CESSNA ACFT FLD - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KCEA
ICAO KCEAIATA CEALocal CEA
CESSNA ACFT FLD
PublicPUB

4 miles SE of WICHITA, KS, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
37° 38' 55"N 97° 15' 02"W
Elevation
1378' MSL
Pattern Alt
2378' MSL
Mag Variation
3°E
Declination
8°E
Fuel
None Listed
FSS
WICHITA (ICT)
Sectional
WICHITA
ARTCC
KANSAS CITY (ZKC)
Data Effective
6/11/26-7/9/26
KBEC (3nm) VFR
4:35 PM CDT
Overcast 4,800'
Broken 4,000'
10sm
74°F
69°F
29.89"Hg
140° 7kts
AO2 LTG DSNT N AND NE T02350203
METAR KBEC 252135Z AUTO 14007KT 10SM BKN040 OVC048 24/20 A2989 RMK AO2 LTG DSNT N AND NE T02350203
+ Add Your Business

KCEA FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

Clearance

Clearance Delivery 125.0

Approach

WICHITA APPROACH 134.8

Departure

WICHITA DEPARTURE 134.8

FAA A/FD Pages

Instrument Approach

Terminal Area Forecast

KIAB
Thu, 6/25 1:00 PM CDT
Thu, 6/25 1:00 PM CDT - Fri, 6/26 7:00 PM CDT
MVFR
1:00 PM CDT - 2:00 PM CDT
Light Showers and Rain and Thunderstorm in vicinity
Overcast 10,000'
Broken 3,000'
Scattered 1,500'
5.59sm
29.91"Hg
VRB° 6kts
MVFR
Temporary 1:00 PM CDT - 2:00 PM CDT
Light Thunderstorm and Rain
Overcast 2,000'
Broken 1,000'
4.97sm
VRB° 10kts
Gusts 20kts
MVFR
Becoming 2:00 PM CDT - 7:00 PM CDT
Overcast 10,000'
Broken 2,500'
Scattered 1,200'
6sm
29.79"Hg
090° 7kts
MVFR
Becoming 7:00 PM CDT - 12:00 AM CDT
Light Showers and Rain and Thunderstorm in vicinity
Overcast 1,500'
Scattered 700'
5.59sm
29.79"Hg
090° 12kts
IFR
Temporary 8:00 PM CDT - 1:00 AM CDT
Thunderstorm and Rain
Overcast 1,000'
Broken 700'
1.99sm
VRB° 25kts
Gusts 40kts
MVFR
Becoming 12:00 AM CDT - 3:00 AM CDT
Overcast 4,000'
Broken 1,500'
Scattered 700'
6sm
29.79"Hg
070° 6kts
IFR
Becoming 3:00 AM CDT - 9:00 AM CDT
Mist
Overcast 500'
3.73sm
29.85"Hg
080° 5kts
MVFR
Becoming 9:00 AM CDT - 11:00 AM CDT
Overcast 18,000'
Broken 1,500'
6sm
29.82"Hg
040° 6kts
VFR
Becoming 11:00 AM CDT - 7:00 PM CDT
Broken 18,000'
Scattered 3,500'
6sm
29.70"Hg
070° 9kts
TAF KIAB 251800Z 2518/2624 VRB06KT 9000 -SHRA VCTS SCT015 BKN030CB OVC100 QNH2990INS
   TEMPO 2518/2519 VRB10G20KT 8000 -TSRA BKN010 OVC020CB
   BECMG 2519/2520 09007KT 9999 NSW SCT012 BKN025 OVC100 QNH2980INS
   BECMG 2600/2601 09012KT 9000 -SHRA VCTS SCT007 OVC015CB QNH2979INS
   TEMPO 2601/2606 VRB25G40KT 3200 TSRA BKN007 OVC010CB
   BECMG 2605/2606 07006KT 9999 NSW SCT007 BKN015 OVC040 QNH2979INS
   BECMG 2608/2609 08005KT 6000 BR OVC005 QNH2984INS
   BECMG 2614/2615 04006KT 9999 NSW BKN015 OVC180 QNH2982INS BEC
KCEA
No NOTAM Available
No
UNATNDD
CESSNA AIRCRAFT COMPANY
10511 EAST CENTRAL
WICHITA, KS 67277
Phone: 316-515-6000
TODD BAYLESS
10511 EAST CENTRAL
WICHITA, KS 67201
Phone: 316-515-8365
WICHITA FSS (ICT)
Toll Free: 1-800-WX-BRIEF
ICT
--
--
N/A
Yes
Yes
No
None
No
None
None
None
None
None

Runway 17/35

3873 ft. x 40 ft.
ASPH
Good
NONE


--
--
--
--
  Runway 17 Runway 35
True Heading 180°0°
Traffic Pattern Left Right
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 37° 39' 14"N 37° 38' 36"N
Longitude 97° 15' 02"W 97° 15' 02"W
Elevation 1,373' 1,373'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110*GTHIS AIRPORT HAS BEEN SURVEYED BY THE NATIONAL GEODETIC SURVEY.
A110-2ACFT OPNS SHOULD COORDINATE WITH MC CONNELL AFB PRIOR TO ARRIVAL AND DEP - CONTROL TOWER 127.25.
A110-3RWY 17R/35L USED ONLY BY CESSNA PERSONNEL; CLOSED TO PUBLIC.
A110-4FOR CD CTC WICHITA APCH AT 316-350-1520.
A57-17OBSTN CLNC SLP 20:1 TO DTHR OVR 23 FT TREE, 475 FT DSTC, 50 FT R.
A57-35OBSTN CLNC SLP 27:1 TO DTHR.
A58-358 FT FENCE 170 FT FM RWY END.
E111EXISTED PRIOR TO 1959.
CESSNA ACFT FLD (ICAO: KCEA, IATA: CEA) is a public airport located in WICHITA, KS, US.
