DETROIT METRO WAYNE COUNTY - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KDTW
ICAO KDTWIATA DTWLocal DTW
DETROIT METRO WAYNE COUNTY
PublicPUB

15 miles S of DETROIT, MI, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
42° 12' 45"N 83° 21' 12"W
Elevation
645' MSL
Pattern Alt
1645' MSL
Mag Variation
7°W
Declination
7°W
Fuel
JET A, 100LL
FSS
LANSING (LAN)
Sectional
DETROIT
ARTCC
CLEVELAND (ZOB)
Data Effective
8/6/26-9/3/26
KDTW VFR
1:53 AM EDT
Scattered 23,000'
10sm
63°F
56°F
30.06"Hg
310° 3kts
AO2 SLP176 T01720133 10228 20172 52003 $
METAR KDTW 250553Z 31003KT 10SM SCT230 17/13 A3006 RMK AO2 SLP176 T01720133 10228 20172 52003 $
+ Add Your Business

KDTW FBOs

Promote Listing
Signature Aviation
ASRI: 129.95, UNICOM: 122.77
Phone: (734) 941-7880
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 8/24
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 8.65 9.18
Fuel Notes
Prices include tax

KDTW Aircraft Service & Maintenance

Promote Listing
Liebherr
Phone: (734) 429-7225
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

Digital ATIS 118.125
DEP
Digital ATIS 133.675
ARR
ASOS (231) 202-2054

Common

UNICOM 122.95

Clearance

METRO CLEARANCE DELIVERY 120.65

Ground

METRO GROUND 119.25
SOUTHEAST
METRO GROUND 119.45
NORTHEAST
METRO GROUND 121.8
NORTHWEST
METRO GROUND 132.725
SOUTHWEST

Tower

METRO TOWER 118.4
ARRIVAL RWY 03R/21L, 27R
METRO TOWER 118.4
DEP, ARPT DIAG RWY 03L/21R, 03R/21L, 27R
METRO TOWER 128.125
ARRIVAL RWY 04R/22L
METRO TOWER 128.75
ARRIVAL RWY 03L/21R, 27L
METRO TOWER 128.75
DEP, ARPT DIAG RWY 27L
METRO TOWER 135.0
ARRIVAL RWY 04L/22R
METRO TOWER 135.0
DEP, ARPT DIAG RWY 04L/22R, 04R/22L

Arrival

BONZZ STAR 126.225
CRAKN STAR 126.225
CUUGR STAR 126.225
FERRL STAR 126.225
GRAYT STAR 124.975
HANBL STAR 124.975
HAYLL STAR 124.975
HTROD STAR 126.225
KKISS STAR 124.975
KLYNK STAR 126.225
LAYKS STAR 124.975
LECTR STAR 124.975
RKCTY STAR 124.975
TPGUN STAR 126.225
VCTRZ STAR 124.975
WNGNT STAR 126.225

