| Domestic |
|
3/29/240434Z
|
!COU 03/443 CHT OBST TOWER LGT (ASR 1215754) 394017.20N0932638.10W (7.1NM SSE CHT) 1236.9FT (419.0FT AGL) U/S 2403290434-2405130433
|
| FDC |
|
8/28/231935Z
|
!FDC 3/2514 CHT IAP CHILLICOTHE MUNI, CHILLICOTHE, MO.
RNAV (GPS) RWY 14, ORIG-B...
VGSI AND DESCENT ANGLES NOT COINCIDENT (VGSI ANGLE 3.00/TCH 40).
2308281935-2508281935EST
|
|
8/28/231927Z
|
!FDC 3/2507 CHT PART 1 OF 2 ODP CHILLICOTHE MUNI, CHILLICOTHE, MO.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT ...
NOTE: RWY 14: NAVAID 10 FT FROM DER, 16 FT LEFT OF CENTERLINE, 3 FT
AGL/765 FT MSL.
TREES BEGINNING 294 FT FROM DER, 277 FT LEFT OF CENTERLINE, UP TO
52 FT AGL/799 FT MSL.
TRAVERSE WAY BEGINNING 358 FT FROM DER, 428 FT RIGHT OF CENTERLINE,
UP TO 777 FT MSL.
TREES, POLES BEGINNING 392 FT FROM DER, 326 FT LEFT OF CENTERLINE,
UP TO 841 FT MSL.
NOTE: RWY 32: NAVAID 9 FT FROM DER, 18 FT RIGHT OF CENTERLINE, 9 FT
AGL/784 FT MSL.
TREE 141 FT FROM DER, 236 FT LEFT OF CENTERLINE, 788 FT MSL.
TRANSMISSION LINE 141 FT FROM DER, 368 FT LEFT OF CENTERLINE, 31 FT
AGL/792 FT MSL.
TRANSMISSION LINE 142 FT FROM DER, 368 FT LEFT OF CENTERLINE, 36 FT
AGL/797 FT MSL.
TREE 177 FT FROM DER, 479 FT RIGHT OF CENTERLINE, 38 FT AGL/807 FT
MSL.
TREE 271 FT FROM DER, 442 FT RIGHT OF CENTERLINE, 44 FT AGL/810 FT
MSL.
2308281927-2508281927EST
END PART 1 OF 2
!FDC 3/2507 CHT PART 2 OF 2 ODP CHILLICOTHE MUNI, CHILLICOTHE, MO.
TREES BEGINNING 353 FT FROM DER, 273 FT RIGHT OF CENTERLINE, UP TO
67 FT AGL/822 FT MSL.
TREES BEGINNING 529 FT FROM DER, 160 FT RIGHT OF CENTERLINE, UP TO
78 FT AGL/827 FT MSL.
TREES BEGINNING 792 FT FROM DER, 211 FT LEFT OF CENTERLINE, UP TO
833 FT MSL.
2308281927-2508281927EST
END PART 2 OF 2
|
