3/4/25 1555Z | 3/4/27 1555Z | | !FDC 5/9025 K09 PART 1 OF 5 ODP PISECO, PISECO, NY.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES:
RWY 4: TREES BEGINNING 6 FT FROM DER, 161 FT RIGHT OF CENTERLINE,
UP TO 1786 FT MSL.
TREE 9 FT FROM DER, 250 FT LEFT OF CENTERLINE, 1771 FT MSL.
TREES BEGINNING 44 FT FROM DER, 84 FT RIGHT OF CENTERLINE, UP TO 94
FT AGL/1820 FT MSL.
TREES BEGINNING 67 FT FROM DER, 338 FT LEFT OF CENTERLINE, UP TO
1794 FT MSL.
TREES BEGINNING 144 FT FROM DER, 310 FT LEFT OF CENTERLINE, UP TO
1798 FT MSL.
TREES BEGINNING 212 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP TO
1803 FT MSL.
TREES, TERRAIN BEGINNING 226 FT FROM DER, 45 FT RIGHT OF
CENTERLINE, UP TO 1821 FT MSL.
TREES BEGINNING 577 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO
1836 FT MSL.
TREES BEGINNING 778 FT FROM DER, 245 FT RIGHT OF CENTERLINE, UP TO
1839 FT MSL.
TREES BEGINNING 827 FT FROM DER, 66 FT RIGHT OF CENTERLINE, UP TO
2503041555-2703041555EST
END PART 1 OF 5
!FDC 5/9025 K09 PART 2 OF 5 ODP PISECO, PISECO, NY.
1845 FT MSL.
TREES BEGINNING 859 FT FROM DER, 94 FT LEFT OF CENTERLINE, UP TO
1805 FT MSL.
TREES BEGINNING 1091 FT FROM DER, 232 FT LEFT OF CENTERLINE, UP TO
1814 FT MSL.
TREES BEGINNING 1095 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP TO
1818 FT MSL.
TREES BEGINNING 2138 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP TO
1823 FT MSL.
TREES BEGINNING 2347 FT FROM DER, 466 FT RIGHT OF CENTERLINE, UP TO
1855 FT MSL.
TREES BEGINNING 2409 FT FROM DER, 660 FT RIGHT OF CENTERLINE, UP TO
1856 FT MSL.
TREES BEGINNING 2429 FT FROM DER, 57 FT RIGHT OF CENTERLINE, UP TO
1860 FT MSL.
TREES BEGINNING 2649 FT FROM DER, 135 FT RIGHT OF CENTERLINE, UP TO
1861 FT MSL.
TREES BEGINNING 2856 FT FROM DER, 14 FT RIGHT OF CENTERLINE, UP TO
1864 FT MSL.
TREE 2975 FT FROM DER, 1160 FT RIGHT OF CENTERLINE, 1868 FT MSL.
2503041555-2703041555EST
END PART 2 OF 5
!FDC 5/9025 K09 PART 3 OF 5 ODP PISECO, PISECO, NY.
TREE 3011 FT FROM DER, 997 FT RIGHT OF CENTERLINE, 1872 FT MSL.
TREES BEGINNING 3018 FT FROM DER, 170 FT RIGHT OF CENTERLINE, UP TO
1875 FT MSL.
TREES BEGINNING 3054 FT FROM DER, 5 FT LEFT OF CENTERLINE, UP TO
1828 FT MSL.
TREES, VERTICAL STRUCTURE BEGINNING 3385 FT FROM DER, 2 FT RIGHT OF
CENTERLINE, UP TO 1881 FT MSL.
TREES BEGINNING 4043 FT FROM DER, 12 FT LEFT OF CENTERLINE, UP TO
1846 FT MSL.
TREES BEGINNING 4849 FT FROM DER, 1024 FT LEFT OF CENTERLINE, UP TO
1850 FT MSL.
TREES BEGINNING 2 NM FROM DER, 1110 FT RIGHT OF CENTERLINE, UP TO
72 FT AGL/2122 FT MSL.
TREE 2.1 NM FROM DER, 1667 FT RIGHT OF CENTERLINE, 2052 FT MSL.
