BILLINGS LOGAN INTL - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KBIL
BILLINGS LOGAN INTL
PublicPUB

2 miles NW of BILLINGS, MT
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
45° 48' 28"N 108° 32' 37"W
3662' MSL
4662' MSL
10E
JET A, 100LL
GREAT FALLS (GTF)
BILLINGS
SALT LAKE CITY (ZLC)
11/28/24-12/26/24
KBIL VFR
6:53 AM MST
Clear
10sm
14°F
8°F
30.25"Hg
Calm
AO2 SLP299 T11001133
KBIL 021353Z 00000KT 10SM CLR M10/M13 A3025 RMK AO2 SLP299 T11001133
Add Your Business

KBIL FBOs

Promote Listing
Beacon Air Group
UNICOM: 128.825
Phone: (800) 700-5107
No Rating Available
0 Reviews (Read | Sign In To Write)
Other
As of 11/27
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 5.22 4.10 4.20
Fuel Notes
Prices include tax
Promote Listing
Edwards Jet Center
UNICOM: 122.95
Phone: (406) 252-0508
No Rating Available
0 Reviews (Read | Sign In To Write)
Other
As of 11/26
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 4.95
Full Serve 5.65 4.75 4.85
Fuel Notes
Prices include tax
Fuel Hours
EJC is open 24/7.

KBIL Aircraft Service & Maintenance

Promote Listing
Aerotronics Inc.
Phone: (406) 259-5006
Fax: (406) 252-4369
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 --

