3/20/25 1528Z | 3/20/27 1528Z | | !FDC 5/5796 AMN PART 1 OF 5 ODP GRATIOT COMMUNITY, ALMA, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 9: LIGHT POLE 39 FT FROM DER, 117 FT
RIGHT OF CENTERLINE, 3 FT AGL/754 FT MSL.
TREE 731 FT FROM DER, 666 FT RIGHT OF CENTERLINE, 64 FT AGL/807 FT
MSL.
TREE 868 FT FROM DER, 659 FT RIGHT OF CENTERLINE, 67 FT AGL/811 FT
MSL.
TREE 1004 FT FROM DER, 719 FT RIGHT OF CENTERLINE, 79 FT AGL/829 FT
MSL.
TREES, POLE BEGINNING 1142 FT FROM DER, 438 FT RIGHT OF CENTERLINE,
UP TO 76 FT AGL/830 FT MSL.
TREE 1388 FT FROM DER, 379 FT LEFT OF CENTERLINE, 797 FT MSL.
TREES BEGINNING 1425 FT FROM DER, 518 FT LEFT OF CENTERLINE, UP TO
820 FT MSL.
TOWER, ANTENNA BEGINNING 2.3 NM FROM DER, 2432 FT LEFT OF
CENTERLINE, UP TO 347 FT AGL/1147 FT MSL. RWY 18: POLE 8 FT FROM
DER, 28 FT RIGHT OF CENTERLINE, 2 FT AGL/755 FT MSL.
TREES BEGINNING 165 FT FROM DER, 377 FT RIGHT OF CENTERLINE, UP TO
55 FT AGL/804 FT MSL.
TREES BEGINNING 551 FT FROM DER, 355 FT RIGHT OF CENTERLINE, UP TO
109 FT AGL/853 FT MSL. 2503201528-2703201528EST
END PART 1 OF 5
!FDC 5/5796 AMN PART 2 OF 5 ODP GRATIOT COMMUNITY, ALMA, MI.
86 FT AGL/836 FT MSL.
TREE 596 FT FROM DER, 601 FT LEFT OF CENTERLINE, 33 FT AGL/782 FT
MSL.
TREE 687 FT FROM DER, 538 FT LEFT OF CENTERLINE, 42 FT AGL/792 FT
MSL.
TREES BEGINNING 709 FT FROM DER, 480 FT RIGHT OF CENTERLINE, UP TO
99 FT AGL/851 FT MSL.
TREES BEGINNING 777 FT FROM DER, 492 FT LEFT OF CENTERLINE, UP TO
98 FT AGL/847 FT MSL.
TREES BEGINNING 839 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO
102 FT AGL/855 FT MSL.
TREES BEGINNING 955 FT FROM DER, 11 FT LEFT OF CENTERLINE, UP TO
104 FT AGL/854 FT MSL.
TREES BEGINNING 1561 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO
110 FT AGL/863 FT MSL.
TREES BEGINNING 2702 FT FROM DER, 447 FT RIGHT OF CENTERLINE, UP TO
110 FT AGL/866 FT MSL. RWY 27: TERRAIN 26 FT FROM DER, 357 FT
RIGHT OF CENTERLINE, 752 FT MSL.
TREE 301 FT FROM DER, 575 FT RIGHT OF CENTERLINE, 778 FT MSL.
TREES BEGINNING 354 FT FROM DER, 570 FT RIGHT OF CENTERLINE, UP TO
109 FT AGL/853 FT MSL. 2503201528-2703201528EST
END PART 2 OF 5
!FDC 5/5796 AMN PART 3 OF 5 ODP GRATIOT COMMUNITY, ALMA, MI.
793 FT MSL.
TREES BEGINNING 544 FT FROM DER, 558 FT RIGHT OF CENTERLINE, UP TO
51 FT AGL/803 FT MSL.
TREES BEGINNING 1027 FT FROM DER, 573 FT RIGHT OF CENTERLINE, UP TO
59 FT AGL/811 FT MSL.
TREE 1160 FT FROM DER, 761 FT LEFT OF CENTERLINE, 45 FT AGL/795 FT
MSL.