Approach

DETROIT APPROACH 124.05
RWY 04L/22R, 04R/22L, 27L
DETROIT APPROACH 125.15
RWY 03R, 21L, 27R

Departure

BARII DP 125.525
RWY 04L/22R, 04R/22L
BARII DP 132.025
RWY 03L/21R, 03R/21L, 27L, 27R
CCOBB DP 125.525
RWY 03L, 03R, 04L, 04R, 21L, 21R, 22L, 22R
CCOBB DP 132.025
RWY 27L, 27R
CLVIN DP 125.525
RWY 04L/22R, 04R/22L
CLVIN DP 132.025
RWY 03L/21R, 03R/21L, 27L, 27R
DETROIT DEPARTURE 118.95
PROPS/TURBOPROPS-WEST
DETROIT DEPARTURE 125.525
TURBOJETS-WEST
DETROIT DEPARTURE 132.025
TURBOJETS-EAST
DETROIT DEPARTURE 134.3
PROPS/TURBOPROPS-EAST
HHOWE DP 125.525
RWY 27L, 27R
HHOWE DP 132.025
RWY 03L/21R, 03R/21L, 04L/22R, 04R/22L
KAYLN DP 125.525
KZLOV DP 132.025
LIDDS DP 132.025
METRO DP 118.95
WESTBOUND
METRO DP 134.3
EASTBOUND
MIGGY DP 125.525
PAVYL DP 132.025
SNDRS DP 125.525
RWY 04L/22R, 04R/22L
SNDRS DP 132.025
RWY 03L/21R, 03R/21L, 27L, 27R
TRMML DP 125.525
RWY 22L, 22R, 27L, 27R
TRMML DP 132.025
RWY 03L, 03R, 04L, 04R, 21L, 21R
ZETTR DP 125.525
RWY 22L, 22R, 27L, 27R
ZETTR DP 132.025
RWY 03L, 03R, 04L, 04R, 21L, 21R

RADAR

Precision Runway Monitor (PRM) 127.05
RWY 04L/22R
Precision Runway Monitor (PRM) 135.775
RWY 04R/22L

