DENVER INTL - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KDEN
DENVER INTL
PublicPUB

16 miles NE of DENVER, CO
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
39° 51' 42"N 104° 40' 23"W
5434' MSL
6434' MSL
08° E (2015)
Jet A, 100LL
DENVER (DEN)
DENVER
DENVER (ZDV)
9/10/20-10/8/20
KDEN VFR
5:53 PM MDT
Broken 22,000'
Broken 15,000'
Few 10,000'
10sm
80°F
34°F
30.10"Hg
190° 10kts
AO2 SLP116 T02670011 10306 20267 55002
KDEN 222353Z 19010KT 10SM FEW100 BKN150 BKN220 27/01 A3010 RMK AO2 SLP116 T02670011 10306 20267 55002

KDEN FBOs, Flight Schools and Ground Support

Signature Flight Support
Freq: 129.720
Phone: (303) 342-5600
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
Fuel as of 9/9 100LL SS-- 100LL FS$7.00 Jet A$6.65 Jet A+-- MoGas--

KDEN Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

KDEN Hotels

No hotels are listed for this airport.

KDEN Restaurants

No restaurants are listed for this airport.

KDEN Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.950 N/A

ATIS

D-ATIS
303-342-0819
125.600
D-ATIS
303-342-0819
134.025

Clearance Delivery

CD/P
118.750

Ground

GND/P
RWY 08/26, 17L/35R, 17R/35L
121.850
GND/P
RWY 07/25, 16L/34R, 16R/34L
127.500

Tower

LCL/P
RWY 07/25
128.750
LCL/P
RWY 08/26, 17L/35R
132.350
LCL/P
RWY 17R/35L
133.300
LCL/P
RWY 16L/34R, 16R/34L
135.300

Standard Term. Arrival

Instrument Approach

Terminal Area Forecast

KDEN
Tue, 9/22 5:38 PM MDT
Tue, 9/22 6:00 PM MDT - Thu, 9/24 12:00 AM MDT
VFR
6:00 PM MDT - 7:00 PM MDT
Showers in vicinity
Broken 15,000'
Scattered 9,000'
> 6sm
N/A
240° 12kts
Gusts 25kts
VFR
Temporary 6:00 PM MDT - 7:00 PM MDT
No Clouds
N/A
N/A
VRB° 15kts
Gusts 30kts
VFR
7:00 PM MDT - 8:00 PM MDT
Showers in vicinity
Broken 14,000'
Scattered 9,000'
> 6sm
N/A
VRB° 6kts
Gusts 15kts
VFR
8:00 PM MDT - 11:00 PM MDT
Broken 14,000'
Scattered 9,000'
> 6sm
N/A
150° 11kts
VFR
11:00 PM MDT - 10:00 AM MDT
Broken 22,000'
> 6sm
N/A
220° 10kts
VFR
10:00 AM MDT - 1:00 PM MDT
Scattered 22,000'
Few 12,000'
> 6sm
N/A
320° 9kts
VFR
1:00 PM MDT - 10:00 PM MDT
Scattered 12,000'
> 6sm
N/A
030° 11kts
VFR
10:00 PM MDT - 12:00 AM MDT
Scattered 12,000'
> 6sm
N/A
220° 10kts
KDEN 222338Z 2300/2406 24012G25KT P6SM VCSH SCT090 BKN150
   TEMPO 2300/2301 VRB15G30KT
   FM230100 VRB06G15KT P6SM VCSH SCT090 BKN140
   FM230200 15011KT P6SM SCT090 BKN140
   FM230500 22010KT P6SM BKN220
   FM231600 32009KT P6SM FEW120 SCT220
   FM231900 03011KT P6SM SCT120
   FM240400 22010KT P6SM SCT120
KDEN NOTAMs
Domestic
9/29/201500Z !DEN 09/564 DEN RWY 25 PAPI U/S 2009291500-2009291800
9/28/201500Z !DEN 09/563 DEN RWY 25 ALS U/S 2009281500-2009281800
9/24/200500Z !DEN 09/554 DEN NAV ILS RWY 25 U/S 2009240500-2009240700
9/24/200500Z !DEN 09/553 DEN NAV ILS RWY 07 U/S 2009240500-2009240700
