| Domestic |
|
3/18/241440Z
|
!DPL 03/004 DPL RWY 05 RWY END ID LGT U/S 2403181440-2406012100
|
|
3/18/241440Z
|
!DPL 03/003 DPL RWY 05 PAPI U/S 2403181440-2406012100
|
|
2/23/240400Z
|
!DPL 02/004 DPL OBST TOWER LGT (ASR 1065422) 345541.40N0780321.10W (5.7NM SW DPL) 544.0FT (419.0FT AGL) U/S 2402230400-2405220500
|
|
5/30/231716Z
|
!DPL 05/013 DPL AD AP ALL SFC WIP GRASS CUTTING 2305301716-PERM
|
| FDC |
|
12/21/232001Z
|
!FDC 3/8623 DPL PART 1 OF 2 ODP DUPLIN COUNTY, KENANSVILLE, NC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 5, SIGN 12 FT FROM DER, 99 FT RIGHT OF
CENTERLINE, 3 FT AGL/138 FT MSL.
TREES BEGINNING 134 FT FROM DER, 501 FT LEFT OF CENTERLINE, UP TO
180 FT MSL.
TREE 194 FT FROM DER, 515 FT RIGHT OF CENTERLINE, 175 FT MSL.
TREES BEGINNING 1092 FT FROM DER, 579 FT RIGHT OF CENTERLINE, UP TO
215 FT MSL.
RWY 23: TERRAIN 6 FT FROM DER, 392 FT LEFT OF CENTERLINE, 146 FT
MSL.
TREES BEGINNING 57 FT FROM DER, 491 FT LEFT OF CENTERLINE, UP TO 32
FT AGL/174 FT MSL.
TREE 115 FT FROM DER, 491 FT RIGHT OF CENTERLINE, 169 FT MSL.
TREE 174 FT FROM DER, 493 FT RIGHT OF CENTERLINE, 53 FT AGL/180 FT
MSL.
TREE 387 FT FROM DER, 538 FT RIGHT OF CENTERLINE, 208 FT MSL.
TREES BEGINNING 507 FT FROM DER, 578 FT RIGHT OF CENTERLINE, UP TO
85 FT AGL/210 FT MSL.
TREES BEGINNING 664 FT FROM DER, 578 FT RIGHT OF CENTERLINE, UP TO
86 FT AGL/212 FT MSL.
2312212001-2512212001EST
END PART 1 OF 2
!FDC 3/8623 DPL PART 2 OF 2 ODP DUPLIN COUNTY, KENANSVILLE, NC.
TREES BEGINNING 690 FT FROM DER, 654 FT LEFT OF CENTERLINE, UP TO
76 FT AGL/194 FT MSL.
TREES BEGINNING 1095 FT FROM DER, 633 FT RIGHT OF CENTERLINE, UP TO
86 FT AGL/214 FT MSL.
TREES BEGINNING 1314 FT FROM DER, 749 FT LEFT OF CENTERLINE, UP TO
198 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED..
2312212001-2512212001EST
END PART 2 OF 2
|
