EL PASO INTL - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KELP
ICAO KELPIATA ELPLocal ELP
EL PASO INTL
PublicPUB

4 miles NE of EL PASO, TX, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
31° 48' 26"N 106° 22' 35"W
Elevation
3962' MSL
Pattern Alt
4962' MSL
Mag Variation
8°E
Declination
8°E
Fuel
JET A-1+, 100LL
FSS
ALBUQUERQUE (ABQ)
Sectional
EL PASO
ARTCC
ALBUQUERQUE (ZAB)
Data Effective
2/19/26-3/19/26
KELP VFR
5:51 PM MDT
Broken 25,000'
Few 20,000'
10sm
80°F
22°F
29.85"Hg
230° 17kts
Gusts 24kts
AO2 PK WND 24035/2308 SLP047 T02671056 10289 20250 56017 $
METAR KELP 142351Z 23017G24KT 10SM FEW200 BKN250 27/M06 A2985 RMK AO2 PK WND 24035/2308 SLP047 T02671056 10289 20250 56017 $
+ Add Your Business

KELP FBOs

Promote Listing
Atlantic Aviation
UNICOM: 128.85
Phone: (915) 779-2831
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 2/28
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 7.18
Full Serve 8.18 7.35
Fuel Notes
Prices include tax
Promote Listing
Million Air
UNICOM: 122.95
Phone: (915) 235-9357
No Rating Available
0 Reviews (Read | Sign In To Write)
Avfuel
As of 2/16
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 6.93
Full Serve 8.19 7.19 7.30
Fuel Notes
Prices include tax

KELP Aircraft Service & Maintenance

Promote Listing
ATI Jet Inc.
Phone: (915) 867-6634
Fax: (915) 887-3309
No Rating Available
0 Reviews (Read | Sign In To Write)
Promote Listing
Avionics Associates
Phone: (915) 779-3481
Fax: (915) 775-1202
Other: (800) 437-2376
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

Digital ATIS 120.0
(915) 774-9415
ASOS (915) 774-9497

Common

UNICOM 122.95

Clearance

EL PASO CLEARANCE DELIVERY 125.0

Ground

EL PASO GROUND 121.9

Tower

EL PASO TOWER 118.3

Approach

EL PASO APPROACH 119.15
SOUTH-V16
EL PASO APPROACH 124.25
Initial Contact - NORTH-V16

Departure

ATKNN DP 119.15
EL PASO DEPARTURE 119.15
JCOXX DP 119.15
LATVE DP 119.15
NEVUE DP 119.15
TDOWN DP 119.15

Flight Service

Flight Service 122.6
(ABQ)