9/23/200500Z !DEN 09/556 DEN NAV ILS RWY 34R DME U/S 2009230500-2009230700
9/23/200500Z !DEN 09/555 DEN NAV ILS RWY 16L U/S 2009230500-2009230700
9/22/200314Z !DEN 09/547 DEN TWY L EDGE LGT BTN TWY CS AND TWY CN U/S 2009220314-2009242359
9/21/201200Z !DEN 09/392 DEN TWY ALL RWY GUARD LGT FOR RWY 17R/35L U/S MON-FRI 1200-2359 2009211200-2010022359
9/17/201419Z !DEN 09/458 DEN TWY H CLSD ABEAM SPOT C4 2009171419-2009242359
9/16/201300Z !DEN 09/324 DEN OBST CRANE (ASN 2020-ANM-1606-NRA) 395117N1044053W (0.6NM SW DEN) 5510FT (135FT AGL) FLAGGED AND LGTD 2009161300-2103120130
9/16/201230Z !DEN 09/278 DEN OBST CRANE (ASN 2020-ANM-1603-NRA) 395130N1043954W (0.4NM ESE DEN) 5523FT (155FT AGL) FLAGGED AND LGTD 2009161230-2109160230
9/9/200800Z !DEN 09/062 DEN SVC CONCOURSE RAMP C S RAMP CTL 131.175 COMMISSIONED 2009090800-PERM
9/9/200800Z !DEN 09/061 DEN SVC CONCOURSE RAMP C S RAMP CTL 130.3 DECOMMISSIONED 2009090800-PERM
9/7/200330Z !DEN 09/148 DEN APRON CONCOURSE B SOUTH GREEN TXL BTN GATE B16
AND TWY H CLSD 2009070330-2010312359
9/6/200651Z !DEN 09/138 DEN OBST TOWER LGT (ASR 1218902) 394845.50N1044349.70W (3.9NM SW DEN) 5529.9FT (61.0FT AGL) U/S 2009060651-2012050400
9/3/200400Z !DEN 08/761 DEN OBST CRANE (ASN 2020-ANM-1552-NRA) 395130N1044023W (0.2NM S DEN) 5470FT (100FT AGL) FLAGGED AND LGTD 2009030400-2009301100
9/2/201930Z !DEN 09/069 DEN APRON CONCOURSE B NORTH GREEN TXL BTN GATE B11
AND TWY H CLSD 2009021930-2009300400
9/2/201918Z !DEN 09/067 DEN TWY K BTN TWY CS AND TWY AN CLSD TO ACFT WINGSPAN MORE THAN 79FT 2009021918-2010102359
9/1/201950Z !DEN 09/043 DEN TWY L BTN TWY CS AND TWY AN CLSD 2009011950-2010010500
9/1/201553Z !DEN 09/031 DEN TWY BS BTN TWY M AND TWY K CLSD 2009011553-2010010500
9/1/201552Z !DEN 09/030 DEN TWY BN BTN TWY M AND TWY K CLSD 2009011552-2010010500
9/1/201200Z !DEN 08/678 DEN OBST CRANE (ASN 2019-ANM-2260-NRA) 395148N1044017W (0.1NM NE DEN) 5575FT (210FT AGL) FLAGGED AND LGTD 2009011200-2103250230
8/28/201622Z !DEN 08/676 DEN OBST CRANE (ASN 2019-ANM-448-NRA) 395331N1044046W (1.8NM N DEN) 5535FT (185FT AGL) FLAGGED AND LGTD 2008281622-2009252300
8/28/201610Z !DEN 08/675 DEN OBST CRANE (ASN 2020-ANM-1602-NRA) 395135N1044003W (0.3NM ESE DEN) 5534FT (166FT AGL) FLAGGED AND LGTD 2008281610-2105270130
8/26/201200Z !DEN 08/501 DEN OBST CRANE (ASN 2020-ANM-1601-NRA) 395136N1043955W (0.4NM ESE DEN) 5540FT (173FT AGL) FLAGGED AND LGTD 2008261200-2108260030
8/25/201200Z !DEN 08/517 DEN OBST CRANE (ASN 2020-ANM-1604-NRA) 395130N1044004W (0.3NM SE DEN) 5580FT (210FT AGL) FLAGGED AND LGTD 2008251200-2107222359
8/19/201200Z !DEN 08/315 DEN OBST CRANE (ASN 2019-ANM-2259-NRA) 395145N1044017W (0.1NM NE DEN) 5565FT (200FT AGL) FLAGGED AND LGTD 2008191200-2103240230
8/19/201200Z !DEN 08/314 DEN OBST CRANE (ASN 2019-ANM-2257-NRA) 395145N1043958W (0.3NM E DEN) 5538FT (173FT AGL) FLAGGED AND LGTD 2008191200-2103240230