Emergency

Emergency 121.5

Other

CLASS B 118.95
SW
CLASS B 132.35
NW/NE
CLASS B 134.3
SE

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

Instrument Approach

Terminal Area Forecast

KDTW
Tue, 8/25 1:20 AM EDT
Tue, 8/25 2:00 AM EDT - Wed, 8/26 8:00 AM EDT
VFR
2:00 AM EDT - 11:00 AM EDT
Scattered 25,000'
6sm
300° 5kts
VFR
11:00 AM EDT - 4:00 PM EDT
Scattered 3,500'
6sm
260° 7kts
VFR
4:00 PM EDT - 9:00 PM EDT
Broken 25,000'
Scattered 4,500'
6sm
170° 7kts
VFR
9:00 PM EDT - 8:00 AM EDT
Broken 25,000'
6sm
180° 5kts
TAF KDTW 250520Z 2506/2612 30005KT P6SM SCT250
   FM251500 26007KT P6SM SCT035
   FM252000 17007KT P6SM SCT045 BKN250
   FM260100 18005KT P6SM BKN250
KDTW
EffectiveExpiresCategoryNOTAM
Domestic
8/31/26
0400Z
9/25/26
2200Z
Runway!DTW 08/388 DTW RWY 04L PAPI U/S 2608310400-2609252200
8/31/26
0400Z
9/25/26
2200Z
Runway!DTW 08/387 DTW RWY 22R PAPI U/S 2608310400-2609252200
8/31/26
0400Z
9/25/26
2200Z
Runway!DTW 08/386 DTW RWY 04L ALS U/S 2608310400-2609252200
8/31/26
0400Z
9/25/26
2200Z
Runway!DTW 08/385 DTW RWY 22R ALS U/S 2608310400-2609252200
8/31/26
0400Z
9/25/26
2200Z
!DTW 08/384 DTW NAV ILS RWY 04L CAT II NA 2608310400-2609252200
8/31/26
0230Z
9/25/26
0630Z
!DTW 08/380 DTW NAV BZB ILS RWY 22R U/S 2608310230-2609250630
8/31/26
0230Z
9/25/26
0630Z
!DTW 08/379 DTW NAV ALA ILS RWY 04L U/S 2608310230-2609250630
8/31/26
0230Z
9/25/26
0630Z
!DTW 08/378 DTW NAV ILS RWY 04L U/S 2608310230-2609250630
8/31/26
0230Z
9/25/26
0630Z
!DTW 08/377 DTW NAV ILS RWY 22R U/S 2608310230-2609250630
8/26/26
0000Z
8/26/26
0400Z
!DTW 08/263 DTW NAV ILS RWY 04L U/S 2608260000-2608260400
8/25/26
1315Z
8/25/26
1500Z
!DTW 08/399 DTW NAV ILS RWY 21L U/S 2608251315-2608251500
8/25/26
1300Z
8/25/26
2000Z
!DTW 08/398 DTW SVC MBST/WS DETECTION SYSTEM NOT AVBL 2608251300-2608252000
8/25/26
0439Z
8/25/26
0915Z
!DTW 08/410 DTW TWY Z BTN TWY V AND TWY Z5 CLSD 2608250439-2608250915
8/25/26
0439Z
8/25/26
0915Z
!DTW 08/409 DTW TWY V1 CLSD 2608250439-2608250915
8/25/26
0438Z
8/25/26
0915Z
!DTW 08/408 DTW TWY P BTN TWY P4 AND RWY 09L/27R CLSD 2608250438-2608250915
8/25/26
0409Z
8/25/26
0915Z
Runway!DTW 08/407 DTW RWY 04R/22L CLSD 2608250409-2608250915
8/25/26
0327Z
8/25/26
0915Z
Runway!DTW 08/406 DTW RWY 04L/22R CLSD 2608250327-2608250915
8/25/26
0312Z
8/25/26
0915Z
!DTW 08/405 DTW TWY V BTN TWY M AND TWY P CLSD 2608250312-2608250915
8/25/26
0311Z
8/25/26
0915Z
Runway!DTW 08/404 DTW RWY 03L/21R CLSD 2608250311-2608250915
8/24/26
2055Z
8/25/26
0900Z
!DTW 08/402 DTW AD AP BIRD ACT INCREASED BLACKBIRDS W SIDE 2608242055-2608250900
8/24/26
1803Z
8/31/26
2359Z
!DTW 08/401 DTW TWY B SFC PAINTED HLDG PSN SIGNS FOR RWY 09L/27R NORTH SIDE NOT STD 2608241803-2608312359
8/24/26
1728Z
12/31/26
2359Z
Runway!DTW 08/400 DTW RWY 09L/27R CLSD EXC TAX 45MIN PPR 734-942-3685 2608241728-2612312359
8/24/26
0401Z
9/25/26
2359Z
!DTW 08/389 DTW TWY Q BTN TWY A AND TWY T CLSD 2608240401-2609252359
8/23/26
1004Z
11/27/26
2359Z
!DTW 08/350 DTW NAV ILS RWY 27L U/S 2608231004-2611272359
8/23/26