Emergency

Emergency 121.5

Other

CLASS C 119.15
SOUTH-V16
CLASS C 119.15
CLASS C 124.25
NORTH-V16

Terminal Area Forecast

KELP
Sat, 3/14 5:36 PM MDT
Sat, 3/14 6:00 PM MDT - Sun, 3/15 6:00 PM MDT
VFR
6:00 PM MDT - 11:00 PM MDT
Broken 25,000'
Few 18,000'
6sm
260° 18kts
Gusts 28kts
VFR
11:00 PM MDT - 7:00 AM MDT
Broken 25,000'
6sm
270° 15kts
VFR
Temporary 12:00 AM MDT - 4:00 AM MDT
No Clouds
N/A
280° 22kts
Gusts 35kts
VFR
7:00 AM MDT - 11:00 AM MDT
Broken 25,000'
6sm
280° 10kts
VFR
11:00 AM MDT - 6:00 PM MDT
Scattered 25,000'
6sm
290° 18kts
Gusts 28kts
TAF KELP 142336Z 1500/1524 26018G28KT P6SM FEW180 BKN250
   FM150500 27015KT P6SM BKN250 WS018/28040KT
   TEMPO 1506/1510 28022G35KT
   FM151300 28010KT P6SM BKN250
   FM151700 29018G28KT P6SM SCT250
KELP
EffectiveExpiresCategoryNOTAM
Domestic
3/17/26
1300Z
3/17/26
2100Z
!ELP 03/107 ELP APRON GA TXL WIP 2603171300-2603172100
3/16/26
1200Z
3/16/26
2300Z
!ELP 03/108 ELP TWY U BTN NASA RAMP AND SOUTH CARGO RAMP WIP 2603161200-2603162300
3/15/26
0000Z
3/21/26
2359Z
!ELP 03/110 ELP AIRSPACE UAS WI AN AREA DEFINED AS 0.5NM EITHER SIDE
OF A LINE FM 314729.50N1063138.10W (7.8NM WSW ELP) TO
314456.70N1062923.90W (6.8NM SW ELP) TO 314508N1062817W (5.9NM SW
ELP) TO 314533.20N1062804.70W (5.5NM SW ELP) TO
314553.10N1062708.10W (4.6NM SW ELP) TO 314508.30N1062501.80W (3.9NM
SSW ELP) TO 314421.40N1062334.10W (4.2NM S ELP) SFC-400FT AGL DLY
0000-2359 2603150000-2603212359
3/14/26
1500Z
3/14/26
2200Z
!ELP 03/041 ELP AIRSPACE UNMANNED ROCKET WI AN AREA DEFINED AS 2NM RADIUS OF 314355N1060803W (12.7NM N E35) SFC-10000FT AGL 2603141500-2603142200
3/14/26
0225Z
3/14/26
1000Z
!ELP 03/109 ELP AIRSPACE UAS WI AN AREA DEFINED AS 3NM RADIUS OF
314521N1062954.80W (7.0NM SW ELP) SFC-400FT AGL
2603140225-2603141000
3/13/26
2237Z
3/20/26
2359Z
!ELP 03/105 ELP TWY J LOCATION SIGN FOR TWY R NOT STD 2603132237-2603202359
3/13/26
2237Z
3/20/26
2359Z
!ELP 03/104 ELP TWY J TWY DIRECTION SIGN FOR TWY R NOT STD 2603132237-2603202359
3/13/26
2235Z
3/20/26
2359Z
!ELP 03/103 ELP TWY J TWY DIRECTION SIGN FOR TWY M NOT STD 2603132235-2603202359
3/13/26
2234Z
3/20/26
2359Z
!ELP 03/102 ELP TWY J LOCATION SIGN FOR TWY M NOT STD 2603132234-2603202359
3/13/26
2233Z
3/20/26
2359Z
!ELP 03/101 ELP TWY M TWY DIRECTION SIGN FOR TWY J NOT STD 2603132233-2603202359
3/13/26
2232Z
3/20/26
2359Z
!ELP 03/100 ELP TWY M LOCATION SIGN NOT STD 2603132232-2603202359
3/13/26
1400Z
3/13/26
1630Z
!ELP 03/044 ELP OBST CRANE (ASN UNKNOWN) 314846N1062337W (.72NM NNW APCH END RWY 08R)
UNKNOWN (60FT AGL) FLAGGED 2603131400-2603131630
3/13/26
0230Z
3/13/26
1028Z
!ELP 03/099 ELP AIRSPACE UAS WI AN AREA DEFINED AS 3NM RADIUS OF
314545.70N1063035.30W (7.3NM WSW ELP) SFC-400FT AGL
2603130230-2603131028
3/12/26
2210Z
4/15/26
2359Z