8/13/201200Z !DEN 08/175 DEN OBST CRANE (ASN 2019-ANM-2257-NRA) 395145N1043958W (0.3NM E DEN) 5475FT (110FT AGL) FLAGGED AND LGTD 2008131200-2103240230
8/3/201200Z !DEN 07/687 DEN OBST CRANE (ASN 2019-ANM-2258-NRA) 395148N1043958W (0.3NM ENE DEN) 5565FT (100FT AGL) FLAGGED AND LGTD 2008031200-2103240230
7/30/201010Z !DEN 07/683 DEN TWY R8 SOUTH OF TWY R CLSD FOR ACFT PRKG
2007301010-2010312359
7/30/201010Z !DEN 07/682 DEN TWY EE BTN TWY R8 AND TWY R9 CLSD FOR ACFT PRKG 2007301010-2010312359
7/30/201008Z !DEN 07/681 DEN APRON DEICE PAD EE CLSD FOR ACFT PRKG 2007301008-2010312359
7/30/201008Z !DEN 07/680 DEN TWY L NORTH OF TWY Z CLSD FOR ACFT PRKG
2007301008-2010312359
7/13/201200Z !DEN 07/159 DEN OBST CRANE (ASN 2019-ANM-2259-NRA) 395145N1044017W (0.1NM NE DEN) 5515FT (150FT AGL) FLAGGED AND LGTD 2007131200-2103250230
7/11/201324Z !DEN 07/200 DEN OBST RIG (ASN 2019-ANM-3057-NRA) 395123N1044222W (1.6NM WSW DEN) 5381FT (80FT AGL) FLAGGED AND LGTD 2007111324-2106022359
7/10/202120Z !DEN 07/189 DEN OBST RIG (ASN 2019-ANM-3342-NRA) 394935N1043960W (2.1NM S DEN) 5494FT (100FT AGL) FLAGGED AND LGTD 2007102120-2101312359
7/10/202119Z !DEN 07/188 DEN OBST RIG (ASN 2020-ANM-81-NRA) 394934N1044040W (2.1NM S DEN) 5473FT (100FT AGL) FLAGGED AND LGTD 2007102119-2108122359
7/10/202112Z !DEN 07/187 DEN OBST RIG (ASN 2019-ANM-2695-NRA) 395232N1044054W (0.9NM NNW DEN) 5437FT (90FT AGL) FLAGGED AND LGTD 2007102112-2104242359
6/29/201449Z !DEN 06/565 DEN OBST CRANE (ASN 2019-ANM-2163-NRA) 395123N1044231W (1.7NM W DEN) 5428FT (115FT AGL) FLAGGED AND LGTD 2006291449-2109301800
6/19/201633Z !DEN 06/359 DEN TWY BN BTN GATE B63 AND TWY L CL LGT NOT STD 2006191633-2010102300
6/11/201200Z !DEN 06/064 DEN OBST CRANE (ASN 2019-ANM-2258-NRA) 395148N1043958W (0.3NM ENE DEN) 5640FT (275FT AGL) FLAGGED AND LGTD 2006111200-2103250230
6/1/202208Z !DEN 06/009 DEN APRON CONCOURSE B NORTH GREEN TXL BTN GATE B11 AND GATE 35 CLSD TO ACFT WINGSPAN MORE THAN 118FT 2006012208-2009302359
5/23/201230Z !DEN 05/463 DEN OBST CRANE (ASN 2020-ANM-1601-NRA) 395136N1043955W (0.4NM ESE DEN) 5602FT (235FT AGL) FLAGGED AND LGTD 2005231230-2105240030
5/13/201150Z !DEN 05/283 DEN OBST CRANE (ASN 2019-ANM-1221-NRA) 395117N1044053W (0.6NM SW DEN) 5665FT (290FT AGL) FLAGGED AND LGTD 2005131150-2011012359
4/20/201200Z !DEN 04/427 DEN OBST CRANE (ASN 2019-ANM-1887-NRA) 395352N1044055W (2.2NM N DEN) 5394FT (60FT AGL) FLAGGED AND LGTD DLY 1200-0130 2004201200-2102280130
10/30/191405Z !DEN 10/048 DEN RWY 16L RTHL U/S 1910301405-2010072000EST
FDC
9/23/201400Z !FDC 0/8981 DEN SID DENVER INTL, DENVER, CO.
YELLOWSTONE FOUR DEPARTURE...
CHEYENNE TRANSITION: NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE
RNAV SYSTEM WITH GPS.
