BOWMAN FLD - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

B10
BOWMAN FLD
PublicPUB

4 miles SE of LIVERMORE FALLS, ME
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 24' 36"N 70° 08' 46"W
324' MSL
1674' MSL
18W
None Listed
BANGOR (BGR)
MONTREAL
BOSTON (ZBW)
10/3/24-10/31/24
KAUG (16nm) VFR
1:53 PM EDT
Clear
10sm
32°F
32°F
30.28"Hg
170° 3kts
AO2 SNB37E43 SLPNO P0000 60000 58014 $
KAUG 221753Z AUTO 17003KT 10SM CLR A3028 RMK AO2 SNB37E43 SLPNO P0000 60000 58014 $
Add Your Business

B10 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KAUG (16nm)
Tue, 10/22 1:40 PM EDT
Tue, 10/22 2:00 PM EDT - Wed, 10/23 2:00 PM EDT
VFR
2:00 PM EDT - 12:00 AM EDT
Few 20,000'
6sm
310° 3kts
LIFR
12:00 AM EDT - 2:00 AM EDT
Broken 200'
6sm
VRB° 2kts
LIFR
2:00 AM EDT - 10:00 AM EDT
Fog
Overcast 100'
0.25sm
Calm
LIFR
10:00 AM EDT - 11:00 AM EDT
Broken 100'
6sm
180° 6kts
VFR
11:00 AM EDT - 2:00 PM EDT
Scattered 1,200'
6sm
190° 7kts
KAUG 221740Z 2218/2318 31003KT P6SM FEW200
   FM230400 VRB02KT P6SM BKN002
   FM230600 00000KT 1/4SM FG OVC001
   FM231400 18006KT P6SM BKN001
   FM231500 19007KT P6SM SCT012
B10
Domestic
9/29/242043Z !BGR 09/147 B10 OBST TOWER LGT (ASR 1273438) 443435.90N0701435.70W (10.9NM NNW B10) 1152.2FT (352.4FT AGL) U/S 2409292043-2412312359
8/10/241158Z !BGR 08/052 B10 OBST TOWER LGT (ASR 1020935) 441857.50N0701248.40W (6.4NM SSW B10) 989.5FT (309.7FT AGL) U/S 2408101158-2411102359
7/30/241936Z !BGR 07/189 B10 OBST TOWER LGT (ASR 1276673) 443512.60N0700347.50W (11.4NM NNE B10) 1110.9FT (254.9FT AGL) U/S 2407301936-2410301159
No
UNATNDD
BOWMAN FLYING CLUB INC
40 RIVER RD
LIVERMORE, ME 04228
KENNETH LYMAN
14 LYMAN LN
LIVERMORE FALLS, ME 04254
Phone: 207-897-5104
BANGOR FSS (BGR)
Toll Free: 1-800-WX-BRIEF
BGR
--
--
N/A
Yes
Yes
No
Tie-Down
No
0
0
0
0
0
0
None
None
None
None
None

Runway 02/20

2201 ft. x 120 ft.
TURF
Good
NONE


--
--
--
--
  Runway 02 Runway 20
True Heading 8°188°
Traffic Pattern Left Left
Markings NSTD NSTD
Markings Condition GOOD GOOD
Latitude 44° 24' 25"N 44° 24' 47"N
Longitude 70° 08' 48"W 70° 08' 44"W
Elevation 316' 324'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1RWY NOT PLOWED IN WINTER; NO NGT OPS EXC IN EMERG.
A110-2RWY 02/20 800 FT BY 160 FT CLEAR AREA BYD THR TO RWY 2 SW.
A110-3RWY 2 40-70 FT TREES 800 FT FM THR, BOTH SIDES.
A110-4RWY 02/20 190 FT BY 200 FT CLEAR AREA BYD THR TO THE NE.
A110-5RWY 02/20 SOFT IN PLACES AFT RAIN, CALL AMGR FOR RWY CONDS.
A110-6ARPT LCTD NEAR 14 LYMAN LN, LIVERMORE FALLS, ME.
A110-8FOR CD CTC PORTLAND APCH AT 207-874-7320, WHEN APCH CLSD CTC BOSTON ARTCC AT 603-879-6859.
BOWMAN FLD (IATA: B10) is a public airport located in LIVERMORE FALLS, ME.
