JOHN GLENN COLUMBUS INTL - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KCMH
JOHN GLENN COLUMBUS INTL
PublicPUB

6 miles E of COLUMBUS, OH
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
39° 59' 49"N 82° 53' 32"W
815' MSL
1815' MSL
07W
Jet A-1+, 100
DAYTON (DAY)
CINCINNATI
INDIANAPOLIS (ZID)
4/18/24-5/16/24
KCMH VFR
5:51 AM EDT
Overcast 3,200'
10sm
55°F
47°F
30.00"Hg
280° 6kts
AO2 SLP157 T01280083 $
KCMH 180951Z 28006KT 10SM OVC032 13/08 A3000 RMK AO2 SLP157 T01280083 $
List Your Business

KCMH FBOs, Flight Schools and Ground Support

Promote Listing
Signature Aviation
Freq: 129.62
Phone: (614) 238-3900
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 4/16
 100LL Jet A Jet A+ Mogas UL94
Self Serve
Full Serve 7.95 6.32
Promote Listing
Lane Aviation
Freq: 131.35
Phone: (614) 237-3747
No Rating Available
0 Reviews (Read | Sign In To Write)
Phillips 66
As of 3/31
 100LL Jet A Jet A+ Mogas UL94
Self Serve
Full Serve 7.99 5.91 5.96

KCMH Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

KCMH Hotels

No hotels are listed for this airport.

KCMH Restaurants

No restaurants are listed for this airport.

KCMH Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 --

ATIS

D-ATIS
 124.6

ASOS

ASOS
614-338-4083
 124.6

Approach/Departure

APCH/P DEP/P
100-279
 134.0
APCH/P DEP/P IC
280-099
 125.95

Clearance Delivery

CD/P
 126.3

Emergency

EMERG
 121.5

Ground

GND/P
 121.9

Tower

LCL/P
 132.7

Other

CBUSS STAR
 125.95
CLASS C
280-099
 125.95
CLASS C
100-279
 134.0
CLPRR STAR
 134.0
DUBLN STAR
 125.95
JAKTZ STAR
 134.0
OPS
DEICE PAD CONTROL
 122.775
SCRLT STAR
 134.0