HANKI, LARAMIE, MEDICINE BOW, NATTI TRANSITIONS: DME REQUIRED
EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
CYS VOR OUT OF SERVICE. 2009231400-2009302100EST
9/22/201400Z !FDC 0/7811 DEN CANCELLED BY FDC 0/8941 ON 09/22/20 20:18
9/21/201400Z !FDC 0/7185 DEN CANCELLED BY FDC 0/8504 ON 09/22/20 14:48
9/18/201709Z !FDC 0/6621 DEN IAP DENVER INTL, DENVER, CO.
LANDR ONE ARRIVAL ...
DISREGARD NOTE: ADJACENT STAR IS SAYGE ARRIVAL.
2009181709-2209181709EST
9/17/201604Z !FDC 0/5653 DEN SID DENVER INTL, DENVER, CO.
EEONS SEVEN DEPARTURE (RNAV)...
EMMYS SEVEN DEPARTURE (RNAV)...
EXTAN SIX DEPARTURE (RNAV)...
CHANGE NOTE: ACCELERATE TO AT OR ABOVE 250K ABOVE 10000. IF SLOWER
SPEED IS REQUIRED TO MEET CROSSING RESTRICTIONS ADVISE CLNC DEL
PRIOR TO TAXI TO READ ACCELERATE TO 250K OR GREATER UPON REACHING
10000. IF SLOWER SPEED IS REQUIRED TO MEET CROSSING RESTRICTIONS,
ADVISE CLNC DEL PRIOR TO TAXI. 2009171604-2209181559EST
9/16/201811Z !FDC 0/4771 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 34L, AMDT 2C...
LNAV/VNAV DA 5714/ HAT 387 ALL CATS, VISIBILITY ALL CATS RVR 3500.
LNAV MDA 5820/ HAT 493 ALL CATS, VISIBILITY CAT C/D RVR 5000. VDP
1.25NM TO RW 34L. TEMPORARY CRANES UP TO 5503 MSL BEGINNING 1.04NM
SOUTHWEST OF RWY 34L (2020-ANM-555/556/557/558-NRA).
2009161811-2104111811EST
9/14/201921Z !FDC 0/2844 DEN SID DENVER INTL, DENVER, CO.
YELLOWSTONE FOUR DEPARTURE...
MEDICINE BOW TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE
RNAV SYSTEM WITH GPS.
NATTI TRANSITION DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH
SUITABLE RNAV SYSTEM WITH GPS,
MBW VOR/DME OUT OF SERVICE. 2009141921-2011181921EST
9/14/201305Z !FDC 0/2343 DEN IAP DENVER INTL, DENVER, CO.
RNAV (RNP) Z RWY 34R, ORIG-C...
RNP 0.10 DA 5906/ HAT 552 ALL CATS, VISIBILITY ALL CATS RVR 6000.
RNP 0.20 DA 6037/ HAT 683 ALL CATS, VISIBILITY ALL CATS 1 1/2. RNP
0.30 DA 6074/ HAT 720 ALL CATS, VISIBILITY ALL CATS 1 5/8. CHANGE
INOP NOTE TO READ: FOR INOPERATIVE ALSF, INCREASE RNP 0.10 ALL CATS
VISIBILITY TO 1 5/8 MILE, RNP 0.20 AND RNP 0.30 ALL CATS VISIBILITY
TO 2 MILES. TEMPORARY CRANES UP TO 5616 MSL 2215FT SOUTHEAST OF RWY
34R (2017-ANM-1749-NRA, 2018-ANM-1368-NRA), TEMPORARY CRANES UP TO
5619 MSL 3084FT SOUTHEAST OF RWY 34R (2017-ANM-1750-NRA,
2018-ANM-1369-NRA), TEMPORARY CRANES 5695 MSL BEGINNING 3778FT
SOUTHEAST OF RWY 34R (2019-ANM-1220/1221/1222/1223-NRA), TEMPORARY
CRANES 5620 MSL 1.10NM SOUTHEAST OF RWY 34R (2018-ANM-307/310-NRA).
2009141305-2010311304EST
9/8/201121Z !FDC 0/6276 DEN IAP DENVER INTL, DENVER, CO.
RNAV (RNP) Z RWY 16R, ORIG-C...
RNP 0.30 DA 5695/ HAT 369 ALL CATS. TEMPORARY CRANE 5535 MSL 4903FT
SOUTHEAST OF RWY 16R (2019-ANM-448/449/450/451-NRA).
2009081121-2010151121EST
9/8/201121Z !FDC 0/6275 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 16L, AMDT 1C...
