6/18/26 1508Z | 6/19/28 1508Z | | !FDC 6/9214 H35 ODP CLARKSVILLE MUNI, CLARKSVILLE, AR.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES:
RWY 9: TREE 83 FT FROM DER, 451 FT RIGHT OF CENTERLINE, 39 FT AGL/507 FT MSL.
TERRAIN BEGINNING 95 FT FROM DER, 140 FT LEFT OF CENTERLINE, UP TO 494 FT MSL.
TREE 119 FT FROM DER, 419 FT LEFT OF CENTERLINE, 49 FT AGL/554 FT MSL.
TREES, FENCE, TERRAIN, VEGETATION BEGINNING 125 FT FROM DER, 92 FT LEFT OF CENTERLINE, UP TO 51 FT AGL/558 FT MSL.
TREE 194 FT FROM DER, 468 FT RIGHT OF CENTERLINE, 50 FT AGL/520 FT MSL.
TREES BEGINNING 235 FT FROM DER, 333 FT RIGHT OF CENTERLINE, UP TO 54 FT AGL/525 FT MSL.
TREE, FENCES, POLES BEGINNING 383 FT FROM DER, 139 FT LEFT OF CENTERLINE, UP TO 60 FT AGL/563 FT MSL.
TREES BEGINNING 463 FT FROM DER, 442 FT RIGHT OF CENTERLINE, UP TO 61 FT AGL/539 FT MSL.
TREES, BUILDING, TERRAIN, FENCE BEGINNING 660 FT FROM DER, 95 FT LEFT OF CENTERLINE, UP TO 66 FT AGL/574 FT MSL.
TREES, TERRAIN, CATENARY WIRES, TRANSMISSION LINE TOWER BEGINNING 697 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO 57 FT AGL/543 FT MSL.
TREE 855 FT FROM DER, 419 FT LEFT OF CENTERLINE, 69 FT AGL/578 FT MSL.
TREES, FENCE BEGINNING 856 FT FROM DER, 219 FT LEFT OF CENTERLINE, UP TO 72 FT AGL/579 FT MSL.
TREES, VEHICLES ON ROADS, POLE BEGINNING 1017 FT FROM DER, 33 FT LEFT OF CENTERLINE, UP TO 71 FT AGL/583 FT MSL.
TREES BEGINNING 1095 FT FROM DER, 17 FT RIGHT OF CENTERLINE, UP TO 80 FT AGL/556 FT MSL.
TREES, POLES BEGINNING 1531 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO 72 FT AGL/599 FT MSL.
TREES BEGINNING 2052 FT FROM DER, 50 FT RIGHT OF CENTERLINE, UP TO 104 FT AGL/561 FT MSL.
TREES BEGINNING 2094 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO 107 FT AGL/565 FT MSL.
TREES BEGINNING 2468 FT FROM DER, 38 FT RIGHT OF CENTERLINE, UP TO 69 FT AGL/568 FT MSL.
TREES BEGINNING 2580 FT FROM DER, 75 FT RIGHT OF CENTERLINE, UP TO 69 FT AGL/573 FT MSL.
TREES BEGINNING 2641 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO 66 FT AGL/576 FT MSL.
TREE 2723 FT FROM DER, 35 FT RIGHT OF CENTERLINE, 73 FT AGL/580 FT MSL.
TREES BEGINNING 2744 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO 63 FT AGL/581 FT MSL.
TREES BEGINNING 2809 FT FROM DER, 57 FT RIGHT OF CENTERLINE, UP TO 73 FT AGL/597 FT MSL.
TREES, POLES BEGINNING 2844 FT FROM DER, ON CENTERLINE, UP TO 73 FT AGL/600 FT MSL.
TREE 5172 FT FROM DER, 1001 FT LEFT OF CENTERLINE, 75 FT AGL/611 FT MSL.
TREES BEGINNING 5904 FT FROM DER, 519 FT LEFT OF CENTERLINE, UP TO 72 FT AGL/645 FT MSL.
TREES BEGINNING 6072 FT FROM DER, 639 FT LEFT OF CENTERLINE, UP TO 66 FT AGL/649 FT MSL.
TREES BEGINNING 1 NM FROM DER, 349 FT LEFT OF CENTERLINE, UP TO 78 FT AGL/675 FT MSL.
TREES BEGINNING 1.1 NM FROM DER, 26 FT LEFT OF CENTERLINE, UP TO 64 FT AGL/700 FT MSL.