Runway!ELP 03/098 ELP RWY 04/22 CLSD EXC TAX BTN TWY N AND TWY J2 2603122210-2604152359
3/12/26
2159Z
3/20/26
2359Z
Runway!ELP 03/097 ELP RWY 26L TWY DIRECTION SIGN AT TWY R RIGHT SIDE NOT STD 2603122159-2603202359
3/12/26
2151Z
3/20/26
2359Z
!ELP 03/096 ELP TWY R TWY DIRECTION SIGN FOR TWY J NOT STD 2603122151-2603202359
3/12/26
2149Z
3/20/26
2359Z
!ELP 03/095 ELP TWY R LOCATION SIGN BTN TWY J AND APCH END RWY 08R NOT STD 2603122149-2603202359
3/12/26
2143Z
3/20/26
2359Z
!ELP 03/094 ELP TWY R LOCATION SIGN BTN APCH END RWY 08R AND TWY J NOT STD 2603122143-2603202359
3/12/26
2038Z
3/20/26
2359Z
!ELP 03/093 ELP TWY J TWY DIRECTION SIGN FOR TWY R NOT STD 2603122038-2603202359
3/12/26
2037Z
3/20/26
2359Z
!ELP 03/092 ELP TWY J LOCATION SIGN BTN TWY R AND TWY M NOT STD 2603122037-2603202359
3/12/26
2033Z
3/20/26
2359Z
!ELP 03/091 ELP TWY J TWY DIRECTION SIGN FOR TWY K1 NOT STD 2603122033-2603202359
3/12/26
2032Z
3/20/26
2359Z
!ELP 03/090 ELP TWY J LOCATION SIGN BTN TWY J9 AND TWY K1 NOT STD 2603122032-2603202359
3/12/26
2031Z
3/20/26
2359Z
!ELP 03/089 ELP TWY K1 TWY DIRECTION SIGN FOR TWY J NOT STD 2603122031-2603202359
3/12/26
2029Z
3/20/26
2359Z
!ELP 03/088 ELP TWY K1 LOCATION SIGN BTN NORTH CARGO RAMP AND TWY J NOT STD 2603122029-2603202359
3/12/26
2028Z
3/20/26
2359Z
!ELP 03/087 ELP TWY J TWY DIRECTION SIGN FOR TWY K1 NOT STD 2603122028-2603202359
3/12/26
2027Z
3/20/26
2359Z
!ELP 03/086 ELP TWY J LOCATION SIGN BTN TWY K1 AND TWY J2 NOT STD 2603122027-2603202359
3/12/26
2025Z
3/20/26
2359Z
!ELP 03/085 ELP TWY J2 TWY DIRECTION SIGN FOR TWY J NOT STD 2603122025-2603202359
3/12/26
2024Z
3/20/26
2359Z
!ELP 03/084 ELP TWY J2 LOCATION SIGN BTN RWY 04/22 AND TWY J NOT STD 2603122024-2603202359
3/12/26
2022Z
3/20/26
2359Z
!ELP 03/083 ELP TWY J TWY DIRECTION SIGN FOR TWY J2 NOT STD 2603122022-2603202359
3/12/26
2021Z
3/20/26
2359Z
!ELP 03/082 ELP TWY J LOCATION SIGN BTN TWY J2 AND TWY Q NOT STD 2603122021-2603202359
3/12/26
2019Z
3/20/26
2359Z
!ELP 03/081 ELP TWY J TWY DIRECTION SIGN FOR TWY Q NOT STD 2603122019-2603202359
3/12/26
2018Z
3/20/26
2359Z
!ELP 03/080 ELP TWY J LOCATION SIGN BTN TWY Q AND TWY J2 NOT STD 2603122018-2603202359
3/12/26
2016Z
3/20/26
2359Z
!ELP 03/079 ELP TWY Q TWY DIRECTION SIGN FOR TWY J NOT STD 2603122016-2603202359
3/12/26
2015Z
3/20/26
2359Z
!ELP 03/078 ELP TWY Q LOCATION SIGN BTN RWY 04/22 AND TWY J NOT STD 2603122015-2603202359
3/12/26
2013Z
3/20/26
2359Z
!ELP 03/077 ELP TWY J TWY DIRECTION SIGN FOR TWY Q NOT STD 2603122013-2603202359
3/12/26
2011Z
3/20/26
2359Z
!ELP 03/076 ELP TWY J LOCATION SIGN BTN TWY Q AND TWY P NOT STD 2603122011-2603202359
3/12/26
2009Z
3/20/26
2359Z
!ELP 03/075 ELP TWY J TWY DIRECTION SIGN FOR TWY N NOT STD 2603122009-2603202359
3/12/26
2007Z
3/20/26
2359Z
!ELP 03/074 ELP TWY J LOCATION SIGN BTN TWY N AND TWY P NOT STD 2603122007-2603202359
