 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

PAOR (61nm)
Wed, 6/17 3:44 AM AKDT
Wed, 6/17 4:00 AM AKDT - Thu, 6/18 4:00 AM AKDT
VFR
4:00 AM AKDT - 10:00 AM AKDT
Scattered 10,000'
6sm
300° 4kts
VFR
10:00 AM AKDT - 4:00 AM AKDT
Showers in vicinity
Broken 8,000'
6sm
330° 10kts
TAF PAOR 171144Z 1712/1812 30004KT P6SM SCT100
   FM171800 33010KT P6SM VCSH BKN080
4Z5
No NOTAM Available
No
UNATNDD
PUBLIC DOMAIN

N/A
NORTHWAY FSS (ORT)
Toll Free: 1-800-478-6611
ORT
--
--
N/A
No
No
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
None

Runway 03/21

900 ft. x 12 ft.
DIRT
Poor
NONE


--
--
--
--
  Runway 03 Runway 21
True Heading Not ListedNot Listed
Traffic Pattern Left Left
Markings NONE NONE
Markings Condition
Latitude N/A N/A
Longitude N/A N/A
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-2LCTD IN BOWL; MT PEAKS IMT VCNTY; EXP UNPREDICTABLE GUSTY WIND.
A30-03/21NARROW ROUGH BRUSH SLOPES DOWN; ENCROACHES ENDS. 4 FT BRUSH ALG EDGES.
A33-03/21_SURFALERT: RUTTED; SLIPPERY MUD HINDERS BA.
A83NSTD; POLE WITH COLORED STREAMERS.
HORSFELD (IATA: 4Z5) is a public airport located in HORSFELD, AK, US.