LNAV/VNAV DA 5753/ HAT 396 ALL CATS, VISIBILITY ALL CATS RVR 3500.
LNAV MDA 5840/ HAT 483 ALL CATS, VISIBILITY CAT C/D RVR 5000. VDP
1.3 NM TO RW16L. DISREGARD LUWEE STEPDOWN FIX AND ALTITUDE IN
PLANVIEW AND PROFILE VIEW. CHANGE INOP NOTE TO READ: FOR
INOPERATIVE MALSR, INCREASE LNAV/VNAV ALL CATS VISIBILITY TO RVR
6000, AND LNAV CATS C/D VISIBILITY TO 1 3/8 SM. TEMPORARY CRANE
5535 MSL 2790FT SOUTHEAST OF RWY 16L
(2019-ANM-448/449/450/451-NRA).
2009081121-2010151121EST
9/8/201121Z !FDC 0/6274 DEN IAP DENVER INTL, DENVER, CO.
RNAV (RNP) Z RWY 16L, ORIG-C...
RNP 0.10 DA 5702/ HAT 345 ALL CATS, VISIBILITY ALL CATS RVR 3200.
RNP 0.30 DA 5702/ HAT 345 ALL CATS. CHANGE INOP NOTE TO READ: FOR
INOPERATIVE MALSR, INCREASE RNP 0.10 AND RNP 0.30 ALL CATS
VISIBILITY TO RVR 5000. TEMPORARY CRANE 5535 MSL 2790FT SOUTHEAST
OF RWY 16L (2019-ANM-448/449/450/451-NRA).
2009081121-2010151121EST
9/4/201128Z !FDC 0/4852 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 34R, AMDT 2B...
LNAV/VNAV DA 5993/ HAT 639 ALL CATS, VISIBILITY ALL CATS 1 3/8.
LNAV MDA 5960/ HAT 606 ALL CATS, VISIBILITY CAT C/D 1 3/8.
TEMPORARY CRANE 5601 MSL 2215FT SOUTHEAST OF RWY 34R
(2017-ANM-1749-NRA), TEMPORARY CRANE 5604 MSL 3084FT SOUTHEAST OF
RWY 34R (2017-ANM-1750-NRA), TEMPORARY CRANES 5695 MSL BEGINNING
3778FT SOUTHEAST OF RWY 34R (2019-ANM-1220/1221/1222/1223-NRA),
TEMPORARY CRANE 5620 MSL 1.10NM SOUTHEAST OF RWY 34R
(2018-ANM-307-NRA).
2009041128-2010311128EST
8/30/200400Z !FDC 0/0012 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 35L, AMDT 2B...
LNAV/VNAV DA 5754/ HAT 320 ALL CATS. LNAV MDA 5860/ HAT 426 ALL
CATS, VISIBILITY CAT C/D RVR 4000. VDP 1.10NM TO RW35L. TEMPORARY
CRANES UP TO 5542 MSL BEGINNING 1820FT SOUTHWEST OF RWY 35L
(2019-ANM-3337/3338/3339/3340-NRA), TEMPORARY CRANE 5538 MSL
1.26NM SOUTHEAST OF RWY 34L (2020-ANM-1853 THRU 1860-NRA).
2008300400-2104110400EST
8/30/200356Z !FDC 0/0009 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 25, AMDT 1B...
LNAV/VNAV DA 5787/ HAT 432 ALL CATS, VISIBILITY ALL CATS RVR 4000.
LNAV MDA 5880/ HAT 525 ALL CATS, VISIBILITY CAT C/D RVR 5500.
CHANGE INOP NOTE TO READ: FOR INOPERATIVE MALSR, INCREASE LNAV/VNAV
ALL CATS VISIBILITY TO 1 1/4 SM. TEMPORARY CRANES 5620 MSL 3688FT
NORTHEAST OF RWY 25 (2018-ANM-307/309/310-NRA).
TEMPORARY CRANE 5538 MSL 2569FT SOUTH OF RWY 25 (2020-ANM-1853 THRU
1860-NRA).
2008300356-2104110356EST
8/17/201101Z !FDC 0/3281 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 16R, AMDT 1D...
LNAV MDA 5720/ HAT 394 ALL CATS, VISIBILITY CAT C/D RVR 3500. VDP
0.96NM TO RW16R. TEMPORARY RIG 5405 MSL 1.40NM NORTH OF RWY 16R
(2018-ANM-332-NRA).
2008171101-2010311101EST
8/17/201101Z !FDC 0/3280 DEN IAP DENVER INTL, DENVER, CO.
RNAV (RNP) Z RWY 17L, ORIG-C...
