8A7
Local 8A7
TWIN LAKES
PublicPUB

5 miles NE of MOCKSVILLE, NC, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
35° 54' 54"N 80° 27' 25"W
Elevation
818' MSL
Pattern Alt
1818' MSL
Mag Variation
8°W
Declination
6°W
Fuel
100LL
FSS
RALEIGH (RDU)
Sectional
CHARLOTTE
ARTCC
ATLANTA (ZTL)
Data Effective
2/19/26-3/19/26
KEXX (11nm) MVFR
11:15 AM EDT
Overcast 9,500'
Broken 3,400'
Broken 2,700'
10sm
61°F
48°F
30.16"Hg
090° 6kts
AO2 T01630090
METAR KEXX 151515Z AUTO 09006KT 10SM BKN027 BKN034 OVC095 16/09 A3016 RMK AO2 T01630090
+ Add Your Business

8A7 FBOs

Promote Listing
Twin Lakes Airport
UNICOM: 122.7
Phone: (336) 998-8101
No Rating Available
0 Reviews (Read | Sign In To Write)
Phillips 66
As of 2/24
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 5.92
Full Serve
Fuel Notes
Prices include tax

8A7 Aircraft Service & Maintenance

Promote Listing
Twin Lakes Avionics
Phone: (336) 998-6120
Fax: (336) 998-6420
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.7
UNICOM 122.7

Approach

GREENSBORO APPROACH 124.35

Departure

GREENSBORO DEPARTURE 124.35

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

KINT (17nm)
Sun, 3/15 7:40 AM EDT
Sun, 3/15 8:00 AM EDT - Mon, 3/16 8:00 AM EDT
MVFR
8:00 AM EDT - 12:00 PM EDT
Broken 1,500'
6sm
040° 4kts
MVFR
12:00 PM EDT - 5:00 PM EDT
Overcast 1,500'
6sm
140° 10kts
Gusts 16kts
MVFR
Temporary 2:00 PM EDT - 5:00 PM EDT
Light Showers and Rain
Overcast 1,500'
Scattered 800'
6sm
Calm
MVFR
5:00 PM EDT - 8:00 PM EDT
Light Rain
Overcast 1,000'
Scattered 600'
4sm
120° 11kts
LIFR
8:00 PM EDT - 8:00 AM EDT
Mist
Overcast 400'
1.5sm
120° 9kts
LIFR
Temporary 11:00 PM EDT - 2:00 AM EDT
Light Showers and Rain
Overcast 400'
0.5sm
Calm
TAF KINT 151140Z 1512/1612 04004KT P6SM BKN015
   FM151600 14010G16KT P6SM OVC015
   TEMPO 1518/1521 P6SM -SHRA SCT008 OVC015
   FM152100 12011KT 4SM -RA SCT006 OVC010
   FM160000 12009KT 1 1/2SM BR OVC004 WS020/18040KT
   TEMPO 1603/1606 1/2SM -SHRA OVC004
8A7
EffectiveExpiresCategoryNOTAM
Domestic
3/13/26
1615Z
6/11/26
0400Z
!RDU 03/169 8A7 OBST TOWER LGT (ASR 1025811) 355811.10N0802958.60W (3.9NM NNW 8A7) 979.7FT (148.0FT AGL) U/S 2603131615-2606110400
3/12/26
0419Z
7/10/26
0419Z
!RDU 03/137 8A7 OBST TOWER LGT (ASR 1052481) 360337.80N0802539.90W (8.9NM NE 8A7) 1085.0FT (310.0FT AGL) U/S 2603120419-2607100419
3/10/26
1024Z
3/25/26
0924Z
!RDU 03/107 8A7 OBST TOWER LGT (ASR 1209320) 355012.10N0803305.30W (6.7NM SW 8A7) 1066.9FT (259.8FT AGL) U/S 2603101024-2603250924
1/11/26
2054Z
1/11/27
2359Z
Runway!RDU 01/135 8A7 RWY 09 PAPI U/S 2601112054-2701112359
No
0800-1700
DR. PHILIP MARTIN
644 HOLLY SPRINGS ROAD SUITE 161
HOLLY SPRINGS, NC 27540
Phone: 919-571-0081
BRIAN MEADOWS
1105 FORK BIXBY RD
ADVANCE, NC 27006
Phone: 336-998-8101
RALEIGH FSS (RDU)
Toll Free: 1-800-WX-BRIEF
RDU
Sunset to Sunrise
--
N/A
Yes
No
No
Tie-Down
No
Major
Major
Low Pressure
None
Avionics
Pilot Instruction
Aircraft Sales

Runway 09/27

2943 ft. x 50 ft.
ASPH
Good
NONE
NSTD

12,000lbs
--
--
--
  Runway 09 Runway 27
True Heading 88°268°
Traffic Pattern
Markings NSTD NSTD
Markings Condition GOOD GOOD
Latitude 35° 54' 53"N 35° 54' 54"N
Longitude 80° 27' 42"W 80° 27' 07"W
Elevation 773' 818'
Threshold Crossing Height 49 ft. AGL --
Visual Glide Path Angle 3.5° --
Visual Slope Indicator P2L --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110*GTHIS AIRPORT HAS BEEN SURVEYED BY THE NATIONAL GEODETIC SURVEY.
A110-2RWY 09 -18 FT DROP-OFF 150 FT FROM THR LEFT & RIGHT OF CNTRLN.
A110-3RWY 09 UPHILL GRADE.
A110-4DEER/MIGRATORY BIRDS OCNLLY ON ARPT.
A110-5FOR CD CTC GREENSBORO APCH AT 336-333-5119.
A110-6FOR AFT HRS SVC CTC 336-998-2126.
A40-09/27RWY 09/27 NSTD LIGHTING DUE TO NUMBER AND LOCATION.
A42-09_MARKRWY 09 MARKINGS NONSTANDARD DUE TO SIZE AND LOCATION.
A42-27_MARKRWY 27 MARKINGS NONSTANDARD DUE TO SIZE AND LOCATION.
A58-09HAS 10-15 FT BRUSH STARTING 0-200 FT FM THR OFFSET 37-58 FT R OF CNTRLN AND HAS 12-31 FT BRUSH 0-200 FT FM THR OFFSET 55-95 FT L OF CNTRLN.
A70-100LL24 HR SELF SERVICE WITH CC.
TWIN LAKES (IATA: 8A7) is a public airport located in MOCKSVILLE, NC, US.
