iFlightPlanner



...
BRAWLEY MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KBWC
ICAO KBWCIATA BWCLocal BWC
BRAWLEY MUNI
PublicPUB

1 miles NE of BRAWLEY, CA, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
32° 59' 35"N 115° 31' 02"W
Elevation
-128' MSL
Pattern Alt
872' MSL
Mag Variation
11°E
Declination
13°E
Fuel
JET A (FSII), 100LL
FSS
SAN DIEGO (SAN)
Sectional
LOS ANGELES
ARTCC
LOS ANGELES (ZLA)
Data Effective
4/16/26-5/14/26
KIPL (10nm) VFR
3:53 PM PDT
Clear
10sm
92°F
28°F
29.67"Hg
260° 15kts
Gusts 22kts
AO2 SLP048 T03331022
METAR KIPL 242253Z AUTO 26015G22KT 10SM CLR 33/M02 A2967 RMK AO2 SLP048 T03331022
+ Add Your Business

KBWC FBOs

Promote Listing
Imperial Flying Service
UNICOM: 122.9
Phone: (760) 344-4581
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 4/10
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 6.20
Full Serve 7.20
Fuel Notes
Prices include tax
Call ahead for JET A.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9
ACTVT REIL RWY 08 & 26; MIRL RWY 08/26; TWY LGTS - CTAF.

Center

YUMA CENTER 118.0
HIGH, USE: CD/P.
YUMA CENTER 132.275
LOW/HIGH, APCH/DEP SVC PRVDD BY YUMA CERAP (ZYL) ON FREQS 132.275/292.2 (EL CENTRO RCAG).

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

KIPL (10nm)
Fri, 4/24 10:35 AM PDT
Fri, 4/24 11:00 AM PDT - Sat, 4/25 11:00 AM PDT
VFR
11:00 AM PDT - 3:00 PM PDT
Few 25,000'
6sm
250° 7kts
VFR
3:00 PM PDT - 11:00 AM PDT
Scattered 25,000'
6sm
260° 13kts
Gusts 23kts
VFR
Temporary 6:00 PM PDT - 9:00 PM PDT
No Clouds
N/A
270° 18kts
Gusts 30kts
TAF KIPL 241735Z 2418/2518 25007KT P6SM FEW250
   FM242200 26013G23KT P6SM SCT250
   TEMPO 2501/2504 27018G30KT
KBWC
EffectiveExpiresCategoryNOTAM
Domestic
4/23/26
2333Z
4/27/26
2359Z
Runway!SAN 04/128 BWC RWY 26 RWY END ID LGT U/S 2604232333-2604272359
4/23/26
2328Z
4/27/26
2359Z
!SAN 04/124 BWC AD AP 100LL FUEL NOT AVBL 2604232328-2604272359
FDC
3/5/26
1243Z
!FDC 6/3922 BWC IAP BRAWLEY MUNI, BRAWLEY, CA.
RNAV (GPS) RWY 26, ORIG-B...
LNAV CAT C VISIBILITY 1 3/8. CHART PLANVIEW NOTE: FINAL APPROACH
COURSE OFFSET 15.03 DEGREES. CHART IPL ASOS.
THIS IS RNAV (GPS) RWY 26, ORIG-C. 2603051243-PERM
12/9/25
1327Z
!FDC 5/6343 BWC IAP BRAWLEY MUNI, BRAWLEY, CA.
VOR-B, AMDT 2D...
PROCEDURE NA.
2512091327-2607211327EST
No
UNATNDD
CITY OF BRAWLEY
400 MAIN STREET
BRAWLEY, CA 92227
Phone: 760-344-5800
ALAN CHAN
180 S. WESTERN AVENUE
BRAWLEY, CA 92227
Phone: 760-587-4122
SAN DIEGO FSS (SAN)
Toll Free: 1-800-WX-BRIEF
SAN
--
ACTVT REIL RWY 08 & 26; MIRL RWY 08/26; TWY LGTS - CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
None
Crop Dusting
Air Ambulance
Charter Service
Pilot Instruction
Aircraft Rental

Runway 08/26

4166 ft. x 60 ft.
ASPH
Good
NONE
MED

20,000lbs
--
--
--
  Runway 08 Runway 26
True Heading 90°270°
Traffic Pattern Left Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 32° 59' 35"N 32° 59' 35"N
Longitude 115° 31' 27"W 115° 30' 38"W
Elevation -128' -132'
Threshold Crossing Height 43 ft. AGL 43 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2R
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes
A110-1FOR CD CTC YUMA CERAP AT 928-269-9569.
A16PUBLIC WORKS DEPT OFFICE IN BRAWLEY
A57-08RWY 08 APCH RATIO 26:1 TO DSPLCD THR.
A57-26APCH RATIO TO DSPLCD THR +15 FT ROAD 510 FT FM DSPLCD THR 34:1.
A58-08RWY 08 +7 FT FENCE 170 FT FM END OF RY.
A58-26RY 26 +15 FT ROAD 115 FT FM RY END +7 FT FENCE 66 FT FM RY END.
A70-100LLFOR FUEL USE CARDLOCK-24/7.
A70-A+AFTER HRS ON-CALL 760-353-1182.
A81-APTACTVT REIL RWY 08 & 26; MIRL RWY 08/26; TWY LGTS - CTAF.
E147TPA 800' CONVENTIONAL ACFT; 1200 JET ACFT.
BRAWLEY MUNI (ICAO: KBWC, IATA: BWC) is a public airport located in BRAWLEY, CA, US.