0320Z
9/30/26
0400Z
Runway!DTW 08/342 DTW RWY 09R/27L CLSD EXC 2HR PPR 734-942-3685 2608230320-2609300400
8/22/26
1651Z
9/30/26
2359Z
!DTW 08/318 DTW TWY T3 CLSD 2608221651-2609302359
8/14/26
1200Z
8/28/26
2230Z
!DTW 08/210 DXO AIRSPACE UAS WI AN AREA DEFINED AS 1NM RADIUS OF 422015N0830103W (4.6NM S DET) SFC-200FT AGL DLY 1200-2230 2608141200-2608282230
8/5/26
2125Z
4/1/29
0359Z
!DTW 08/056 DTW OBST CRANE (ASN 2025-AGL-7725-OE) 421540N0831723W (4.1NM NE DTW) 780FT (147FT AGL) FLAGGED AND LGTD 2608052125-2904010359
8/2/26
2001Z
10/1/26
0400Z
!DTW 08/033 DTW APRON TXL J11 EAST SIDE DEICE FREQ SIGN MISSING 2608022001-2610010400
7/30/26
2317Z
Runway!DTW 07/479 DTW RWY 09R RWY END ID LGT U/S 2607302317-2610292000EST
7/27/26
1250Z
11/19/26
2359Z
!DTW 07/428 DTW APRON DEICE PAD FOR RWY 04R SPOT 6 CLSD 2607271250-2611192359
7/27/26
1036Z
11/19/26
2359Z
!DTW 07/419 DTW TWY Y BTN TWY K2 AND TWY U WIP CONST ADJ EAST SIDE LGTD AND BARRICADED 2607271036-2611192359
7/27/26
1035Z
11/19/26
2359Z
!DTW 07/418 DTW TWY T BTN TWY Q AND TWY K CLSD 2607271035-2611192359
7/27/26
1033Z
11/19/26
2359Z
!DTW 07/416 DTW TWY K CLSD TO ACFT WINGSPAN MORE THAN 118FT BTN TWY R AND GATE B12 2607271033-2611192359
7/27/26
1032Z
11/19/26
2359Z
!DTW 07/415 DTW TWY Y BTN TWY R AND TWY U CLSD TO ACFT WINGSPAN MORE THAN 135FT 2607271032-2611192359
7/27/26
1032Z
11/19/26
2359Z
!DTW 07/414 DTW TWY Y3, Y4 CLSD TO ACFT WINGSPAN MORE THAN 135FT 2607271032-2611192359
7/27/26
1032Z
11/19/26
2359Z
!DTW 07/413 DTW TWY R BTN TWY K AND TWY Y CLSD TO ACFT WINGSPAN MORE THAN 135FT 2607271032-2611192359
7/27/26
1032Z
11/19/26
2359Z
!DTW 07/412 DTW APRON DEICE PAD FOR RWY 04R SPOT 1, DEICE PAD FOR RWY 04R SPOT 2, DEICE PAD FOR RWY 04R SPOT 3, DEICE PAD FOR RWY 04R SPOT 4, DEICE PAD FOR RWY 04R SPOT 5 CLSD TO ACFT WINGSPAN MORE THAN 135FT 2607271032-2611192359
7/27/26
1031Z
11/19/26
2359Z
!DTW 07/417 DTW APRON DEICE PAD FOR RWY 04R SPOT 1H CLSD 2607271031-2611192359
7/27/26
1031Z
11/19/26
2359Z
!DTW 07/410 DTW TWY K2, K3, K4 CLSD 2607271031-2611192359
7/27/26
1029Z
11/19/26
2359Z
!DTW 07/409 DTW TWY K CLSD BTN GATE B12 AND TWY U 2607271029-2611192359
7/27/26
1027Z
11/19/26
2300Z
!DTW 07/408 DTW TWY K BTN DEICE PAD FOR RWY 04R SPOT 1 AND TWY R CLSD TO ACFT WINGSPAN MORE THAN 135FT 2607271027-2611192300
7/22/26
0049Z
9/24/26
2000Z
Runway!DTW 07/347 DTW RWY 27R ALS U/S 2607220049-2609242000
7/22/26
0043Z
9/24/26
2000Z
Runway!DTW 07/345 DTW RWY 27R PAPI U/S 2607220043-2609242000
7/20/26
1021Z
10/9/27
2359Z
!DTW 07/317 DTW OBST TOWER (ASN 2026-AGL-5026-OE) 421438N0831937W (2.2NM NNE DTW) 713FT (82FT AGL) NOT LGTD 2607201021-2710092359
7/20/26
0943Z
11/19/26
2359Z
!DTW 07/307 DTW TWY K BTN TWY J AND TWY T CLSD 2607200943-2611192359
7/20/26
0941Z
11/19/26
2359Z
!DTW 07/305 DTW TWY Y1 CLSD 2607200941-2611192359
7/20/26
0941Z
11/19/26
2359Z
!DTW 07/304 DTW TWY K BTN DEICE PAD FOR RWY 04R SPOT 1 AND TWY J CLSD 2607200941-2611192359
6/30/26
1059Z
12/31/26
2200Z
Runway!DTW 06/453 DTW RWY 22L ALS U/S 2606301059-2612312200
