DELTA DAVES - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

AA22
Local AA22
DELTA DAVES
PrivatePVT

7 miles NW of DELTA JUNCTION, AK, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
64° 07' 47"N 145° 48' 23"W
Elevation
1050' MSL
Pattern Alt
2050' MSL
Mag Variation
17°E
Fuel
None Listed
FSS
FAIRBANKS (FAI)
Sectional
FAIRBANKS
ARTCC
ANCHORAGE (ZAN)
Data Effective
6/11/26-7/9/26
PABI (9nm) VFR
3:53 PM AKDT
Broken 20,000'
Scattered 13,000'
Scattered 4,700'
10sm
67°F
45°F
29.79"Hg
320° 7kts
AO2 SLP088 SHRA DSNT NE CIG THN CB DSNT NE 6//// T01940072 10194 20144 56013 $
METAR PABI 252353Z 32007KT 10SM SCT047 SCT130 BKN200 19/07 A2979 RMK AO2 SLP088 SHRA DSNT NE CIG THN CB DSNT NE 6//// T01940072 10194 20144 56013 $
+ Add Your Business

AA22 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

No frequencies available for this airport.

FAA A/FD Pages

Terminal Area Forecast

PABI (9nm)
Thu, 6/25 2:00 PM AKDT
Thu, 6/25 2:00 PM AKDT - Fri, 6/26 8:00 PM AKDT
VFR
2:00 PM AKDT - 5:00 PM AKDT
Overcast 9,500'
Broken 6,500'
Few 5,000'
6sm
29.79"Hg
VRB° 6kts
VFR
Becoming 5:00 PM AKDT - 1:00 AM AKDT
Light Rain
Overcast 8,500'
Broken 4,000'
5.59sm
29.73"Hg
VRB° 6kts
VFR
Becoming 1:00 AM AKDT - 8:00 PM AKDT
Overcast 8,500'
Few 4,500'
6sm
29.73"Hg
VRB° 6kts
TAF PABI 252200Z 2522/2704 VRB06KT 9999 FEW050 BKN065 OVC095 620951 QNH2978INS
   BECMG 2601/2602 VRB06KT 9000 -RA BKN040 OVC085 620951 QNH2974INS
   BECMG 2609/2610 VRB06KT 9999 NSW FEW045 OVC085 620951 QNH2973INS TX20/2601Z TN13/2612Z LAST NO AMDS AFT 2605 NEXT 2614
AA22
No NOTAM Available
No
UNATNDD
DAVID & TWYLA WEBBER
PO BOX 31
DELTA JUNCTION, AK 99737
Phone: 907-895-4887
DAVID & TWYLA WEBBER
PO BOX 31
DELTA JUNCTION, AK 99737
Phone: 907-895-4887
FAIRBANKS FSS (FAI)
Toll Free: 1-866-248-6516
N/A
--
--
N/A
Yes
N/A
No
None
No
None
None
None
None
None

Runway 06/24

1800 ft. x 100 ft.
TURF
DIRT
NONE


--
--
--
--
  Runway 06 Runway 24
True Heading 90°270°
Traffic Pattern Left Left
Markings NONE NONE
Markings Condition
Latitude 64° 07' 41"N 64° 07' 41"N
Longitude 145° 48' 51"W 145° 48' 10"W
Elevation 1,049' 1,048'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 15/33

2350 ft. x 60 ft.

TURF
NONE


--
--
--
--
  Runway 15 Runway 33
True Heading 180°0°
Traffic Pattern Right
Markings
Markings Condition
Latitude 64° 08' 03"N 64° 07' 40"N
Longitude 145° 48' 17"W 145° 48' 17"W
Elevation 1,038' 1,050'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1WX CAMERA AVBL ON INTERNET AT HTTPS://WEATHERCAMS.FAA.GOV
DELTA DAVES (IATA: AA22) is a private airport located in DELTA JUNCTION, AK, US.