ATIS

ATIS
 126.3

ASOS

ASOS
406-255-2790
 126.3

Approach/Departure

APCH/P DEP/P
EAST
 119.2
APCH/P DEP/P IC
WEST
 120.5

Clearance Delivery

CD PRE TAXI CLNC
 121.9

Emergency

EMERG
 121.5

Ground

GND/P
 121.9

Tower

LCL/P
 127.2

Other

CLASS C
EAST
 119.2
CLASS C
WEST
 120.5

Terminal Area Forecast

KBIL
Mon, 12/2 4:34 AM MST
Mon, 12/2 5:00 AM MST - Tue, 12/3 5:00 AM MST
VFR
5:00 AM MST - 11:00 AM MST
Few 25,000'
6sm
120° 5kts
VFR
11:00 AM MST - 5:00 AM MST
Few 25,000'
6sm
230° 7kts
KBIL 021134Z 0212/0312 12005KT P6SM FEW250
   FM021800 23007KT P6SM FEW250
KBIL
Domestic
12/2/241400Z !BIL 11/131 BIL RWY 07 PAPI U/S DLY 1400-0030 2412021400-2412060030
11/26/240515Z !BIL 11/119 BIL OBST TOWER LGT (ASR 1020873) 454551.30N1082721.00W (4.5NM SE BIL) 3893.0FT (206.0FT AGL) U/S 2411260515-2412102359
11/24/240710Z !BIL 11/085 BIL OBST TOWER LGT (ASR 1239653) 454554.80N1082719.20W (4.5NM SE BIL) 4127.0FT (499.0FT AGL) U/S 2411240710-2412090610
11/22/240517Z !BIL 11/084 BIL OBST TOWER LGT (ASR 1214911) 454549.30N1082720.40W (4.5NM SE BIL) 4023.6FT (349.7FT AGL) U/S 2411220517-2412070417
11/9/240045Z !BIL 11/032 BIL OBST TOWER LGT (ASR 1220881) 454935.80N1083105.00W (1.6NM NE BIL) 3732.6FT (344.8FT AGL) U/S 2411090045-2503090045
10/27/242211Z !BIL 10/060 BIL OBST TOWER LGT (ASR 1228141) 455721.00N1080559.80W (20.5NM ENE BIL) 3296.9FT (265.1FT AGL) U/S 2410272211-2412112200
FDC
11/4/241400Z !FDC 4/8320 BIL IAP BILLINGS LOGAN INTL, BILLINGS, MT.
RNAV (GPS) RWY 10L, AMDT 4B...
LNAV MDA 4100/HAT 518 ALL CATS, VIS CAT C/D RVR 5000. CIRCLING CAT A/B MDA 4180/HAA 518. VDP: 1.40 NM TO RW10L. FOR ALS INOP, INCREASE LNAV VISIBILITY TO 1 3/8 SM. EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE UP TO 3863 MSL 1.0NM SW OF RWY 10L (2024-ANM-6331 TO 6333-OE).
2411041400-2503111704EST
11/4/241400Z !FDC 4/8319 BIL IAP BILLINGS LOGAN INTL, BILLINGS, MT.
VOR/DME RWY 28R, AMDT 14C...
CIRCLING CAT A MDA 4180/HAA 518, EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE UP TO 3863 MSL 1.5NM W OF BIL AIRPORT (2024-ANM-6331 TO 6333-OE).
2411041400-2503111704EST
11/4/241400Z !FDC 4/8318 BIL IAP BILLINGS LOGAN INTL, BILLINGS, MT.
ILS OR LOC RWY 28R, AMDT 3B...
ILS Y OR LOC Y RWY 10L, AMDT 26B...
RNAV (GPS) RWY 25, AMDT 2C...
RNAV (GPS) Y RWY 28R, AMDT 4B...
CIRCLING CAT A/B MDA 4180/HAA 518, EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE UP TO 3863 MSL 1.5NM W OF BIL AIRPORT (2024-ANM-6331 TO 6333-OE).
2411041400-2503111704EST
11/4/241400Z !FDC 4/8317 BIL IAP BILLINGS LOGAN INTL, BILLINGS, MT.
RNAV (GPS) RWY 7, AMDT 2B...
LPV MINIMUMS NOT AVAILABLE. LNAV/VNAV MINIMUMS NOT AVAILABLE. CIRCLING CAT A/B MDA 4180/HAA 518, EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE UP TO 3863 MSL 5240FT W OF RWY 7 (2024-ANM-6330 TO 6333-OE).
2411041400-2503111704EST
11/4/241400Z !FDC 4/8315 BIL SID BILLINGS LOGAN INTL, BILLINGS, MT.
BILLINGS FIVE DEPARTURE...
TAKEOFF MINIMUMS: RWY 25, 300-1 1/8 OR STANDARD WITH MINIMUM CLIMB OF 349FT PER NM TO 4000, EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE UP TO 3863 MSL 5240FT W OF RWY 7 (2024-ANM-6331 TO 6333-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2411041400-2503111704EST
11/4/241400Z !FDC 4/8314 BIL ODP BILLINGS LOGAN INTL, BILLINGS, MT.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 7A...
TAKEOFF MINIMUMS: RWY 25, 300-1 1/8 OR STANDARD WITH MINIMUM CLIMB OF 349FT PER NM TO 4000, EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE UP TO 3863 MSL 5240FT W OF RWY 7 (2024-ANM-6331 TO 6333-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2411041400-2503111704EST
Yes
ALL
CITY OF BILLINGS
CITY HALL
BILLINGS, MT 59101
Phone: 406-657-8495
JEFF ROACH, MANAGER
1901 TERMINAL CIRCLE DR., ROOM 216
BILLINGS, MT 59105
Phone: (406) 657-8484
GREAT FALLS FSS (GTF)
Toll Free: 1-800-WX-BRIEF
BIL
--
ATC-CTL. FOR MIRL RYS 10R/28L & 07/25; HIRL RY 10L/28R; MALSR RY 10L & REIL RYS 25 & 28R - CTC ATCT.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
High & Low Pressure
High & Low Pressure
Air Freight
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 07/25

5501 ft. x 75 ft.
ASPH
Good
GRVD
MED

12,000lbs
--
--
--
  Runway 07 Runway 25
True Heading 84°264°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 45° 48' 28"N 45° 48' 33"N
Longitude 108° 33' 30"W 108° 32' 13"W
Elevation 3,636' 3,534'
Threshold Crossing Height 31 ft. AGL 36 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes

Runway 10L/28R

10518 ft. x 150 ft.
ASPH
Good
GRVD
HIGH

120,000lbs
214,000lbs
365,000lbs
--
  Runway 10L Runway 28R
True Heading 111°291°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 45° 48' 46"N 45° 48' 07"N
Longitude 108° 33' 17"W 108° 30' 59"W
Elevation 3,584' 3,488'
Threshold Crossing Height 51 ft. AGL 56 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes

Runway 10R/28L

3800 ft. x 75 ft.
ASPH
Good
NONE
MED

12,000lbs
--
--
--
  Runway 10R Runway 28L
True Heading 111°291°
Traffic Pattern
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 45° 48' 37"N 45° 48' 23"N
Longitude 108° 33' 59"W 108° 33' 09"W
Elevation 3,662' 3,614'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-11TWY D 35 FT WIDE CLSD TO ACFT OVER 12,500 LBS.
A110-12NO CUSTOMS, REMOTE ACFT PARKING, LTD GROUND HANDLING SVCS
A110-2180 DEG TURNS PROHIBITED ON ALL SFCS.
A110-8MIGRATORY WATERFOWL INVOF ARPT.
A110-9RYS 07/25 AND 10R/28L CLSD TO ACFT OVER 12,500 LBS.
BILLINGS LOGAN INTL (ICAO: KBIL, IATA: BIL) is a public airport located in BILLINGS, MT.