6/29/26
1959Z
9/30/26
2359Z
Runway!DTW 06/443 DTW RWY 04L/22R CL MARKINGS OBSC 2606291959-2609302359
6/22/26
1641Z
2/9/27
2359Z
!DTW 06/351 DTW OBST CRANE (ASN 2025-AGL-16172-OE) 421427N0832118W (1.7NM N DTW) 756FT (114FT AGL) FLAGGED AND LGTD 2606221641-2702092359
6/22/26
1640Z
2/9/27
2359Z
!DTW 06/350 DTW OBST CRANE (ASN 2025-AGL-16175-OE) 421436N0832122W (1.9NM N DTW) 756FT (114FT AGL) FLAGGED AND LGTD 2606221640-2702092359
6/22/26
1639Z
2/9/27
2359Z
!DTW 06/349 DTW OBST CRANE (ASN 2025-AGL-16174-OE) 421436N0832118W (1.9NM N DTW) 756FT (114FT AGL) FLAGGED AND LGTD 2606221639-2702092359
6/22/26
1638Z
2/9/27
2359Z
!DTW 06/348 DTW OBST CRANE (ASN 2025-AGL-16173-OE) 421426N0832122W (1.7NM N DTW) 756FT (114FT AGL) FLAGGED AND LGTD 2606221638-2702092359
5/28/26
0618Z
!DTW 05/462 DTW NAV ILS RWY 03R IM U/S 2605280618-2608282111EST
3/25/26
0013Z
10/31/26
2359Z
!DTW 03/441 DTW TWY P BTN TXL PP SOUTH END AND DEICE PAD FOR RWY 03L SPOT 1 CLSD TO ACFT WINGSPAN MORE THAN 118FT 2603250013-2610312359
3/17/26
1906Z
12/31/26
2359Z
!DTW 03/365 DTW APRON DEICE PAD FOR RWY 21R SPOT 5, DEICE PAD FOR RWY 21R SPOT 6 CLSD 2603171906-2612312359
2/15/26
2259Z
!DTW 02/525 DTW NAV ILS RWY 04L IM U/S 2602152259-2702162111EST
2/9/26
1534Z
!DTW 02/433 DTW NAV ILS RWY 04R IM U/S 2602091534-2709222111EST
11/25/25
1227Z
3/23/28
2359Z
!DTW 11/404 DTW OBST CRANE (ASN 2025-AGL-7325-NRA) 421234N0832145W (0.4NM WSW DTW) 728FT (90FT AGL) FLAGGED AND LGTD 2511251227-2803232359
11/25/25
1226Z
3/23/28
2359Z
!DTW 11/403 DTW OBST CRANE (ASN 2025-AGL-7324-NRA) 421230N0832148W (0.5NM WSW DTW) 728FT (90FT AGL) FLAGGED AND LGTD 2511251226-2803232359
11/25/25
1225Z
3/23/28
2359Z
!DTW 11/402 DTW OBST CRANE (ASN 2025-AGL-7321-NRA) 421253N0832112W (0.1NM NE DTW) 727FT (90FT AGL) FLAGGED AND LGTD 2511251225-2803232359
FDC
8/11/26
2102Z
!FDC 6/3976 DTW STAR DETROIT METRO WAYNE COUNTY, DETROIT, MI. VCTRZ TWO ARRIVAL... HOSSA TRANSITION: MOCA 2800 ALL SEGMENTS. SAMPL TRANSITION: MOCA 2800 ALL SEGMENTS. ALL OTHER DATA REMAINS AS PUBLISHED. 2608112102-2702180001EST
8/11/26
2100Z
!FDC 6/3975 DTW STAR DETROIT METRO WAYNE COUNTY, DETROIT, MI. HAYLL THREE ARRIVAL... HOSSA TRANSITION: MOCA 2800 ALL SEGMENTS. SAMPL TRANSITION: MOCA 2800 ALL SEGMENTS. ALL OTHER DATA REMAINS AS PUBLISHED. 2608112100-2702180001EST
8/11/26
2057Z
!FDC 6/3973 DTW STAR DETROIT METRO WAYNE COUNTY, DETROIT, MI. RKCTY TWO ARRIVAL... DUDDA TRANSITION: MOCA 2300 TINDR TO FRELE. ENGRM TRANSITION: MOCA 2300 ENGRM TO FRELE. HOOTA TRANSITION: MOCA 2500 STIDL TO BUCKE. MOCA 2300 TINDR TO FRELE. PORZL TRANSITION: MOCA 2900 PORZL TO CHEFE. MOCA 2300 TINDR TO FRELE. ALL OTHER DATA REMAINS AS PUBLISHED. 2608112057-2702180001EST
6/24/26
1436Z
!FDC 6/0388 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
ILS RWY 3R (SA CAT II-III), AMDT 18 ...
S-ILS 3R CAT II NA EXCEPT FOR AIRCRAFT EQUIPPED WITH RADIO ALTIMETER. I-HUU INNER MARKER OUT OF SERVICE 2606241436-2702031436EST
4/29/26
1322Z