3/12/26
2003Z
3/20/26
2359Z
!ELP 03/073 ELP TWY N TWY DIRECTION SIGN FOR TWY J NOT STD 2603122003-2603202359
3/12/26
2002Z
3/20/26
2359Z
!ELP 03/072 ELP TWY N LOCATION SIGN NOT STD 2603122002-2603202359
3/12/26
1959Z
3/20/26
2359Z
!ELP 03/071 ELP TWY J TWY DIRECTION SIGN FOR TWY N NOT STD 2603121959-2603202359
3/12/26
1956Z
3/20/26
2359Z
!ELP 03/070 ELP TWY J LOCATION SIGN BTN TWY P AND TWY Q NOT STD 2603121956-2603202359
3/12/26
0245Z
3/12/26
1043Z
!ELP 03/068 ELP AIRSPACE UAS WI AN AREA DEFINED AS 3NM RADIUS OF
314422.20N1062349.90W (4.2NM S ELP) SFC-400FT AGL
2603120245-2603121043
3/12/26
0200Z
3/12/26
1000Z
!ELP 03/067 ELP AIRSPACE UAS WI AN AREA DEFINED AS 3NM RADIUS OF
314521.80N1062954W (7.0NM SW ELP) SFC-400FT AGL
2603120200-2603121000
3/11/26
2244Z
3/20/26
2359Z
!ELP 03/066 ELP TWY J2 LOCATION SIGN FOR RWY 04/22 NOT STD 2603112244-2603202359
3/11/26
2243Z
3/20/26
2359Z
!ELP 03/065 ELP TWY Q LOCATION SIGN FOR RWY 04/22 NOT STD 2603112243-2603202359
3/11/26
2242Z
3/20/26
2359Z
!ELP 03/064 ELP TWY P TWY DIRECTION SIGN FOR TWY J NOT STD 2603112242-2603202359
3/11/26
2240Z
3/20/26
2359Z
!ELP 03/063 ELP TWY P LOCATION SIGN BTN RWY 04/22 AND TWY J NOT STD 2603112240-2603202359
3/11/26
2238Z
3/20/26
2359Z
!ELP 03/062 ELP TWY P LOCATION SIGN FOR RWY 04/22 NOT STD 2603112238-2603202359
3/11/26
2237Z
3/20/26
2359Z
!ELP 03/061 ELP TWY N LOCATION SIGN FOR RWY 04/22 NOT STD 2603112237-2603202359
3/11/26
2235Z
3/20/26
2359Z
!ELP 03/060 ELP TWY J TWY DIRECTION SIGN FOR TWY H NOT STD 2603112235-2603202359
3/11/26
2233Z
3/20/26
2359Z
!ELP 03/059 ELP TWY J TWY DIRECTION SIGN FOR TWY M NOT STD 2603112233-2603202359
3/11/26
2231Z
3/20/26
2359Z
!ELP 03/058 ELP TWY M LOCATION SIGN FOR RWY 04/22 NOT STD 2603112231-2603202359
3/11/26
2228Z
3/20/26
2359Z
!ELP 03/057 ELP TWY J LOCATION SIGN FOR TWY M NOT STD 2603112228-2603202359
3/11/26
2227Z
3/20/26
2359Z
!ELP 03/056 ELP TWY J LOCATION SIGN BTN TWY M AND TWY N NOT STD 2603112227-2603202359
3/11/26
1300Z
3/14/26
0100Z
!ELP 03/053 ELP TWY R BTN TWY J AND APCH END RWY 08R WIP CONST
2603111300-2603140100
3/11/26
1300Z
3/14/26
0100Z
!ELP 03/051 ELP TWY J BTN TWY G AND TWY J9 WIP CONST 2603111300-2603140100
3/9/26
1100Z
3/31/26
2300Z
!ELP 03/006 ELP OBST CRANE (ASN UNKNOWN) 314752N1062203W (.43NM NNE ELP)
UNKNOWN (50FT AGL) FLAGGED DLY 1100-2300 2603091100-2603312300
3/8/26
0000Z
3/14/26
2359Z
!ELP 03/030 ELP AIRSPACE UAS WI AN AREA DEFINED AS 0.5NM EITHER SIDE
OF A LINE FM 314729.50N1063138.10W (7.8NM WSW ELP) TO
314456.70N1062923.90W (6.8NM SW ELP) TO 314508N1062817W (5.9NM SW
ELP) TO 314533.20N1062804.70W (5.5NM SW ELP) TO
314553.10N1062708.10W (4.6NM SW ELP) TO 314508.30N1062501.80W (3.9NM
SSW ELP) TO 314421.40N1062334.10W (4.2NM S ELP) SFC-400FT AGL DLY
0000-2359 2603080000-2603142359