RNP 0.30 DA 5786/ HAT 447 ALL CATS, VISIBILITY ALL CATS RVR 4500.
TEMPORARY RIG 5427 MSL 5585FT NORTHWEST OF RWY 17L
(2018-ANM-250-NRA).
2008171101-2010311101EST
8/17/201048Z !FDC 0/3258 DEN IAP DENVER INTL, DENVER, CO.
RNAV (RNP) Z RWY 35L, ORIG-C...
RNP 0.10 DA 5703/ HAT 269 ALL CATS. TEMPORARY CRANES UP TO 5542 MSL
BEGINNING 1820FT SOUTHWEST OF RWY 35L
(2019-ANM-3337/3338/3339/3340-NRA).
2008171048-2009301048EST
8/17/201044Z !FDC 0/3254 DEN SID DENVER INTL, DENVER, CO.
DENVER TWO DEPARTURE ...
PIKES TWO DEPARTURE ...
PLAINS ONE DEPARTURE ...
ROCKIES FIVE DEPARTURE ...
YELLOWSTONE THREE DEPARTURE ...
ADD TAKEOFF OBSTACLE NOTES: RWY 26, TEMPORARY CRANES BEGINNING
5459FT FROM DER, 40FT LEFT OF CENTERLINE, 150FT AGL/ UP TO 5503FT
MSL (2019-ANM-292 THRU 295-NRA). ALL OTHER DATA REMAINS AS
PUBLISHED. 2008171044-2009301044EST
8/17/201044Z !FDC 0/3253 DEN IAP DENVER INTL, DENVER, CO.
ILS OR LOC RWY 8, AMDT 5A...
S-ILS 8 DA 5788/HAT 434 ALL CATS. VIS ALL CATS RVR 4000.
S-LOC 8 MDA 5820/HAT 466 ALL CATS, VIS CATS A/B RVR 4000, CATS C/D
RVR 5000.
VDP AT I-FUI 1.07 DME; DISTANCE VDP TO THLD 1.25 MILES.
DISREGARD NOTE: ** RVR 1800 AUTHORIZED WITH USE OF FD OR AP OR HUD
TO DA.
FOR INOPERATIVE MALSR, INCREASE S-LOC 8 CAT A/B VISIBILITY TO RVR
5500 AND CAT C/D VISIBILITY TO 1 3/8.
TEMPORARY CRANES UP TO 5503 MSL BEGINNING 4420FT WEST OF RWY 8
(2019-ANM-292 THRU 295-NRA).
2008171044-2009301044EST
8/17/201044Z !FDC 0/3250 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 8, AMDT 1C...
LPV DA 5788/HAT 434 ALL CATS, VIS RVR 4000 ALL CATS.
LNAV MDA 5820/ HAT 466 ALL CATS. VIS CATS A/B RVR 4000, CATS C/D
RVR 5000.
VDP 1.13 NM TO RW08.
FOR INOPERATIVE MALSR, INCREASE LNAV CAT C/D VISIBILITY TO 1 3/8
MILE.
DISREGARD NOTE: ** RVR 1800 AUTHORIZED WITH USE OF FD OR AP OR HUD
TO DA.
TEMPORARY CRANES UP TO 5503 MSL BEGINNING 4420FT WEST OF RWY 8
(2019-ANM-292 THRU 295-NRA).
2008171044-2009301044EST
6/23/201824Z !FDC 0/2156 DEN ODP DENVER INTL, DENVER, CO.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3A...
ADD TAKEOFF OBSTACLE NOTES: RWY 8, TEMPORARY RIG 1398FT FROM DER,
502FT RIGHT OF CENTERLINE, 105FT AGL/ 5378FT MSL
(2017-ANM-1973-NRA). RWY 26, TEMPORARY CRANES BEGINNING 5459FT FROM
DER, 40FT LEFT OF CENTERLINE, 150FT AGL/ UP TO 5503FT MSL
(2019-ANM-292 THRU 295-NRA). ALL OTHER DATA REMAINS AS PUBLISHED.
2006231824-2102021824EST
6/23/201824Z !FDC 0/2153 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 26, AMDT 1C...
LPV DA 5613/HAT 304 ALL CATS, VISIBILITY ALL CATS RVR 2400.
LNAV/VNAV DA 5687/HAT 378 ALL CATS, VISIBILITY ALL CATS RVR 3500.
VDP NA. TEMPORARY RIG 5378 MSL 1485FT SOUTHEAST OF RWY 26
(2017-ANM-1973-NRA).
2006231824-2102021824EST
6/23/201824Z !FDC 0/2152 DEN IAP DENVER INTL, DENVER, CO.
RNAV (RNP) Z RWY 26, AMDT 1...