!FDC 6/6793 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
RNAV (GPS) RWY 27L, AMDT 3A...
LNAV/VNAV DA 1001/HAT 371 ALL CATS, VIS RVR 3500 ALL CATS.
2604291322-2805021322EST
4/29/26
1322Z
!FDC 6/6792 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
ILS Z OR LOC RWY 4L, AMDT 4C...
HIPKA FIX MINIMUMS (DME REQUIRED): S-LOC 4L MDA 1020/HAT 375 ALL CATS, VIS CATS C/D RVR 3500.
2604291322-2805021322EST
4/22/26
1449Z
!FDC 6/5071 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
RNAV (RNP) W RWY 3R, ORIG...
RNAV (RNP) X RWY 3R, ORIG-B...
RNP 0.30 DA 1024/ HAT 391 ALL CATS.
2604221449-2804241449EST
4/21/26
1311Z
!FDC 6/4655 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
ILS RWY 27L (SA CAT I-II), AMDT 5A ...
PROCEDURE NA. 2604211311-2612011310EST
4/14/26
2129Z
!FDC 6/2453 DTW ODP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1A...
TAKEOFF OBSTACLE NOTE: RWY 3L, TEMPORARY CRANE 2606FT FROM DER, 230FT RIGHT OF CENTERLINE, 90FT AGL/708FT MSL (2025-AGL-8425-NRA). ALL OTHER DATA REMAINS AS PUBLISHED. 2604142129-2611242355EST
4/3/26
1404Z
!FDC 6/7912 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
ILS PRM Z RWY 22R, ORIG-B...
ILS PRM Z RWY 4L, ORIG-B...
PROCEDURE NA.
2604031404-2804031404EST
3/20/26
1950Z
!FDC 6/1919 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
ILS Z RWY 4L (CAT II AND III), AMDT 4C ...
S-ILS 4L CAT II NA EXCEPT FOR AIRCRAFT EQUIPPED WITH RADIO ALTIMETER. I-HJT INNER MARKER OUT OF SERVICE. 2603201950-2610301950EST
8/21/25
1929Z
!FDC 5/1328 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
RNAV (RNP) W RWY 4L, AMDT 1...
RNP 0.30 DA 1063/HAT 418 ALL CATS.
2508211929-2708211929EST
8/21/25
1848Z
!FDC 5/1298 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
RNAV (RNP) X RWY 4L, ORIG-A...
RNP 0.30 DA 1063/HAT 418 ALL CATS.
2508211848-2708211848EST
8/21/25
1822Z
!FDC 5/1277 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
RNAV (RNP) U RWY 4L, ORIG-A...
RNP 0.30 DA 1063/HAT 418 ALL CATS.
2508211822-2708211822EST
8/14/25
1425Z
!FDC 5/7521 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
ILS PRM Y RWY 4L, AMDT 1C...
ILS PRM Z RWY 4L, ORIG-B...
ILS Y RWY 4L, AMDT 1C...
ILS Z OR LOC RWY 4L, AMDT 4C...
ILS Z RWY 4L (CAT II AND III), AMDT 4C... IM U/S.
2508141425-2708141425EST
12/3/24
1422Z
!FDC 4/0441 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
ILS PRM RWY 04R (SA CAT I) AMDT 3A ...
ILS PRM RWY 04R (CAT II AND III) AMDT 3A ...
PROCEDURE NA 2412031422-2612031421EST
10/7/24
1429Z
!FDC 4/5725 DTW IAP DETROIT METRO WAYNE COUNTY, DETROIT, MI.
RNAV (RNP) X RWY 22L, ORIG...
RNP 0.15 DA 952/HAT 315 ALL CATS, VIS RVR 4000 ALL CATS.
2410071429-2610071429EST
Yes
ALL
WAYNE COUNTY, MICHIGAN
11050 ROGELL DR #602
DETROIT, MI 48242
Phone: 734-942-3550
CHAD NEWTON
11050 ROGELL DR #602
DETROIT, MI 48242
Phone: 734-942-3685
LANSING FSS (LAN)
Toll Free: 1-800-WX-BRIEF
DTW
--
--
N/A
Yes - Lighted
No
Yes
Hanger, Tie-Down
NOT a Landing Rights Airport
Airport of Entry
None
None
None
None
Air Freight
Cargo Handling
Charter Service

