DUPAGE - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KDPA
DUPAGE
PublicPUB

29 miles W of CHICAGO/WEST CHICAGO, IL
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
41° 54' 25"N 88° 14' 53"W
758' MSL
1758' MSL
01° W (1985)
Jet A, 100LL
KANKAKEE (IKK)
CHICAGO
CHICAGO (ZAU)
6/18/20-7/16/20
KDPA VFR
18:52 Z
Few 6,000'
10sm
90°F
65°F
30.00"Hg
Calm
AO2 SLP151 T03220183
KDPA 051852Z 00000KT 10SM FEW060 32/18 A3000 RMK AO2 SLP151 T03220183

KDPA FBOs, Flight Schools and Ground Support

DuPage Flight Center
Freq: 122.950
Phone: (630) 208-5600
No Rating Available
0 Reviews (Read | Sign In To Write)
Phillips 66
Fuel as of 7/1 100LL SS$4.57 100LL FS$5.64 Jet A$4.55 Jet A+$4.55 MoGas--

KDPA Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

KDPA Hotels

No hotels are listed for this airport.

KDPA Restaurants

No restaurants are listed for this airport.

KDPA Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.950 N/A

ATIS

ATIS
132.075

Clearance Delivery

CD/P
119.750

Ground

GND/P
121.800

Tower

LCL/P
120.900
LCL/S
124.500

Terminal Area Forecast

KDPA
17:20 Z
Sun, 7/5, 18:00 Z - Mon, 7/6, 18:00 Z
VFR
18:00 - 3:00 Z
Few 5,000'
> 6sm
N/A
040° 6kts
VFR
3:00 - 14:00 Z
Few 30,000'
> 6sm
N/A
Calm
VFR
14:00 - 18:00 Z
Few 30,000'
> 6sm
N/A
VRB° 3kts
KDPA 051720Z 0518/0618 04006KT P6SM FEW050
   FM060300 00000KT P6SM FEW300
   FM061400 VRB03KT P6SM FEW300
KDPA NOTAMs
Domestic
3/31/201400Z !DPA 03/017 DPA COM VOR VOICE 122.1 U/S 2003311400-2009302000EST
FDC
4/15/201900Z !FDC 0/4912 DPA IAP DUPAGE, CHICAGO/WEST CHICAGO, IL.
RNAV (GPS) RWY 20R, AMDT 1G...
CIRCLING CAT B MDA 1360/HAA 601. CIRCLING CAT C/D MDA 1460/HAA
701, VIS CAT C 2, VIS CAT D 2 1/4. ALTERNATE MINIMUMS: STANDARD
EXCEPT CAT D 800-2 1/4, NA WHEN LOCAL WEATHER NOT AVAILABLE.
2004151900-2204151900EST
4/15/201900Z !FDC 0/4911 DPA IAP DUPAGE, CHICAGO/WEST CHICAGO, IL.
RNAV (GPS) RWY 20L, ORIG-D...
CIRCLING CAT B MDA 1360/HAA 601. CIRCLING CAT C/D MDA 1460/HAA
701, VIS CAT C 2, VIS CAT D 2 1/4. ALTERNATE MINIMUMS: STANDARD
EXCEPT CAT D 800-2 1/4, NA WHEN LOCAL WEATHER NOT AVAILABLE.
CHANGE NOTE TO READ: WHEN LOCAL ALTIMETER SETTING NOT RECEIVED,
USE AURORA ALTIMETER SETTING AND INCREASE ALL MDA 40 FEET, AND
CIRCLING CAT C/D VISIBILITY 1/4 SM.
2004151900-2204151900EST
4/15/201900Z !FDC 0/4909 DPA IAP DUPAGE, CHICAGO/WEST CHICAGO, IL.
RNAV (GPS) RWY 10, ORIG-E...
CIRCLING CAT B MDA 1360/HAA 601. CIRCLING CAT C/D MDA 1460/HAA
701, VIS CAT C 2, VIS CAT D 2 1/4. ALTERNATE MINIMUMS: STANDARD
EXCEPT CAT D 800-2 1/4, NA WHEN LOCAL WEATHER NOT AVAILABLE.
CHANGE NOTE TO READ: WHEN LOCAL ALTIMETER SETTING NOT RECEIVED,
USE AURORA ALTIMETER SETTING AND INCREASE ALL DA 37 FEET AND ALL
MDA 40 FEET, INCREASE LNAV CAT D AND CIRCLING CAT C/D VISIBILITY
1/4 SM.
2004151900-2204151900EST
4/15/201900Z !FDC 0/4908 DPA IAP DUPAGE, CHICAGO/WEST CHICAGO, IL.
RNAV (GPS) RWY 2R, ORIG-D...
CIRCLING CAT B MDA 1360/HAA 601. CIRCLING CAT C/D MDA 1460/HAA
701, VIS CAT C 2, VIS CAT D 2 1/4. ALTERNATE MINIMUMS: STANDARD
EXCEPT CAT D 800-2 1/4, NA WHEN LOCAL WEATHER NOT AVAILABLE.
CHANGE NOTE TO READ: WHEN LOCAL ALTIMETER SETTING NOT RECEIVED,
USE AURORA ALTIMETER SETTING AND INCREASE ALL DA 37 FEET AND ALL
MDA 40 FEET; INCREASE LNAV/VNAV ALL CATS VISIBILITY 1/4 MILE, LNAV
CAT C/D VISIBILITY 1/8 SM, AND CIRCLING CAT C/D VISIBILITY 1/4 SM.
2004151900-2204151900EST
4/15/201900Z !FDC 0/4907 DPA IAP DUPAGE, CHICAGO/WEST CHICAGO, IL.
RNAV (GPS) RWY 2L, ORIG-E...
CIRCLING CAT B MDA 1360/HAA 601. CIRCLING CAT C/D MDA 1460/HAA
701, VIS CAT C 2, VIS CAT D 2 1/4. ALTERNATE MINIMUMS: STANDARD
EXCEPT CAT D 800-2 1/4, NA WHEN LOCAL WEATHER NOT AVAILABLE.
CHANGE NOTE TO READ: WHEN LOCAL ALTIMETER SETTING NOT RECEIVED,
USE AURORA ALTIMETER SETTING AND INCREASE ALL DA 37 FEET AND ALL
MDA 40 FEET; INCREASE LNAV/VNAV ALL CATS AND LNAV CAT C/D
VISIBILITY 1/8 SM, AND CIRCLING CAT C/D VISIBILITY 1/4 SM..
2004151900-2204151900EST
4/15/201900Z !FDC 0/4906 DPA IAP DUPAGE, CHICAGO/WEST CHICAGO, IL.
ILS OR LOC RWY 10, AMDT 8D...
CIRCLING CAT B MDA 1360/HAA 601. CIRCLING CAT C/D MDA 1460/HAA
701, VIS CAT C 2, VIS CAT D 2 1/4. HOVUB INT MINIMUMS: CIRCLING
CAT B MDA 1360/HAA 601. CIRCLING CAT C/D MDA 1460/HAA 701, VIS CAT
C 2, VIS CAT D 2 1/4.
ALTERNATE MINIMUMS: ILS: STANDARD; LOC: STANDARD EXCEPT CAT D
800-2 1/4, NA WHEN LOCAL WEATHER NOT AVAILABLE.
CHANGE NOTE TO READ: WHEN LOCAL ALTIMETER SETTING NOT RECEIVED,
USE CHICAGO/AURORA ALTIMETER SETTING AND INCREASE ALL DA 37 FEET
AND ALL MDA 40 FEET, AND INCREASE S-LOC 10 CATS C AND D AND HOVUB
INT MINIMUMS S-LOC 10 CATS C AND D VISIBILITY 1/8 SM, AND INCREASE
CIRCLING AND HOVUB INT MINIMUMS CIRCLING CATS C AND D VISIBILITY
1/4 SM.
2004151900-2204151900EST
Yes
ALL
DUPAGE ARPT AUTH
2700 INTERNATIONAL DRIVE STE 200
WEST CHICAGO, IL 60185-0787
Phone: 630-584-2211
MARK DOLES
2700 INT'L DRIVE, STE 200
WEST CHICAGO, IL 60185-0787
Phone: 630-584-2211
KANKAKEE FSS (IKK)
Toll Free: 1-800-WX-BRIEF
DPA
--
ATC-CTL
Clear-Green
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
160
31
60
4
0
0
Major
Major
High & Low Pressure
High & Low Pressure
Air Freight
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 02L/20R