3/3/26
0040Z
4/17/26
0039Z
!ELP 03/010 ELP OBST TOWER LGT (ASR 1284833) 315235.10N1061936.20W (4.8NM NNE ELP) 4058.7FT (62.0FT AGL) U/S 2603030040-2604170039
3/1/26
0000Z
3/31/26
2359Z
!ELP 02/160 ELP AIRSPACE UAS WI AN AREA DEFINED AS 5NM RADIUS OF
314935.50N1055505.60W (21.9NM NNE E35) SFC-400FT AGL DLY 0000-2359
2603010000-2603312359
3/1/26
0000Z
3/31/26
2359Z
!ELP 02/159 ELP AIRSPACE UAS WI AN AREA DEFINED AS 1.5NM EITHER SIDE
OF A LINE FM 313500N1061700W (8.0NM WNW E35) TO 313600N1061700W
(8.6NM WNW E35) TO 313600N1061800W (9.3NM WNW E35) TO
313700N1061800W (9.8NM WNW E35) TO 313900N1062000W (9.7NM SSE ELP)
TO 314100N1062000W (7.7NM SSE ELP) TO 314200N1062200W (6.4NM SSE
ELP) TO 314300N1062200W (5.5NM SSE ELP) SFC-400FT AGL DLY 0000-2359
2603010000-2603312359
2/28/26
0101Z
6/1/26
2359Z
!ELP 02/171 ELP AIRSPACE UAS WI AN AREA DEFINED AS 314329N1061946W (6.2NM SE ELP) TO 313806N1061542W (8.7NM NW E35) TO 313513N1061356W (5.3NM NW E35) TO 313433N1061708W (7.6NM NW E35) TO 313717N1061810W (9.8NM NW E35) TO 314150N1062055W (7.9NM SSE ELP) TO 314256N1062154W (6.3NM SSE ELP) TO POINT OF ORIGIN SFC-400FT AGL 2602280101-2606012359
2/28/26
0101Z
6/1/26
2359Z
!ELP 02/170 ELP AIRSPACE UAS WI AN AREA DEFINED AS 314703N1063142W (7.4NM WSW ELP) TO 314703N1062800W (5.1NM WSW ELP) TO 314920N1062800W (4.7NM WNW ELP) TO 314920N1063518W (7.1NM SE DNA) TO POINT OF ORIGIN SFC-400FT AGL 2602280101-2606012359
2/27/26
0620Z
4/13/26
0523Z
!ELP 02/169 ELP OBST TOWER LGT (ASR 1284830) 315051.40N1062143.60W (2.5NM NNE ELP) 4008.9FT (62.0FT AGL) U/S 2602270620-2604130523
2/26/26
1806Z
4/12/26
1805Z
!ELP 02/164 ELP OBST TOWER LGT (ASR 1284831) 315059.70N1061952.80W (3.4NM NE ELP) 4035.1FT (62.0FT AGL) U/S 2602261806-2604121805
2/25/26
2204Z
4/20/26
2355Z
Runway!ELP 02/158 ELP RWY 22 ALS U/S 2602252204-2604202355
2/25/26
2203Z
4/20/26
2355Z
!ELP 02/157 ELP NAV ILS RWY 22 U/S 2602252203-2604202355
2/25/26
2203Z
4/20/26
2355Z
!ELP 02/156 ELP AD AP RVR ALL U/S 2602252203-2604202355
2/25/26
2202Z
4/20/26
2355Z
!ELP 02/155 ELP NAV ILS RWY 04 U/S 2602252202-2604202355
2/25/26
2202Z
4/20/26
2355Z
Runway!ELP 02/154 ELP RWY 22 PAPI U/S 2602252202-2604202355
2/25/26
2201Z
4/20/26
2355Z
Runway!ELP 02/153 ELP RWY 04 PAPI U/S 2602252201-2604202355
2/25/26
2201Z
4/20/26
2355Z
Runway!ELP 02/152 ELP RWY 04 RWY END ID LGT U/S 2602252201-2604202355
2/24/26
2309Z
4/15/26
2359Z
!ELP 02/148 ELP TWY J BTN TWY R AND TERMINAL RAMP CLSD 2602242309-2604152359
2/24/26
1713Z
3/28/26
2359Z
!ELP 02/147 ELP APRON CUST RAMP E 250FT CL MARKINGS OBSC 2602241713-2603282359
2/24/26
1708Z
3/28/26
2359Z
!ELP 02/146 ELP APRON MIL RAMP SFC MARKINGS NOT STD 2602241708-2603282359
2/23/26
1300Z
4/15/26
2359Z
!ELP 02/117 ELP APRON TERMINAL RAMP W 1500FT CLSD TO ACFT WINGSPAN MORE THAN 118FT 2602231300-2604152359