Runway 03L/21R

8501 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,000,000lbs
  Runway 03L Runway 21R
True Heading 29°209°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 42° 12' 28"N 42° 13' 42"N
Longitude 83° 21' 04"W 83° 20' 10"W
Elevation 636' 631'
Threshold Crossing Height 55 ft. AGL 55 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights
Centerline Lights Yes Yes
Runway End Identifier Lights Yes Yes

Runway 03R/21L

10001 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

100,000lbs
200,000lbs
350,000lbs
750,000lbs
  Runway 03R Runway 21L
True Heading 29°209°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 11' 44"N 42° 13' 11"N
Longitude 83° 21' 06"W 83° 20' 03"W
Elevation 633' 632'
Threshold Crossing Height 70 ft. AGL 80 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No No

Runway 04L/22R

10000 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

100,000lbs
200,000lbs
350,000lbs
750,000lbs
  Runway 04L Runway 22R
True Heading 29°209°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 12' 08"N 42° 13' 34"N
Longitude 83° 23' 02"W 83° 21' 59"W
Elevation 645' 642'
Threshold Crossing Height 71 ft. AGL 71 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No No

Runway 04R/22L

12003 ft. x 200 ft.
CONC
Excellent
GRVD
HIGH

100,000lbs
185,000lbs
350,000lbs
--
  Runway 04R Runway 22L
True Heading 29°209°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 12' 08"N 42° 13' 52"N
Longitude 83° 22' 17"W 83° 20' 60"W
Elevation 637' 636'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No

Runway 04X/22X

0 ft. x 0 ft.





--
--
--
--
  Runway 04X Runway 22X
True Heading 29°209°
Traffic Pattern
Markings
Markings Condition
Latitude N/A N/A
Longitude N/A N/A
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 09L/27R

8708 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

100,000lbs
185,000lbs
350,000lbs
--
  Runway 09L Runway 27R
True Heading 89°269°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 13' 01"N 42° 13' 03"N
Longitude 83° 21' 47"W 83° 19' 52"W
Elevation 638' 634'
Threshold Crossing Height -- 61 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4L
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights Yes No