PROCEDURE NA. TEMPORARY RIG 5378 MSL 1485FT SOUTHEAST OF RWY 26
(2017-ANM-1973-NRA).
2006231824-2102021824EST
6/23/201824Z !FDC 0/2148 DEN IAP DENVER INTL, DENVER, CO.
ILS OR LOC RWY 26, AMDT 3A...
S-ILS 26 DA 5559/HAT 250 ALL CATS. FEETS FIX MINIMUMS: S-LOC 26 MDA
5680/ HAT 371 ALL CATS, VISIBILITY CATS C/D RVR 3500. VDP NA.
TEMPORARY RIG 5378 MSL 1485FT SOUTHEAST OF RWY 26
(2017-ANM-1973-NRA).
2006231824-2102021824EST
5/27/201107Z !FDC 0/3881 DEN IAP DENVER INTL, DENVER, CO.
ILS OR LOC RWY 17R, AMDT 3B...
S-ILS 17R, DA 5719/HAT 327 ALL CATS, VISIBILITY ALL CATS RVR 2600.
S-LOC 17R, MDA 5880/HAT 488 ALL CATS, VISIBILITY CATS C/D RVR 5000.
VDP AT I-ACX 1.18 DME; DISTANCE TO THLD 1.35NM.
CHANGE NOTE TO READ: FOR INOP ALS, INCREASE S-ILS 17R VISIBILITY
ALL CATS TO RVR 5000 AND S-LOC 17R CATS C/D VISIBILITY TO 1 3/8 SM.
TEMPORARY CRANES UP TO 5605 MSL BEGINNING 1501FT SOUTHWEST OF RWY
17R (2017-ANM-1601/1602/1603/1604/1698/1699/1700/1701-NRA).
2005271107-2106071107EST
5/27/201107Z !FDC 0/3880 DEN IAP DENVER INTL, DENVER, CO.
RNAV (GPS) Y RWY 17R, AMDT 1C...
LPV DA 5742/HAT 350 ALL CATS, VISIBILITY ALL CATS RVR 3000.
CHANGE NOTE TO READ: FOR INOPERATIVE MALSR, INCREASE LPV ALL CATS
VISIBILITY TO RVR 5500, LNAV/VNAV ALL CATS VISIBILITY TO 1 1/2 MILE
AND LNAV CAT C/D TO 1 1/2 MILE.
TEMPORARY CRANES UP TO 5605 MSL BEGINNING 1501FT SOUTHWEST OF RWY
17R (2017-ANM-1601/1602/1603/1604/1698/1699/1700/1701-NRA).
2005271107-2106071107EST
5/27/201104Z !FDC 0/3877 DEN IAP DENVER INTL, DENVER, CO.
RNAV (RNP) Z RWY 17R, ORIG-C...
RNP 0.10 DA 5876/HAT 484 ALL CATS. VIS RVR 5000 ALL CATS.
FOR INOPERATIVE MALSR, INCREASE RNP 0.10 ALL CATS VISIBILITY TO 1
3/8 MILE AND RNP 0.30 ALL CATS VISIBILITY TO 1 5/8 MILE.
TEMPORARY CRANES 5665 MSL BEGINNING 1768FT WEST OF RWY 17R
(2019-ANM-2257 THRU 2260-NRA), TEMPORARY CRANE 5600 MSL 1712FT WEST
OF RWY 17R (2017-ANM-1762-NRA), TEMPORARY CRANES, UP TO 5605 MSL
BEGINNING 1501FT SOUTHWEST OF RWY 17R
(2017-ANM-1601/1602/1603/1604/1698/1699/1700/1701-NRA).
2005271104-2106071104EST
3/26/200800Z !FDC 0/9843 DEN STAR DENVER INTL, DENVER, CO.
SSKII ONE ARRIVAL...
TAACO TRANSITION NOT AUTHORIZED
2003260800-PERM
3/26/200800Z !FDC 0/9842 DEN STAR DENVER INTL, DENVER, CO.
KOHOE FOUR ARRIVAL...
PROCEDURE "ATC ASSIGNED ONLY"
2003260800-PERM
7/24/191550Z !FDC 9/7216 DEN IAP DENVER INTL, Denver, CO.
ILS OR LOC RWY 34L, AMDT 2B...
S-LOC 34L MDA 5700/HAT 373 ALL CATS. VISIBILITY CATS C/D RVR 3500.
1907241550-2107241550EST
Yes
ALL
CITY & COUNTY OF DENVER
DEPT OF AVIATION
DENVER, CO 80249
Phone: 303-342-2200
KIM DAY
ADMIN BLDG, 8500 PENA BLVD
DENVER, CO 80249
Phone: (303) 342-2206
DENVER FSS (DEN)
Toll Free: 1-800-WX-BRIEF
DEN
Sunset to Sunrise
--
Clear-Green
Yes
No
Yes
Hangar
No
0
1
0
0
0
0
Major
Major
High Pressure
High Pressure
None

