KAXV
ICAO KAXVIATA AXVLocal AXV
NEIL ARMSTRONG
PublicPUB

8 miles SW of WAPAKONETA, OH, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
40° 29' 37"N 84° 17' 53"W
Elevation
912' MSL
Pattern Alt
1902' MSL
Mag Variation
6°W
Declination
4°W
Fuel
JET A-1+, 100LL
FSS
DAYTON (DAY)
Sectional
DETROIT
ARTCC
INDIANAPOLIS (ZID)
Data Effective
2/19/26-3/19/26
KAXV VFR
9:55 AM EDT
Scattered 12,000'
10sm
50°F
32°F
29.78"Hg
160° 12kts
AO2
METAR KAXV 151355Z AUTO 16012KT 10SM SCT120 10/00 A2978 RMK AO2
+ Add Your Business

KAXV FBOs

Promote Listing
Auglaize County Airport Authority
UNICOM: 122.8
Phone: (419) 753-2810
No Rating Available
0 Reviews (Read | Sign In To Write)
Phillips 66
As of 3/10
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 5.57 4.32 4.32
Full Serve 5.57 4.32 4.32
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3PT 128.325
(419) 753-2821

Common

CTAF 122.8
UNICOM 122.8

Approach

COLUMBUS APPROACH 134.45

Departure

COLUMBUS DEPARTURE 134.45

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

KDAY (35nm)
Sun, 3/15 7:26 AM EDT
Sun, 3/15 8:00 AM EDT - Mon, 3/16 8:00 AM EDT
VFR
8:00 AM EDT - 10:00 AM EDT
Broken 15,000'
6sm
140° 12kts
VFR
10:00 AM EDT - 12:00 PM EDT
Broken 20,000'
6sm
170° 16kts
Gusts 26kts
VFR
12:00 PM EDT - 7:00 PM EDT
Broken 20,000'
Scattered 5,000'
6sm
180° 26kts
Gusts 40kts
VFR
7:00 PM EDT - 12:00 AM EDT
Broken 5,000'
6sm
180° 20kts
Gusts 32kts
MVFR
12:00 AM EDT - 3:00 AM EDT
Light Showers and Rain and Mist
Overcast 3,500'
3sm
210° 22kts
Gusts 38kts
MVFR
3:00 AM EDT - 8:00 AM EDT
Broken 2,500'
6sm
240° 22kts
Gusts 35kts
TAF KDAY 151126Z 1512/1612 14012KT P6SM BKN150 WS020/19045KT
   FM151400 17016G26KT P6SM BKN200
   FM151600 18026G40KT P6SM SCT050 BKN200
   FM152300 18020G32KT P6SM BKN050 WS020/19055KT
   FM160400 21022G38KT 3SM -SHRA BR OVC035 WS020/19055KT
   FM160700 24022G35KT P6SM BKN025
KAXV
EffectiveExpiresCategoryNOTAM
Domestic
3/19/26
1400Z
3/19/26
2200Z
!AXV 03/008 AXV AIRSPACE FLTCK ACFT OPS WI AN AREA DEFINED AS 5NM RADIUS OF AXV SFC-3500FT AGL ACFT CS FLC75 2603191400-2603192200
3/13/26
1914Z
3/28/26
1814Z
!AXV 03/007 AXV OBST TOWER LGT (ASR 1060411) 402607.00N0841024.00W (6.6NM ESE AXV) 1325.5FT (330.1FT AGL) U/S 2603131914-2603281814
3/13/26
1901Z
7/11/26
1901Z
!AXV 03/006 AXV OBST TOWER LGT (ASR 1037974) 402412.20N0841006.50W (8.0NM SE AXV) 1304.5FT (267.7FT AGL) U/S 2603131901-2607111901
3/13/26
1824Z
7/11/26
1824Z
!AXV 03/005 AXV OBST TOWER LGT (ASR 1282133) 402458.30N0842247.30W (6.0NM SW AXV) 1237.9FT (288.1FT AGL) U/S 2603131824-2607111824
FDC
3/13/26
1154Z
5/31/26
1154Z
!FDC 6/7955 AXV IAP NEIL ARMSTRONG, WAPAKONETA, OH.
VOR-A, AMDT 8B...
DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
DQN VOR/DME OUT OF SERVICE. 2603131154-2605311154EST
3/4/26
1321Z
!FDC 6/3371 AXV IAP NEIL ARMSTRONG, WAPAKONETA, OH.
RNAV (GPS) RWY 8, ORIG-D...
LNAV CAT C VISIBILITY 1 3/8.
THIS IS RNAV (GPS) RWY 8, ORIG-E. 2603041321-PERM
4/16/25
1316Z
!FDC 5/7283 AXV IAP NEIL ARMSTRONG, WAPAKONETA, OH.
VOR-A, AMDT 8B...
PROCEDURE NA.
2504161316-2704161315EST
No
MON-FRI 0700-1700
SAT-SUN ON CALL
FOR SVC & FUEL CALL AMGR.
AUGLAIZE CO ARPT AUTH
PO BOX 400
NEW KNOXVILLE, OH 45871
Phone: 419-753-2810
TED BERGSTROM
PO BOX 400
NEW KNOXVILLE, OH 45871
Phone: 419-753-2810
DAYTON FSS (DAY)
Toll Free: 1-800-WX-BRIEF
AXV
--
ACTVT REIL RWY 08 & 26; MIRL RWY 08/26 - 122.7.
N/A
Yes - Lighted
No
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
High Pressure
None
Pilot Instruction

Runway 08/26

5500 ft. x 100 ft.
ASPH
Fair
GRVD
MED

--
--
--
--
  Runway 08 Runway 26
True Heading 77°257°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 40° 29' 30"N 40° 29' 43"N
Longitude 84° 18' 28"W 84° 17' 18"W
Elevation 908' 908'
Threshold Crossing Height 50 ft. AGL 40 ft. AGL
Visual Glide Path Angle 4° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes
A110-1FOR CD CTC COLUMBUS APCH AT 614-338-8537.
A110-2WILDLIFE ON & INVOF ARPT.
A17-H2FOR SVC & FUEL CALL AMGR.
A57-08APCH SLP 13:1 TO DTHR DUE TO +89 FT TREE, 1168 FT DIST, 238 FT L.
A57-26APCH SLP 20:1 TO DTHR
A58-268 FT FENCE, 65-200 FT DIST, 220-230 FT L.
A70-100LL100LL & JET A1+ AVBL H24 SELF SVC VIA CREDIT CARD.
A81-APTACTVT REIL RWY 08 & 26; MIRL RWY 08/26 - 122.7.
NEIL ARMSTRONG (ICAO: KAXV, IATA: AXV) is a public airport located in WAPAKONETA, OH, US.