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KCMH
Thu, 4/18 5:23 AM EDT
Thu, 4/18 5:00 AM EDT - Fri, 4/19 2:00 AM EDT
VFR
5:00 AM EDT - 9:00 AM EDT
Broken 3,500'
6sm
280° 6kts
VFR
9:00 AM EDT - 3:00 PM EDT
Sky Clear
6sm
290° 6kts
VFR
3:00 PM EDT - 8:00 PM EDT
Scattered 25,000'
6sm
230° 5kts
VFR
8:00 PM EDT - 2:00 AM EDT
Scattered 25,000'
6sm
140° 6kts
KCMH 180923Z 1809/1906 28006KT P6SM BKN035
   FM181300 29006KT P6SM SKC
   FM181900 23005KT P6SM SCT250
   FM190000 14006KT P6SM SCT250
KCMH
Domestic
4/17/240602Z !CMH 04/105 CMH OBST TOWER LGT (ASR 1210204) 400512.50N0824402.90W (9.1NM NE CMH) 1429.8FT (256.9FT AGL) U/S 2404170602-2408150602
4/16/241204Z !CMH 04/095 CMH NAV ILS RWY 10L LOC/GP/DME U/S 2404161204-2405172130
4/16/241203Z !CMH 04/094 CMH NAV ILS RWY 28R DME U/S 2404161203-2405172130
4/12/241312Z !CMH 04/074 CMH OBST TOWER LGT (ASR 1321855) 400316.81N0824406.31W (8.0NM ENE CMH) 1377FT (250FT AGL) U/S 2404121312-2405122300
4/11/242101Z !CMH 04/048 CMH TWY C9 CLSD TO ACFT WINGSPAN MORE THAN 118FT 2404112101-2411302300
4/11/240743Z !CMH 04/063 CMH APRON NORTH T HANGAR APN CL MARKINGS OBSC 2404110743-2404192200
4/9/241133Z !CMH 04/046 CMH OBST TOWER LGT (ASR 1053081) 400558.90N0824207.60W (10.7NM NE CMH) 1482.0FT (273.0FT AGL) U/S 2404091133-2408071133
3/25/241100Z !CMH 03/221 CMH TWY C9, D6 WIP HVY EQPT MON-FRI 1100-2300 2403251100-2410112300
3/22/241639Z !CMH 03/201 CMH TWY D6, C7, C8, TWY C BTN TWY C9 AND TWY C6 CLSD TO ACFT WINGSPAN MORE THAN 118FT 2403221639-2410092300
3/22/240423Z !CMH 03/195 CMH OBST TOWER LGT (ASN 2021-AGL-33781-OE) 400317N0824406W (8.0NM ENE CMH) 1377FT (250FT AGL) U/S 2403220423-2405060415
3/19/240920Z !CMH 03/168 CMH TWY C4 CL MARKINGS NOT STD 2403190920-2410311600
3/18/241600Z !CMH 03/144 CMH TWY C5, C6, TWY C BTN TWY C4 AND TWY D6, TWY D5 BTN TWY D AND TWY C CLSD 2403181600-2410092100
10/19/231409Z !CMH 10/149 CMH OBST TOWER LGT (ASR 1011189) 395707.00N0824529.00W (6.7NM ESE CMH) 1330.1FT (310.0FT AGL) U/S 2310191409-2404192359
FDC
4/10/241647Z !FDC 4/9158 CMH IAP JOHN GLENN COLUMBUS INTL, COLUMBUS, OH.
ILS OR LOC RWY 28R, AMDT 5...
S-LOC 28R MDA 1300/HAT 487 ALL CATS. CIRCLING CAT B MDA 1360/HAA 545. EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE 1054 MSL 1.8NM E OF RWY 28R (2023-AGL-21526-OE).
2404101647-2407151647EST
4/10/241645Z !FDC 4/9157 CMH IAP JOHN GLENN COLUMBUS INTL, COLUMBUS, OH.
RNAV (GPS) Y RWY 28L, AMDT 4...
LNAV/VNAV DA 1358/HAT 543 ALL CATS, VIS RVR 6000 ALL CATS. CIRCLING CAT B MDA 1360/HAA 545. EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE 1054 MSL 1.4NM E OF RWY 28L (2023-AGL-21526-OE).
2404101645-2407151645EST
4/10/241645Z !FDC 4/9156 CMH IAP JOHN GLENN COLUMBUS INTL, COLUMBUS, OH.
RNAV (GPS) Y RWY 28R, AMDT 3...
LNAV/VNAV DA 1114/HAT 301 ALL CATS. LNAV MDA 1320/HAT 507 ALL CATS. CIRCLING CAT B MDA 1360/HAA 545. TEMPORARY CRANE 1054 MSL 1.8NM E OF RWY 28R (2023-AGL-21526-OE). TEMPORARY CRANE 953 MSL 5562FT E OF RWY 28R (2023-AGL-21660-OE).
2404101645-2407151645EST
4/10/241644Z !FDC 4/9155 CMH IAP JOHN GLENN COLUMBUS INTL, COLUMBUS, OH.
ILS OR LOC RWY 10L, AMDT 20...
ILS OR LOC RWY 10R, AMDT 10...
ILS OR LOC RWY 28L, AMDT 31...
RNAV (GPS) Y RWY 10L, AMDT 4...
RNAV (GPS) Y RWY 10R, AMDT 4...
CIRCLING CAT B MDA 1360/HAA 545. EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN.TEMPORARY CRANE 1054 MSL 2.3NM E OF CMH AIRPORT (2023-AGL-21526-OE).
2404101644-2407151644EST
2/6/242120Z !FDC 4/2062 CMH ODP JOHN GLENN COLUMBUS INTL, COLUMBUS, OH.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 7A...
TAKEOFF MINIMUMS: RWY 10R, 300-1 3/4 OR STANDARD WITH MINIMUM CLIMB OF 224 FT PER NM TO 1200. TEMPORARY CRANE 1054 MSL 1.4NM E OF RWY 28L (2023-AGL-21526-OE). ADD TAKEOFF OBSTACLE NOTE: RWY 10L, TEMPORARY CRANE 5553FT FROM DER, 313FT RIGHT OF CENTERLINE, 140FT AGL/953FT MSL (2023-AGL-21660-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2402062120-2407152120EST
2/6/242120Z !FDC 4/2060 CMH IAP JOHN GLENN COLUMBUS INTL, COLUMBUS, OH.
RNAV (RNP) Z RWY 28L, AMDT 2A...
RNP 0.30 DA 1346/HAT 531 ALL CATS, VIS RVR 5500 ALL CATS. EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE 1054 MSL 1.4NM E OF RWY 28L (2023-AGL-21526-OE).
2402062120-2407152120EST
1/9/241200Z !FDC 4/1755 CMH IAP JOHN GLENN COLUMBUS INTL, COLUMBUS, OH.
RNAV (RNP) Z RWY 28R, AMDT 2...
RNP 0.16 DA 1177/HAT 364 ALL CATS, VIS RVR 3500 ALL CATS. RNP 0.30 DA 1232/HAT 419 ALL CATS, VIS RVR 4000 ALL CATS. FOR INOP ALS, INCREASE RNP 0.16 ALL CATS VISIBILITY TO RVR 5500 AND INCREASE RNP 0.30 ALL CATS VISIBILITY TO RVR 6000. EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE 953 MSL 5562FT E OF RWY 28R (2023-AGL-21660-OE).
2401091200-2407152122EST
6/29/230201Z !FDC 3/8393 CMH IAP JOHN GLENN COLUMBUS INTL, COLUMBUS, OH.
ILS RWY 10R (SA CAT I - II), AMDT 10 ...
ILS RWY 28L (SA CAT I - II), AMDT 31 ...
PROCEDURE NA EXC FOR RDO ALTIMETER TOLERANT ACFT AND ACFT USING APPROVED ALTERNATIVE METHODS OF COMPLIANCE DUE TO 5G C-BAND INTERFERENCE PLUS SEE AIRWORTHINESS DIRECTIVE 2023-10-02 AND 5G C-BAND DOMESTIC NOTICES. 2306290201-2506290149EST
Yes
ALL
COLUMBUS REGIONAL AIRPORT AUTH
4600 INTERNATIONAL GATEWAY
COLUMBUS, OH 43219
Phone: 614-239-4000
JOE NARDONE
COLUMBUS REGIONAL AIRPORT AUTHORITY, 4600 INTERNATIONAL GATEWAY
COLUMBUS, OH 43219
Phone: 614-239-4004
DAYTON FSS (DAY)
Toll Free: 1-800-WX-BRIEF
CMH
--
--
N/A
Yes
No
Yes
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
10
7
46
3
0
0
Major
Major
High & Low Pressure
None
Air Freight
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 10L/28R