7571 ft. x 150 ft.
CONC
Good
GRVD
HIGH

30000 lbs
45000 lbs
0 lbs
0 lbs
  Runway 02L Runway 20R
Runway Heading 14° 194°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 41° 53' 39"N 41° 54' 51"N
Longitude 88° 15' 13"W 88° 14' 49"W
Elevation 750.8 ft. 755.5 ft.
Threshold Crossing Height 0 ft. AGL 40 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L
Approach Lights MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 02R/20L

6451 ft. x 100 ft.
CONC
Good
GRVD
MED

30000 lbs
45000 lbs
0 lbs
0 lbs
  Runway 02R Runway 20L
Runway Heading 14° 194°
Traffic Pattern Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 41° 53' 36"N 41° 54' 38"N
Longitude 88° 14' 60"W 88° 14' 39"W
Elevation 750.5 ft. 758.5 ft.
Threshold Crossing Height 0 ft. AGL 0 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator
Approach Lights
Centerline Lights
Runway End Identifier Lights No No

Runway 10/28

4750 ft. x 75 ft.
ASPH
Good
GRVD
HIGH

30000 lbs
45000 lbs
0 lbs
0 lbs
  Runway 10 Runway 28
Runway Heading 96° 276°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 41° 54' 49"N 41° 54' 44"N
Longitude 88° 15' 31"W 88° 14' 28"W
Elevation 753.3 ft. 755.9 ft.
Threshold Crossing Height 50 ft. AGL 40 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator V4L P4L
Approach Lights RLLS
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 15/33

3399 ft. x 100 ft.
ASPH
Good

MED

30000 lbs
45000 lbs
100000 lbs
0 lbs
  Runway 15 Runway 33
Runway Heading 148° 328°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 41° 55' 09"N 41° 54' 41"N
Longitude 88° 14' 45"W 88° 14' 21"W
Elevation 756.9 ft. 757.6 ft.
Threshold Crossing Height 42 ft. AGL 0 ft. AGL
Visual Glide Path Angle 3.9°
Visual Slope Indicator P4R
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-1DEER, COYOTE, BIRDS & MIGRATORY WATERFOWL ON & INVOF ARPT.
A110-2ACFT ON SHORT FINAL TO RY 15 ARE NOT VSB FROM ATCT DUE TO TREES.
A110-3ARFF INDEX B PPR

View hangar and property listings at KDPA, provided by our partner Hangar Network.

KDPA
2727 Freedom Drive
West Chicago, IL 60185
For Lease
For Sale
Transient Space
Property Type Hangar
Office Size 9,000 sf
View Listing Details »
DUPAGE (ICAO: KDPA, IATA: DPA) is a public airport located in CHICAGO/WEST CHICAGO, IL.