2/23/26
1300Z
4/15/26
2359Z
!ELP 02/116 ELP TWY J BTN TWY R AND TWY M WIP CONST 2602231300-2604152359
2/17/26
2125Z
4/3/26
2124Z
!ELP 02/113 ELP OBST TOWER LGT (ASR 1016901) 320242.40N1054954.80W (31.2NM ENE ELP) 5747FT (370FT AGL) U/S 2602172125-2604032124
2/16/26
1822Z
!ELP 02/105 ELP TWY F CLSD 2602161822-PERM
2/14/26
1030Z
3/15/26
2359Z
!ELP 02/099 ELP OBST TOWER LGT (ASR 1257457) 314742.60N1062852.60W (5.4NM W ELP) 5331.7FT (229.0FT AGL) U/S 2602141030-2603152359
2/11/26
1902Z
4/15/26
2359Z
!ELP 02/078 ELP TWY J1 HLDG PSN SIGN LGT U/S 2602111902-2604152359
2/10/26
2247Z
4/15/26
2359Z
!ELP 02/067 ELP TWY J2 HLDG PSN SIGN LGT U/S 2602102247-2604152359
2/10/26
2240Z
4/15/26
2359Z
!ELP 02/066 ELP TWY N HLDG PSN SIGN LGT U/S 2602102240-2604152359
2/10/26
2239Z
4/15/26
2359Z
!ELP 02/065 ELP TWY P HLDG PSN SIGN LGT U/S 2602102239-2604152359
2/10/26
2237Z
4/15/26
2359Z
!ELP 02/064 ELP TWY Q HLDG PSN SIGN LGT U/S 2602102237-2604152359
2/9/26
1300Z
4/15/26
2359Z
!ELP 02/035 ELP TWY M CLSD 2602091300-2604152359
2/9/26
1300Z
4/15/26
2359Z
!ELP 02/034 ELP TWY A CLSD 2602091300-2604152359
2/9/26
1300Z
3/28/26
2359Z
!ELP 02/032 ELP APRON CUST RAMP W 250FT CLSD 2602091300-2603282359
2/9/26
1300Z
4/19/26
2359Z
!ELP 02/027 ELP TWY D CLSD 2602091300-2604192359
1/13/26
2306Z
!ELP 01/045 ELP TWY G BTN RWY 04/22 AND TERMINAL RAMP CLSD 2601132306-PERM
1/13/26
2306Z
!ELP 01/044 ELP TWY H CLSD 2601132306-PERM
1/13/26
1543Z
4/14/26
0500Z
!ELP 01/043 ELP OBST TOWER LGT (ASR 1281674) 314549.90N1062642.70W (4.4NM SW ELP) 3857.0FT (155.8FT AGL) U/S 2601131543-2604140500
FDC
2/18/26
1637Z
!FDC 6/5919 ELP IAP EL PASO INTL, EL PASO, TX.
RNAV (RNP) Y RWY 4, ORIG-F...
FOR UNCOMPENSATED BARO-VNAV SYSTEMS, PROCEDURE NA BELOW -5C OR ABOVE 54C..
2602181637-2802181637EST
2/18/26
1603Z
!FDC 6/5828 ELP IAP EL PASO INTL, EL PASO, TX.
RNAV (RNP) Y RWY 8R, ORIG...
RNP 0.30 DA 4332/HAT 392, VIS 1 1/8 SM.
2602181603-2802181603EST
2/18/26
1603Z
!FDC 6/5827 ELP IAP EL PASO INTL, EL PASO, TX.
RNAV (RNP) X RWY 8R, ORIG...
RNP 0.30 DA 4332/HAT 392, VIS 1 1/8 SM.
2602181603-2802181603EST
10/2/24
1701Z
!FDC 4/3904 ELP IAP EL PASO INTL, EL PASO, TX.
RNAV (GPS) Y RWY 26L, AMDT 1D...
LP MDA 4400/HAT 438 ALL CATS.
LNAV MDA 4400/HAT 438 ALL CATS.
FOR INOPERATIVE ALS, INCREASE LP AND LNAV CAT A/B VISIBILITY TO 1SM AND CAT C/D VISIBILITY TO 1 1/4 SM.
2410021701-2610021701EST
Yes
ALL
CITY OF EL PASO
300 N. CAMPBELL
EL PASO, TX 79901
Phone: (915) 212-0000
TONY NEVAREZ
6701 CONVAIR RD
EL PASO, TX 79925
Phone: 915-212-0333
ALBUQUERQUE FSS (ABQ)
Toll Free: 1-800-WX-BRIEF
ELP
Sunset to Sunrise
--
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
Airport of Entry
Major
Major
Low Pressure
Low Pressure
Air Freight
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 04/22