RWY 22: TREES, TRAVERSE WAY, POLE, BUILDING BEGINNING 5 FT FROM
DER, 2 FT RIGHT OF CENTERLINE, UP TO 76 FT AGL/1766 FT MSL.
TRAVERSE WAY 15 FT FROM DER, 239 FT LEFT OF CENTERLINE, 1700 FT
MSL.
TREES, TRAVERSE WAY BEGINNING 106 FT FROM DER, 182 FT LEFT OF
CENTERLINE, UP TO 1752 FT MSL.
2503041555-2703041555EST
END PART 3 OF 5
!FDC 5/9025 K09 PART 4 OF 5 ODP PISECO, PISECO, NY.
TREES BEGINNING 181 FT FROM DER, 243 FT LEFT OF CENTERLINE, UP TO
1766 FT MSL.
TREES, POLE BEGINNING 261 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP
TO 1768 FT MSL.
TREES BEGINNING 809 FT FROM DER, 114 FT LEFT OF CENTERLINE, UP TO
1780 FT MSL.
TREES BEGINNING 980 FT FROM DER, 15 FT RIGHT OF CENTERLINE, UP TO
1769 FT MSL.
TREES BEGINNING 1381 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO
1799 FT MSL.
TREES BEGINNING 2676 FT FROM DER, 782 FT LEFT OF CENTERLINE, UP TO
1802 FT MSL.
TREES BEGINNING 3246 FT FROM DER, 741 FT LEFT OF CENTERLINE, UP TO
1807 FT MSL.
TREE 3605 FT FROM DER, 1446 FT RIGHT OF CENTERLINE, 1787 FT MSL.
TREE 3848 FT FROM DER, 1448 FT RIGHT OF CENTERLINE, 1806 FT MSL.
TREES BEGINNING 4014 FT FROM DER, 1383 FT RIGHT OF CENTERLINE, UP
TO 1814 FT MSL.
TREE 4300 FT FROM DER, 1523 FT RIGHT OF CENTERLINE, 1831 FT MSL.
TREES BEGINNING 4347 FT FROM DER, 1402 FT RIGHT OF CENTERLINE, UP
2503041555-2703041555EST
END PART 4 OF 5
!FDC 5/9025 K09 PART 5 OF 5 ODP PISECO, PISECO, NY.
TO 1841 FT MSL.
TREES BEGINNING 4967 FT FROM DER, 1642 FT RIGHT OF CENTERLINE, UP
TO 1875 FT MSL.
TREE 5069 FT FROM DER, 1781 FT RIGHT OF CENTERLINE, 1898 FT MSL.
TREES BEGINNING 5149 FT FROM DER, 1625 FT RIGHT OF CENTERLINE, UP
TO 1902 FT MSL.
TREES BEGINNING 5561 FT FROM DER, 1724 FT RIGHT OF CENTERLINE, UP
TO 1922 FT MSL.
TREES BEGINNING 5803 FT FROM DER, 1709 FT RIGHT OF CENTERLINE, UP
TO 1954 FT MSL.
TREES BEGINNING 5908 FT FROM DER, 1797 FT RIGHT OF CENTERLINE, UP
TO 1973 FT MSL.
TREES BEGINNING 6026 FT FROM DER, 1593 FT RIGHT OF CENTERLINE, UP
TO 2010 FT MSL.
TREES BEGINNING 1.2 NM FROM DER, 1579 FT RIGHT OF CENTERLINE, UP TO
2348 FT MSL.
TREES BEGINNING 1.3 NM FROM DER, 1775 FT RIGHT OF CENTERLINE, UP TO
2434 FT MSL.
TREES BEGINNING 2.5 NM FROM DER, 2759 FT RIGHT OF CENTERLINE, UP TO
2295 FT MSL.
2503041555-2703041555EST
END PART 5 OF 5
|
