9/15/25 1535Z | 9/15/27 1535Z | | !FDC 5/3777 AXH PART 1 OF 4 ODP HOUSTON/SOUTHWEST, HOUSTON, TX.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 5...
CHANGE TAKEOFF OBSTACLE NOTES TO READ: NOTE: RWY 9: BUILDING, POLE,
NAVAID, TREE BEGINNING 117 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP
TO 44 FT AGL/111 FT MSL.
BUILDING, POLE, NAVAID BEGINNING 244 FT FROM DER, 2 FT RIGHT OF
CENTERLINE, UP TO 42 FT AGL/106 FT MSL.
TREES BEGINNING 500 FT FROM DER, 354 FT RIGHT OF CENTERLINE, UP TO
110 FT MSL.
TREES BEGINNING 660 FT FROM DER, 8 FT RIGHT OF CENTERLINE, UP TO
111 FT MSL.
TREES BEGINNING 676 FT FROM DER, 18 FT LEFT OF CENTERLINE, UP TO 48
FT AGL/114 FT MSL.
TOWER 1171 FT FROM DER, 658 FT LEFT OF CENTERLINE, 51 FT AGL/115 FT
MSL.
TREES BEGINNING 1490 FT FROM DER, 597 FT LEFT OF CENTERLINE, UP TO
51 FT AGL/118 FT MSL.
TREE 1762 FT FROM DER, 412 FT RIGHT OF CENTERLINE, 51 FT AGL/117 FT
MSL.
TREE 1922 FT FROM DER, 69 FT LEFT OF CENTERLINE, 122 FT MSL.
WATER TOWER 2193 FT FROM DER, 903 FT RIGHT OF CENTERLINE, 87 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2509151535-2709151535EST
END PART 1 OF 4
!FDC 5/3777 AXH PART 2 OF 4 ODP HOUSTON/SOUTHWEST, HOUSTON, TX.
AGL/153 FT MSL.
SIGN, POLE BEGINNING 2236 FT FROM DER, 676 FT LEFT OF CENTERLINE,
UP TO 71 FT AGL/138 FT MSL.
NOTE: RWY 27: VEHICLE ON ROAD 99 FT FROM DER, 290 FT RIGHT OF
CENTERLINE, 83 FT MSL.
TREE 164 FT FROM DER, 187 FT LEFT OF CENTERLINE, 16 FT AGL/82 FT
MSL.
VEHICLE ON ROAD 203 FT FROM DER, 282 FT RIGHT OF CENTERLINE, 85 FT
MSL.
TREE 219 FT FROM DER, 527 FT RIGHT OF CENTERLINE, 39 FT AGL/105 FT
MSL.
TREES BEGINNING 346 FT FROM DER, 498 FT RIGHT OF CENTERLINE, UP TO
40 FT AGL/106 FT MSL.
TREE 411 FT FROM DER, 481 FT LEFT OF CENTERLINE, 30 FT AGL/96 FT
MSL.
POLE, VEHICLE ON ROAD, TREE BEGINNING 543 FT FROM DER, 220 FT RIGHT
OF CENTERLINE, UP TO 43 FT AGL/110 FT MSL.
TREE 868 FT FROM DER, 463 FT RIGHT OF CENTERLINE, 44 FT AGL/114 FT
MSL.
TREE, POLE BEGINNING 873 FT FROM DER, 492 FT RIGHT OF CENTERLINE,
ALL OTHER DATA REMAINS AS PUBLISHED. 2509151535-2709151535EST
END PART 2 OF 4
!FDC 5/3777 AXH PART 3 OF 4 ODP HOUSTON/SOUTHWEST, HOUSTON, TX.
UP TO 121 FT MSL.
TREES BEGINNING 1050 FT FROM DER, 337 FT LEFT OF CENTERLINE, UP TO
126 FT MSL.
TREE, POLE BEGINNING 1220 FT FROM DER, 146 FT RIGHT OF CENTERLINE,
UP TO 123 FT MSL.
TREES BEGINNING 1307 FT FROM DER, 354 FT LEFT OF CENTERLINE, UP TO
57 FT AGL/127 FT MSL.
TREES BEGINNING 1406 FT FROM DER, 12 FT LEFT OF CENTERLINE, UP TO
134 FT MSL.
TREE, POLE BEGINNING 1465 FT FROM DER, 130 FT RIGHT OF CENTERLINE,
UP TO 61 FT AGL/125 FT MSL.
TREES BEGINNING 1542 FT FROM DER, 535 FT RIGHT OF CENTERLINE, UP TO
129 FT MSL.
TREE, POLE BEGINNING 1599 FT FROM DER, 45 FT RIGHT OF CENTERLINE,
UP TO 130 FT MSL.
TREES BEGINNING 1951 FT FROM DER, 13 FT LEFT OF CENTERLINE, UP TO
137 FT MSL.
TREES BEGINNING 2124 FT FROM DER, 20 FT LEFT OF CENTERLINE, UP TO
140 FT MSL.
TREE 2385 FT FROM DER, 859 FT RIGHT OF CENTERLINE, 72 FT AGL/136 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2509151535-2709151535EST
END PART 3 OF 4
!FDC 5/3777 AXH PART 4 OF 4 ODP HOUSTON/SOUTHWEST, HOUSTON, TX.
MSL..
ALL OTHER DATA REMAINS AS PUBLISHED. 2509151535-2709151535EST
END PART 4 OF 4
|
