!FDC 3/7490 BXG PART 1 OF 3 ODP BURKE COUNTY, WAYNESBORO, GA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 8: TERRAIN 5 FT FROM DER, 315 FT LEFT
OF CENTERLINE, 313 FT MSL. TREE, VEGETATION BEGINNING 11 FT FROM
DER, 176 FT RIGHT OF CENTERLINE, UP TO 378 FT MSL. TERRAIN
BEGINNING 46 FT FROM DER, 189 FT LEFT OF CENTERLINE, UP TO 314 FT
MSL. TREE 114 FT FROM DER, 249 FT RIGHT OF CENTERLINE, 390 FT MSL.
TREES BEGINNING 143 FT FROM DER, 360 FT RIGHT OF CENTERLINE, UP TO
392 FT MSL. TERRAIN 151 FT FROM DER, 411 FT LEFT OF CENTERLINE, 315
FT MSL. TERRAIN BEGINNING 165 FT FROM DER, 188 FT LEFT OF
CENTERLINE, UP TO 316 FT MSL. TREE 236 FT FROM DER, 432 FT RIGHT OF
CENTERLINE, 394 FT MSL. TREE, POLE BEGINNING 255 FT FROM DER, 41 FT
RIGHT OF CENTERLINE, UP TO 396 FT MSL. TERRAIN 357 FT FROM DER, 208
FT LEFT OF CENTERLINE, 318 FT MSL. TREE, POLE BEGINNING 761 FT FROM
DER, 152 FT LEFT OF CENTERLINE, UP TO 371 FT MSL. TREES BEGINNING
1438 FT FROM DER, 98 FT LEFT OF CENTERLINE, UP TO 380 FT MSL. TREES
BEGINNING 1480 FT FROM DER, 96 FT LEFT OF CENTERLINE, UP TO 397 FT
MSL. TREES BEGINNING 1592 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP
TO 399 FT MSL. TREES BEGINNING 2857 FT FROM DER, 44 FT LEFT OF
CENTERLINE, UP TO 405 FT MSL. TREE 3359 FT FROM DER, 244 FT RIGHT
OF CENTERLINE, 397 FT MSL. RWY 26: TREE 6 FT FROM DER, 134 FT RIGHT
ALL OTHER DATA REMAINS AS PUBLISHED. 2311291714-2511291714EST
END PART 1 OF 3
!FDC 3/7490 BXG PART 2 OF 3 ODP BURKE COUNTY, WAYNESBORO, GA.
OF CENTERLINE, 296 FT MSL. TREES BEGINNING 62 FT FROM DER, 383 FT
LEFT OF CENTERLINE, UP TO 344 FT MSL. TREES BEGINNING 71 FT FROM
DER, 50 FT RIGHT OF CENTERLINE, UP TO 302 FT MSL. TREES BEGINNING
86 FT FROM DER, 151 FT LEFT OF CENTERLINE, UP TO 345 FT MSL. TREE
133 FT FROM DER, 458 FT RIGHT OF CENTERLINE, 326 FT MSL. TREES
BEGINNING 142 FT FROM DER, 6 FT RIGHT OF CENTERLINE, UP TO 330 FT
MSL. TREE 184 FT FROM DER, 538 FT LEFT OF CENTERLINE, 347 FT MSL.
TREES BEGINNING 195 FT FROM DER, 89 FT LEFT OF CENTERLINE, UP TO
358 FT MSL. TREES BEGINNING 211 FT FROM DER, 93 FT RIGHT OF
CENTERLINE, UP TO 357 FT MSL. TREES BEGINNING 299 FT FROM DER, 211
FT LEFT OF CENTERLINE, UP TO 362 FT MSL. TREES BEGINNING 539 FT
FROM DER, 333 FT RIGHT OF CENTERLINE, UP TO 363 FT MSL. TREE 794 FT
FROM DER, 485 FT LEFT OF CENTERLINE, 363 FT MSL. TREES BEGINNING
842 FT FROM DER, 343 FT LEFT OF CENTERLINE, UP TO 364 FT MSL. TREES
BEGINNING 949 FT FROM DER, 306 FT RIGHT OF CENTERLINE, UP TO 365 FT
MSL. TREES BEGINNING 998 FT FROM DER, 242 FT LEFT OF CENTERLINE, UP
TO 373 FT MSL. TREES BEGINNING 1070 FT FROM DER, 334 FT RIGHT OF
CENTERLINE, UP TO 367 FT MSL. TREES BEGINNING 1191 FT FROM DER, 348
FT LEFT OF CENTERLINE, UP TO 377 FT MSL. TREES BEGINNING 1283 FT
FROM DER, 356 FT RIGHT OF CENTERLINE, UP TO 369 FT MSL. TREES
ALL OTHER DATA REMAINS AS PUBLISHED. 2311291714-2511291714EST
END PART 2 OF 3
!FDC 3/7490 BXG PART 3 OF 3 ODP BURKE COUNTY, WAYNESBORO, GA.
BEGINNING 1371 FT FROM DER, 323 FT LEFT OF CENTERLINE, UP TO 380 FT
MSL. TREES BEGINNING 1529 FT FROM DER, 532 FT RIGHT OF CENTERLINE,
UP TO 371 FT MSL. TREES BEGINNING 1631 FT FROM DER, 411 FT LEFT OF
CENTERLINE, UP TO 386 FT MSL. TREE 1746 FT FROM DER, 559 FT RIGHT
OF CENTERLINE, 372 FT MSL. TREES BEGINNING 1754 FT FROM DER, 657 FT
LEFT OF CENTERLINE, UP TO 394 FT MSL. TREES BEGINNING 1815 FT FROM
DER, 311 FT RIGHT OF CENTERLINE, UP TO 376 FT MSL. TREES BEGINNING
1935 FT FROM DER, 362 FT RIGHT OF CENTERLINE, UP TO 386 FT MSL.
TREES BEGINNING 2027 FT FROM DER, 571 FT RIGHT OF CENTERLINE, UP TO
388 FT MSL. TREES BEGINNING 2164 FT FROM DER, 152 FT RIGHT OF
CENTERLINE, UP TO 393 FT MSL. TREES BEGINNING 2839 FT FROM DER, 96
FT RIGHT OF CENTERLINE, UP TO 402 FT MSL. TREES BEGINNING 3202 FT
FROM DER, 330 FT RIGHT OF CENTERLINE, UP TO 405 FT MSL. TREES
BEGINNING 3301 FT FROM DER, 495 FT LEFT OF CENTERLINE, UP TO 396 FT
MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2311291714-2511291714EST