8000 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
74 /F/C/X/T
120,000lbs
250,000lbs
419,000lbs
--
  Runway 10L Runway 28R
True Heading 94°274°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 40° 00' 12"N 40° 00' 06"N
Longitude 82° 54' 27"W 82° 52' 45"W
Elevation 815' 812'
Threshold Crossing Height 51 ft. AGL 50 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALSR MALSR
Centerline Lights
Runway End Identifier Lights No

Runway 10R/28L

10114 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
77 /F/C/W/T
120,000lbs
250,000lbs
424,000lbs
--
  Runway 10R Runway 28L
True Heading 94°274°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 39° 59' 37"N 39° 59' 30"N
Longitude 82° 54' 33"W 82° 52' 23"W
Elevation 805' 815'
Threshold Crossing Height 70 ft. AGL 68 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No No
A110-1MODEL ACFT TFC WITHIN A 1 NM RDS OF A POINT 8 NM ON A 010 DEG BRG FM THE ARPT; SFC - 5000 FT AGL; SR-SS DLY.
A110-12ALL SURFACES AROUND TERMINAL; NORTH OF TWY 'D' & SOUTH OF TWY 'E' ARE NON-MOVEMENT AREAS.
A110-18NOISE BARRIER LOCATED AT SE SIDE OF AIRFIELD RESTRICTED TO ACFT WITH WINGSPAN LESS THAN 79 FT.
A110-20TO REQ LDG RIGHTS CTC US CUSTOMS BETWEEN 1230-0300Z, MON-FRI AT 614-497-1865.
A110-21FLIGHT NOTIFICATION SERVICE (ADCUS) AVBL.
A110-26TWY F1 RSTRD TO AIRCRAFT WITH WINGSPAN LESS THAN 120 FT.
A110-3BIRDS INVOF ARPT.
A110-30TWYS R2, R3, R4, R5 AND R6 RSTRD TO WINGSPAN LESS THAN 118 FT.
A110-31TWY R1 RSTRD TO ACFT WITH WINGSPAN LESS THAN 79 FT.
A110-33TAXILANE CONCOURSE A BTN TWY D3 AND TWY D4 CLSD TO ACFT WINGSPAN MORE THAN 130 FT.
A110-34TAXILANE CONCOURSE C BTN TWY J AND TWY K CLSD TO ACFT WINGSPAN MORE THAN 135 FT.
A110-35HOLD PAD FOR RWY 28L RSTRD TO ACFT WITH WINGSPAN LESS THAN 118 FT.
A110-6TWY D-5 PAVEMENT (NORTH OF TWY D) IS RSTRD TO ACFT WITH WINGSPAN LESS THAN 79 FT.
A110-7BE ALERT: RY 10L/28R RESTRICTIONS ON STAGE I & II TURBOJET ACFT 2200-0800 & ON STAGE III TURBOJET ACFT 2200-0700. PRACTICE APCHS FOR HIGH NOISE LEVEL TYPE ACFT INCLUDING NON-STAGE III MIL JET ACFT SHALL NOT BE APPROVED UNLESS RY 10R/28L IS IN USE & THE APCH TERMINATES IN A FULL STOP TAXI-BACK OPN.
JOHN GLENN COLUMBUS INTL (ICAO: KCMH, IATA: CMH) is a public airport located in COLUMBUS, OH.
