10/26/231528Z
|
!FDC 3/2140 EGQ PART 1 OF 4 ODP EMMETSBURG MUNI, EMMETSBURG, IA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 13, TREE 17 FT FROM DER, 158 FT RIGHT
OF CENTERLINE, 5 FT AGL/1208 FT MSL.
UTILITY BUILDING 111 FT FROM DER, 161 FT LEFT OF CENTERLINE, 8 FT
AGL/1211 FT MSL.
BUILDING 684 FT FROM DER, 641 FT LEFT OF CENTERLINE, 20 FT AGL/1223
FT MSL.
TREE 886 FT FROM DER, 656 FT RIGHT OF CENTERLINE, 26 FT AGL/1231 FT
MSL.
TREE 959 FT FROM DER, 586 FT RIGHT OF CENTERLINE, 27 FT AGL/1233 FT
MSL.
POLE 963 FT FROM DER, 558 FT LEFT OF CENTERLINE, 29 FT AGL/1231 FT
MSL.
TREES BEGINNING 1003 FT FROM DER, 234 FT RIGHT OF CENTERLINE, UP TO
55 FT AGL/1258 FT MSL.
TREE, POLES BEGINNING 1032 FT FROM DER, 246 FT LEFT OF CENTERLINE,
UP TO 1250 FT MSL.
TREE 1083 FT FROM DER, 259 FT RIGHT OF CENTERLINE, 58 FT AGL/1262
FT MSL.
TREES BEGINNING 1083 FT FROM DER, 119 FT RIGHT OF CENTERLINE, UP TO
2310261528-2510261528EST
END PART 1 OF 4
!FDC 3/2140 EGQ PART 2 OF 4 ODP EMMETSBURG MUNI, EMMETSBURG, IA.
60 FT AGL/1264 FT MSL.
TREE 1492 FT FROM DER, 341 FT LEFT OF CENTERLINE, 53 FT AGL/1254 FT
MSL.
TREES BEGINNING 1505 FT FROM DER, 61 FT RIGHT OF CENTERLINE, UP TO
70 FT AGL/1274 FT MSL.
TREE 1667 FT FROM DER, 639 FT RIGHT OF CENTERLINE, 77 FT AGL/1279
FT MSL.
TREES BEGINNING 1706 FT FROM DER, 609 FT RIGHT OF CENTERLINE, UP TO
78 FT AGL/1280 FT MSL.
TREES BEGINNING 2261 FT FROM DER, 606 FT LEFT OF CENTERLINE, UP TO
1264 FT MSL.
TREE 2294 FT FROM DER, 723 FT LEFT OF CENTERLINE, 1268 FT MSL.
TREES BEGINNING 2317 FT FROM DER, 671 FT LEFT OF CENTERLINE, UP TO
71 FT AGL/1272 FT MSL.
RWY 31, TREE 159 FT FROM DER, 246 FT LEFT OF CENTERLINE, 1217 FT
MSL.
TREE, POLE BEGINNING 194 FT FROM DER, 80 FT RIGHT OF CENTERLINE, UP
TO 20 FT AGL/1225 FT MSL.
TREE 263 FT FROM DER, 353 FT LEFT OF CENTERLINE, 1260 FT MSL.
TREES BEGINNING 292 FT FROM DER, 57 FT LEFT OF CENTERLINE, UP TO
2310261528-2510261528EST
END PART 2 OF 4
!FDC 3/2140 EGQ PART 3 OF 4 ODP EMMETSBURG MUNI, EMMETSBURG, IA.
1280 FT MSL.
TREES BEGINNING 347 FT FROM DER, 442 FT LEFT OF CENTERLINE, UP TO
86 FT AGL/1291 FT MSL.
TREES BEGINNING 382 FT FROM DER, 117 FT LEFT OF CENTERLINE, UP TO
91 FT AGL/1297 FT MSL.
TREE 778 FT FROM DER, 127 FT RIGHT OF CENTERLINE, 1226 FT MSL.
TREE 855 FT FROM DER, 182 FT RIGHT OF CENTERLINE, 30 FT AGL/1232 FT
MSL.
TREE 900 FT FROM DER, 227 FT RIGHT OF CENTERLINE, 49 FT AGL/1247 FT
MSL.
TREES BEGINNING 982 FT FROM DER, 155 FT RIGHT OF CENTERLINE, UP TO
48 FT AGL/1251 FT MSL.
TREE 1025 FT FROM DER, 164 FT RIGHT OF CENTERLINE, 58 FT AGL/1258
FT MSL.
TREES BEGINNING 1030 FT FROM DER, 148 FT RIGHT OF CENTERLINE, UP TO
55 FT AGL/1260 FT MSL.
TREES BEGINNING 1101 FT FROM DER, 119 FT RIGHT OF CENTERLINE, UP TO
59 FT AGL/1264 FT MSL.
TREE 1173 FT FROM DER, 133 FT RIGHT OF CENTERLINE, 61 FT AGL/1265
FT MSL.
2310261528-2510261528EST
END PART 3 OF 4
!FDC 3/2140 EGQ PART 4 OF 4 ODP EMMETSBURG MUNI, EMMETSBURG, IA.
TREES BEGINNING 1196 FT FROM DER, 66 FT RIGHT OF CENTERLINE, UP TO
66 FT AGL/1270 FT MSL.
TREES BEGINNING 1506 FT FROM DER, 509 FT RIGHT OF CENTERLINE, UP TO
76 FT AGL/1275 FT MSL.
TREE 1779 FT FROM DER, 803 FT RIGHT OF CENTERLINE, 78 FT AGL/1276
FT MSL.
TREES BEGINNING 1836 FT FROM DER, 352 FT RIGHT OF CENTERLINE, UP TO
94 FT AGL/1295 FT MSL.
TREES BEGINNING 2386 FT FROM DER, 104 FT RIGHT OF CENTERLINE, UP TO
92 FT AGL/1296 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2310261528-2510261528EST
END PART 4 OF 4
|
