KAUM
AUSTIN MUNI
PublicPUB

2 miles E of AUSTIN, MN
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
43° 39' 45"N 92° 55' 58"W
1234' MSL
2234' MSL
00E
JET A, 100LL
PRINCETON (PNM)
CHICAGO
MINNEAPOLIS (ZMP)
9/5/24-10/3/24
KAUM VFR
9:55 PM CDT
Overcast 5,000'
10sm
70°F
63°F
30.06"Hg
100° 4kts
AO2
KAUM 140255Z AUTO 10004KT 10SM OVC050 21/17 A3006 RMK AO2
Add Your Business

KAUM FBOs

Promote Listing
Austin Aeroflight
UNICOM: 122.7
Phone: (507) 433-1813
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 8/22
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 6.46 6.26
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.7 122.7

AWOS-3

AWOS-3
507-433-6667
 119.025

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KRST (24nm)
Fri, 9/13 6:32 PM CDT
Fri, 9/13 7:00 PM CDT - Sat, 9/14 7:00 PM CDT
VFR
7:00 PM CDT - 1:00 AM CDT
Overcast 20,000'
6sm
140° 8kts
VFR
1:00 AM CDT - 7:00 AM CDT
Overcast 5,000'
6sm
140° 6kts
VFR
7:00 AM CDT - 11:00 AM CDT
Light Showers and Rain
Overcast 4,500'
Scattered 2,500'
6sm
140° 8kts
VFR
11:00 AM CDT - 7:00 PM CDT
Showers in vicinity
Broken 4,000'
Scattered 2,500'
6sm
150° 8kts
KRST 132332Z 1400/1424 14008KT P6SM OVC200
   FM140600 14006KT P6SM OVC050
   FM141200 14008KT P6SM -SHRA SCT025 OVC045
   FM141600 15008KT P6SM VCSH SCT025 BKN040
KAUM
Domestic
9/8/241200Z !AUM 09/001 AUM RWY 35 PAPI U/S 2409081200-2410312200
8/1/241456Z !AUM 08/005 AUM OBST TOWER LGT (ASR 1024273) 434231.00N0925645.00W (2.8NM N AUM) 1465.2FT (246.1FT AGL) U/S 2408011456-2501312359
8/1/241455Z !AUM 08/004 AUM OBST TOWER LGT (ASR 1024272) 434234.00N0925650.00W (2.9NM NNW AUM) 1471.1FT (246.1FT AGL) U/S 2408011455-2501312359
8/1/241454Z !AUM 08/003 AUM OBST TOWER LGT (ASR 1024271) 434226.00N0925702.00W (2.8NM NNW AUM) 1469.2FT (246.1FT AGL) U/S 2408011454-2501312359
8/1/241452Z !AUM 08/002 AUM OBST TOWER LGT (ASR 1024270) 434223.00N0925656.00W (2.7NM NNW AUM) 1467.8FT (246.1FT AGL) U/S 2408011452-2501312359
7/31/241748Z !AUM 07/006 AUM NAV ILS RWY 35 U/S 2407311748-2410032000EST
7/3/241436Z !AUM 07/001 AUM OBST TOWER LGT (ASR 1043296) 433823.00N0923831.00W (12.7NM E AUM) 1890.4FT (500.0FT AGL) U/S 2407031436-2410012359
No
SAT 0800-1600
SUN 0900-1500
MON-FRI 0800-1700
CITY OF AUSTIN
500 4TH AV NE
AUSTIN, MN 55912-3773
Phone: 507-437-7674
BRUCE W BUDAHN
710 21ST ST NE
AUSTIN, MN 55912-4165
Phone: 507-433-1813
PRINCETON FSS (PNM)
Toll Free: 1-800-WX-BRIEF
AUM
--
ACTVT MALSR RWY 35; REIL RWY 17; PAPI RWY 17 & 35; HIRL RWY 17/35 DALGT - CTAF. HIRL RWY 17/35 PRESET LOW INTST AT NIGHT; TO INCR INTST - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
None
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 17/35

5800 ft. x 100 ft.
CONC
Good
NONE
HIGH
48 /R/C/W/T
100,000lbs
135,000lbs
--
--
  Runway 17 Runway 35
True Heading 172°352°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 43° 40' 14"N 43° 39' 17"N
Longitude 92° 56' 04"W 92° 55' 53"W
Elevation 1,231' 1,231'
Threshold Crossing Height 41 ft. AGL 42 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes
A110-1MIGRATORY WATERFOWL & DEER INVOF ARPT.
A110-3FOR CD CTC ROCHESTER APCH AT 507-424-8111.
AUSTIN MUNI (ICAO: KAUM, IATA: AUM) is a public airport located in AUSTIN, MN.
