| FDC |
|
8/24/231840Z
|
!FDC 3/0921 5G7 IAP BLUFFTON, BLUFFTON, OH.
RNAV (GPS) RWY 23, ORIG-B...
CHANGE CHART NOTE TO READ: USE FINDLAY ALTIMETER SETTING; WHEN NOT RECEIVED USE LIMA ALTIMETER SETTING AND INCREASE ALL MDA 20 FEET AND CIRCLING CAT C/D VISIBILITY 1/4 SM.
2308241840-2508241840EST
|
|
8/24/231833Z
|
!FDC 3/0906 5G7 PART 1 OF 2 ODP BLUFFTON, BLUFFTON, OH.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1A...
CHANGE TAKEOFF OBSTACLE NOTES TO READ: NOTE: RWY 5, VEHICLE ON ROAD
BEGINNING AT DER, 330 FT RIGHT OF CENTERLINE, UP TO 864 FT MSL.
RUNWAY LIGHTS 9 FT FROM DER, 78 FT RIGHT OF CENTERLINE, 3 FT
AGL/848 FT MSL. RUNWAY LIGHTS 10 FT FROM DER, 79 FT LEFT OF
CENTERLINE, 2 FT AGL/848 FT MSL. POLES, TREES BEGINNING 163 FT FROM
DER, 507 FT LEFT OF CENTERLINE, UP TO 42 FT AGL/889 FT MSL. TREES
BEGINNING 1347 FT FROM DER, 594 FT RIGHT OF CENTERLINE, UP TO 889
FT MSL. TREE 1595 FT FROM DER, 446 FT RIGHT OF CENTERLINE, 904 FT
MSL. TREE 1690 FT FROM DER, 869 FT LEFT OF CENTERLINE, 907 FT MSL.
TREE 2369 FT FROM DER, 611 FT RIGHT OF CENTERLINE, 911 FT MSL.
NOTE: RWY 23, TREE 8 FT FROM DER, 215 FT LEFT OF CENTERLINE, 8 FT
AGL/852 FT MSL. RUNWAY LIGHTS 11 FT FROM DER, 77 FT RIGHT OF
CENTERLINE, 4 FT AGL/852 FT MSL. TREE 298 FT FROM DER, 505 FT RIGHT
OF CENTERLINE, 866 FT MSL. TREES BEGINNING 327 FT FROM DER, 511 FT
RIGHT OF CENTERLINE, UP TO 31 FT AGL/876 FT MSL. TREE 406 FT FROM
DER, 369 FT LEFT OF CENTERLINE, 893 FT MSL. TREES BEGINNING 438 FT
FROM DER, 34 FT LEFT OF CENTERLINE, UP TO 68 FT AGL/903 FT MSL.
TREE 1007 FT FROM DER, 344 FT RIGHT OF CENTERLINE, 888 FT MSL. TREE
1115 FT FROM DER, 478 FT RIGHT OF CENTERLINE, 895 FT MSL. TREE 1208
ALL OTHER DATA REMAINS AS PUBLISHED. 2308241833-2508241833EST
END PART 1 OF 2
!FDC 3/0906 5G7 PART 2 OF 2 ODP BLUFFTON, BLUFFTON, OH.
FT FROM DER, 565 FT RIGHT OF CENTERLINE, 897 FT MSL. TRANSMISSION
LINE, TREES BEGINNING 1346 FT FROM DER, 108 FT RIGHT OF CENTERLINE,
UP TO 85 FT AGL/919 FT MSL. TREE 1708 FT FROM DER, 778 FT LEFT OF
CENTERLINE, 904 FT MSL. TREES BEGINNING 2227 FT FROM DER, 281 FT
LEFT OF CENTERLINE, UP TO 932 FT MSL. TREE 2632 FT FROM DER, 1122
FT LEFT OF CENTERLINE, 100 FT AGL/934 FT MSL. TREES BEGINNING 2891
FT FROM DER, 624 FT RIGHT OF CENTERLINE, UP TO 100 FT AGL/944 FT
MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2308241833-2508241833EST
END PART 2 OF 2
|