TREE 1369 FT FROM DER, 683 FT LEFT OF CENTERLINE, 825 FT MSL.
TREES BEGINNING 1457 FT FROM DER, 571 FT RIGHT OF CENTERLINE, UP TO
835 FT MSL.
TREES BEGINNING 1498 FT FROM DER, 592 FT LEFT OF CENTERLINE, UP TO
838 FT MSL.
TREES BEGINNING 1755 FT FROM DER, 550 FT LEFT OF CENTERLINE, UP TO
849 FT MSL.
TREES BEGINNING 1895 FT FROM DER, 131 FT RIGHT OF CENTERLINE, UP TO
103 FT AGL/854 FT MSL.
TREES BEGINNING 2525 FT FROM DER, 220 FT LEFT OF CENTERLINE, UP TO
852 FT MSL.
TREES BEGINNING 3801 FT FROM DER, 936 FT LEFT OF CENTERLINE, UP TO
853 FT MSL. RWY 36: POLE 11 FT FROM DER, 27 FT RIGHT OF
109 FT AGL/853 FT MSL. 2503201528-2703201528EST
END PART 3 OF 5
!FDC 5/5796 AMN PART 4 OF 5 ODP GRATIOT COMMUNITY, ALMA, MI.
CENTERLINE, 2 FT AGL/755 FT MSL.
TREE 143 FT FROM DER, 288 FT LEFT OF CENTERLINE, 27 FT AGL/780 FT
MSL.
TREE 170 FT FROM DER, 459 FT LEFT OF CENTERLINE, 786 FT MSL.
TREES BEGINNING 182 FT FROM DER, 419 FT LEFT OF CENTERLINE, UP TO
57 FT AGL/808 FT MSL.
BUILDING, POLE BEGINNING 238 FT FROM DER, 517 FT RIGHT OF
CENTERLINE, UP TO 28 FT AGL/777 FT MSL.
TREES BEGINNING 298 FT FROM DER, 437 FT LEFT OF CENTERLINE, UP TO
811 FT MSL.
TREES BEGINNING 861 FT FROM DER, 38 FT LEFT OF CENTERLINE, UP TO 81
FT AGL/833 FT MSL.
TREES BEGINNING 1059 FT FROM DER, 141 FT RIGHT OF CENTERLINE, UP TO
787 FT MSL.
TREES BEGINNING 1113 FT FROM DER, 223 FT RIGHT OF CENTERLINE, UP TO
59 FT AGL/808 FT MSL.
TREE 1265 FT FROM DER, 330 FT RIGHT OF CENTERLINE, 814 FT MSL.
TREES BEGINNING 1274 FT FROM DER, 12 FT RIGHT OF CENTERLINE, UP TO
839 FT MSL.
TREES BEGINNING 1603 FT FROM DER, 7 FT RIGHT OF CENTERLINE, UP TO
109 FT AGL/853 FT MSL. 2503201528-2703201528EST
END PART 4 OF 5
!FDC 5/5796 AMN PART 5 OF 5 ODP GRATIOT COMMUNITY, ALMA, MI.
101 FT AGL/848 FT MSL.
TREES BEGINNING 1674 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO
842 FT MSL.
TREES BEGINNING 2164 FT FROM DER, 16 FT LEFT OF CENTERLINE, UP TO
97 FT AGL/844 FT MSL.
TREES BEGINNING 2361 FT FROM DER, 72 FT RIGHT OF CENTERLINE, UP TO
103 FT AGL/856 FT MSL.
TREES BEGINNING 2847 FT FROM DER, 271 FT LEFT OF CENTERLINE, UP TO
102 FT AGL/850 FT MSL.
TREES BEGINNING 3187 FT FROM DER, 540 FT LEFT OF CENTERLINE, UP TO
105 FT AGL/852 FT MSL.
TREES BEGINNING 3381 FT FROM DER, 78 FT LEFT OF CENTERLINE, UP TO
109 FT AGL/853 FT MSL. 2503201528-2703201528EST
END PART 5 OF 5
|