Runway 09R/27L

8500 ft. x 150 ft.
CONC
Fair
GRVD
HIGH

100,000lbs
185,000lbs
350,000lbs
--
  Runway 09R Runway 27L
True Heading 89°269°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 11' 56"N 42° 11' 58"N
Longitude 83° 21' 42"W 83° 19' 49"W
Elevation 636' 629'
Threshold Crossing Height -- 71 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4L
Approach Lights MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights Yes
A110-1BRIGHTLY LIGHTED PARKING LOT 2.6 NM SW OF ARPT.
A110-12RY STATUS LGTS ARE IN OPN.
A110-13RWY VISUAL SCREEN 20 FT AGL 1150 FT S. AER 04R
A110-14PPR FOR B747-8 OPRS DUE TO CONSTRAINTS ON RWYS, TWYS AND RAMPS CTC AIRFIELD OPRS AT 734-942-3685.
A110-15ACFT WITH WINGSPAN GTR THAN 171 FT ARE RSTRD FM USING TWY P BTN TWY J & TWY P3.
A110-16ACFT WITH WINGSPAN GTR THAN 171 FT ARE RSTRD FM USING TWY H BTN TWY B & TWY F.
A110-17TURNING RSTRD TO WINGSPAN 135 FT OR LESS TWY G NORTH TO TWY V EAST.
A110-19DVRSN ACR ACFT WO A PRESENCE AT DTW SHOULD CTC EVANS RAMP TWR 734-247-1046 PRIOR TO DIVG TO THE EXTENT PRACTICAL & PRVD CO, FLT OPR, CTC INFO, TYP, POB, INTL OR DOM, & ANY GND HANDLER AGRMTS IN PLACE.
A110-2BE ALERT BIRDS, WATERFOWL, ON & INVOF ARPT.
A110-20AIRCRAFT WITH WINGSPAN GREATER THAN 171 FT CANNOT PASS EACH OTHER ON TWYS Y AND K BETWEEN TWYS U AND K6 INSUFFICIENT WINGTIP CLEARANCE.
A110-21TURNING RESTRICTION TWY B TO TWY K RESTRICTED TO AIRCRAFT WITH WINGSPAN 171 FT OR LESS.
A110-22AUTH TO CONDUCT SIMUL INDEPENDENT INSTR APCHS TO PARL RWY 04L/22R & 03R/21L WO FINAL MONITORS, RWY CNTRLNS SEPARATED BY 8800 FT.
A110-5ACFT ON TWY 'F' AND TWY 'V' DO NOT BLOCK FIRE STATION EXITS.
A110-9TAXI ON RWY 09L/27R LTD TO: EXITING FM RWY 04R/22L, 03L/21R, & 03R/21L EXC NO TAXI BTN RWY 03L/21R & TWY W; TWO-WAY TAXI BTN TWY Y & TWY M WHEN RED STOP BAR LGTS ARE LGTD AT RWY 04R/22L & 03L/21R OR WHEN BARRICADES ARE USED INSTEAD AT THE RESPECTIVE INTS. TAXI BTN SS-SR OR IN CONDS WITH VIS LESS THAN 1 SM RQRS GREEN CNTRLN LGT TO BE OPR.
A30-04X/22XRY ID 04X/22X SUPPORTS SECOND ILS'S (I-BZB AND I-ALA) AT RY 04L/22R.
A30-09R/27LWEST 1713 FT CLSD INDEFLY.
A39-03L/21RPCR VALUE: 863/R/A/W/T
A39-03R/21LPCR VALUE: 863/R/A/W/T
A39-04L/22RPCR VALUE: 863/R/A/W/T
A39-04R/22LPCR VALUE: 863/R/A/W/T
A39-09L/27RPCR VALUE: 762/R/A/W/T
A39-09R/27LPCR VALUE: 863/R/A/W/T
A43-03LPAPI UNUSBL BYD 8 DEGS LEFT OR RIGHT OF CNTRLN.
A49-03RALSF2 RQRD WHEN RVR/VSBLY IS 6000/1 MILE OR LESS. SSALR OPERD WHEN RVR/VSBLY IS 6000/1 MILE.
A49-04RALSO HAS SSALR.
DETROIT METRO WAYNE COUNTY (ICAO: KDTW, IATA: DTW) is a public airport located in DETROIT, MI, US.