Runway 07/25

12000 ft. x 150 ft.
CONC
Good
GRVD
HIGH
92 /R/B/W/T
116000 lbs
240000 lbs
515000 lbs
1085000 lbs
  Runway 07 Runway 25
Runway Heading 90° 271°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 39° 50' 27"N 39° 50' 26"N
Longitude 104° 43' 36"W 104° 41' 02"W
Elevation 5350.2 ft. 5355 ft.
Threshold Crossing Height 68 ft. AGL 83 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4R P4L
Approach Lights MALSR MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 08/26

12000 ft. x 150 ft.
CONC
Good
GRVD
HIGH
92 /R/B/W/T
116000 lbs
240000 lbs
515000 lbs
1085000 lbs
  Runway 08 Runway 26
Runway Heading 91° 271°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 39° 52' 39"N 39° 52' 38"N
Longitude 104° 39' 44"W 104° 37' 10"W
Elevation 5354.3 ft. 5294.4 ft.
Threshold Crossing Height 70 ft. AGL 70 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights MALSR MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 16L/34R

12000 ft. x 150 ft.
CONC
Good
GRVD
HIGH
92 /R/B/W/T
116000 lbs
240000 lbs
515000 lbs
1085000 lbs
  Runway 16L Runway 34R
Runway Heading 181°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 39° 53' 49"N 39° 51' 51"N
Longitude 104° 41' 12"W 104° 41' 14"W
Elevation 5349.9 ft. 5353.7 ft.
Threshold Crossing Height 71 ft. AGL 63 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights MALSR ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 16R/34L

16000 ft. x 200 ft.
CONC
Good
GRVD
HIGH
92 /R/B/W/T
116000 lbs
240000 lbs
515000 lbs
1085000 lbs
  Runway 16R Runway 34L
Runway Heading 181°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 39° 53' 45"N 39° 51' 07"N
Longitude 104° 41' 46"W 104° 41' 48"W
Elevation 5321.8 ft. 5327 ft.
Threshold Crossing Height 71 ft. AGL 70 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4R P4L
Approach Lights MALSR ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 17L/35R

12000 ft. x 150 ft.
CONC
Good
GRVD
HIGH
92 /R/B/W/T
116000 lbs
240000 lbs
515000 lbs
1085000 lbs
  Runway 17L Runway 35R
Runway Heading 181°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 39° 51' 54"N 39° 49' 55"N
Longitude 104° 38' 29"W 104° 38' 30"W
Elevation 5328.1 ft. 5370 ft.
Threshold Crossing Height 66 ft. AGL 66 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4R
Approach Lights MALSR ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 17R/35L

12000 ft. x 150 ft.
CONC
Good
GRVD
HIGH
92 /R/B/W/T
116000 lbs
240000 lbs
515000 lbs
1085000 lbs
  Runway 17R Runway 35L
Runway Heading 181°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 39° 51' 40"N 39° 49' 42"N
Longitude 104° 39' 37"W 104° 39' 38"W
Elevation 5377.9 ft. 5433.8 ft.
Threshold Crossing Height 69 ft. AGL 71 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4R
Approach Lights MALSR ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights
A110-11ARPT MAINTAINS CLEARWAYS (500 FT X 1,000 FT, 1.25% SLOPE) ON DEP RY 08, RY 25, & RY 34R.
A110-12ASDE-X IN USE. OPERATE TRANSPONDERS WITH ALTITUDE REPORTING MODE AND ADS-B (IF EQUIPPED) ENABLED ON ALL AIRPORT SURFACES.
A110-14TWY F7 CLSD TO ACFT WINGSPAN MORE THAN 118 FT.
A110-3OVERHEAD PSGR BRIDGE ON SOUTH SIDE OF CONCOURSE 'A' PRVDS 42 FT TAIL & 118 FT WINGSPAN CLNC WHEN ON TWY CNTRLN.
A110-5CUSTOMS AVBL WITH PRIOR PERMISSION.
A110-6INFORMAL RY USE PROGRAM IS IN EFFECT 24 HRS A DAY. FOR ADDITIONAL NOISE ABATEMENT INFORMATION CONTACT AIRPORT MANAGEMENT AT 303-342-4200.
A110-8WATERFOWL AND MIGRATORY BIRD ACTIVITY INVOF ARPT YEAR ROUND.

View hangar and property listings at KDEN, provided by our partner Hangar Network.

KDEN
7850 Harry B. Combs Parkway
Denver, CO 80249
For Lease
Property Type Hangar
Hangar Size 21,620 sf
View Listing Details »
KDEN
7830 Harry B. Combs Pkwy
Hangar #South Hangar
Denver, CO 80249
For Lease
Property Type Hangar
Hangar Size 28,200 sf
Office Size 24,000 sf
View Listing Details »
KDEN
7830 Harry B Combs Parkway
Hangar #South Hangar Offices & Shop
Denver, CO 80249
For Lease
Property Type Office_shop
Office Size 24,000 sf
View Listing Details »
DENVER INTL (ICAO: KDEN, IATA: DEN) is a public airport located in DENVER, CO.