TREES BEGINNING 1.1 NM FROM DER, 33 FT RIGHT OF CENTERLINE, UP TO 74 FT AGL/688 FT MSL.
TREES, POLES BEGINNING 1.2 NM FROM DER, 19 FT RIGHT OF CENTERLINE, UP TO 77 FT AGL/723 FT MSL.
TREES, BUILDING, POLES, TERRAIN BEGINNING 1.2 NM FROM DER, 60 FT LEFT OF CENTERLINE, UP TO 69 FT AGL/741 FT MSL.
TREE, VERTICALSTRUCTURE BEGINNING 1.3 NM FROM DER, 90 FT LEFT OF CENTERLINE, UP TO 75 FT AGL/753 FT MSL.
TREES, TERRAIN BEGINNING 1.3 NM FROM DER, 9 FT RIGHT OF CENTERLINE, UP TO 84 FT AGL/750 FT MSL.
TREE, TERRAIN BEGINNING 1.4 NM FROM DER, 171 FT RIGHT OF CENTERLINE, UP TO 79 FT AGL/772 FT MSL.
TREES BEGINNING 1.5 NM FROM DER, 550 FT RIGHT OF CENTERLINE, UP TO 64 FT AGL/794 FT MSL.
TREE 2 NM FROM DER, 1259 FT LEFT OF CENTERLINE, 71 FT AGL/820 FT MSL.
RWY 27: TREES, POLE, BUILDING BEGINNING 32 FT FROM DER, 311 FT RIGHT OF CENTERLINE, UP TO 34 FT AGL/481 FT MSL.
BUILDING 47 FT FROM DER, 256 FT LEFT OF CENTERLINE, 13 FT AGL/457 FT MSL.
POLE 192 FT FROM DER, 366 FT LEFT OF CENTERLINE, 32 FT AGL/472 FT MSL.
LIGHT POLE, POLES, TREES, BUILDING BEGINNING 213 FT FROM DER, 16 FT LEFT OF CENTERLINE, UP TO 78 FT AGL/517 FT MSL.
TREES, POLE BEGINNING 398 FT FROM DER, 317 FT RIGHT OF CENTERLINE, UP TO 55 FT AGL/497 FT MSL.
TREES, BUILDING, TRANSMISSION LINE TOWER BEGINNING 614 FT FROM DER, 30 FT RIGHT OF CENTERLINE, UP TO 62 FT AGL/506 FT MSL.
TREE 777 FT FROM DER, 384 FT RIGHT OF CENTERLINE, 75 FT AGL/520 FT MSL.
TREES, BUILDING, TRANSMISSION LINE TOWER BEGINNING 789 FT FROM DER, 69 FT RIGHT OF CENTERLINE, UP TO 87 FT AGL/528 FT MSL.
TREES, POLE, TERRAIN BEGINNING 836 FT FROM DER, 60 FT RIGHT OF CENTERLINE, UP TO 94 FT AGL/536 FT MSL.
TREES, ANTENNA, TRANSMISSION LINE TOWER, POLES, VEHICLES ON ROADS BEGINNING 941 FT FROM DER, 6 FT RIGHT OF CENTERLINE, UP TO 89 FT AGL/548 FT MSL.
TREES BEGINNING 1272 FT FROM DER, 14 FT RIGHT OF CENTERLINE, UP TO 84 FT AGL/572 FT MSL.
TREES, POLE BEGINNING 1385 FT FROM DER, 43 FT RIGHT OF CENTERLINE, UP TO 73 FT AGL/582 FT MSL.
TREES, TERRAIN, POLES, VEGETATION BEGINNING 1438 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO 68 FT AGL/584 FT MSL.
TREES BEGINNING 1829 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP TO 70 FT AGL/526 FT MSL.
TREES BEGINNING 1910 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO 72 FT AGL/529 FT MSL.
TREES BEGINNING 2061 FT FROM DER, ON CENTERLINE, UP TO 86 FT AGL/554 FT MSL.
TREES BEGINNING 2264 FT FROM DER, 6 FT LEFT OF CENTERLINE, UP TO 78 FT AGL/558 FT MSL.
TREES BEGINNING 2514 FT FROM DER, 6 FT LEFT OF CENTERLINE, UP TO 58 FT AGL/560 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2606181508-2806191508EST |