12020 ft. x 150 ft.
ASPH CONC
Fair
GRVD
HIGH

100,000lbs
180,000lbs
350,000lbs
--
  Runway 04 Runway 22
True Heading 50°230°
Traffic Pattern Right
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 31° 48' 06"N 31° 49' 22"N
Longitude 106° 23' 59"W 106° 22' 13"W
Elevation 3,917' 3,950'
Threshold Crossing Height 55 ft. AGL 70 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes

Runway 08L/26R

5499 ft. x 75 ft.
CONC
Good
GRVD
MED

60,000lbs
180,000lbs
--
--
  Runway 08L Runway 26R
True Heading 93°273°
Traffic Pattern Right
Markings BSC NPI
Markings Condition GOOD GOOD
Latitude 31° 48' 25"N 31° 48' 22"N
Longitude 106° 22' 11"W 106° 21' 08"W
Elevation 3,953' 3,949'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 08R/26L

9025 ft. x 150 ft.
ASPH CONC
Fair
GRVD
HIGH

100,000lbs
180,000lbs
350,000lbs
--
  Runway 08R Runway 26L
True Heading 93°273°
Traffic Pattern Right Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 31° 48' 07"N 31° 48' 02"N
Longitude 106° 23' 19"W 106° 21' 35"W
Elevation 3,927' 3,962'
Threshold Crossing Height 75 ft. AGL 75 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes
A110-124 HR PPR CLASS A EXPLOSIVES CTC 915-212-0333.
A110-11HOLDING POSITION MARKINGS FOR RUNWAY 8R APPROACH AND RUNWAY 4/22 ARE IN CLOSE PROXIMITY TO THE TERMINAL APRON; REVIEW AIRPORT DIAGRAM PRIOR TO PUSHBACK FROM THE GATE.
A110-12MILITARY USERS SHOULD REVIEW NOISE ABATEMENT PROCEDURES LISTED FOR BIGGS AAF.
A110-15NOISE ABATEMENT PROCEDURES IN EFFECT, CTC ATCT FOR DETAILS.
A110-16ENGINE POWER IS RSTRD TO IDLE POWER ON ONE ENGINE AT A TIME FOR MAX 5 MIN ON ANY TERMINAL OR PARKING APRONS, CROSS-BLEED STARTS OR OTHER PRE DEP ACTIVITY ON MOVEMENT AREAS ONLY, MAINT OR OTR RQRMT NEEDING LONGER OR HIGHER POWER CTC TWR FOR DIRECTIONS TO DESIGNATED RUNUP AREAS.
A110-17COMPASS ROSE CLSD PERMLY.
A110-2CTN: BIGGS AAF 2NM NW RWY 22 CAN BE MISTAKEN FOR ELP RWY 22.
A110-8NORTH BOUND TFC PROHIBITED ON TWY F SOUTH OF APCH END RWY 08R.
A110-9TWY A SOUTH OF RWY 4; TWY J NE OF TWY K1; TWY J1 AND TWY J9 NOT VISIBLE FM ATCT.
A30-08L/26RRWY 08L/26R NOT AVBL FOR PART 121/PART 380 OPS WITH SKED PAX CARRYING OPS MORE THAN 9 PAX SEATS AND NON-SKED PAX CARRYING OPS MORE THAN 30 PAX SEATS.
A33-04/22_SURFRWY 4/22 206 FEET CONC, 10,814 FEET ASPH, 1,000 FEET CONC.
A33-08R/26L_SURFRWY 08R/26L 7,780 FEET ASPH, 1,247 FEET CONC.
A39-04/22PCR VALUE: 680/F/B/X/T
A39-08L/26RPCR VALUE: 100/R/C/W/T
A39-08R/26LPCR VALUE: 520/F/B/X/T
A70-100LLFOR FUEL AT MIL RAMP CTC ATLANTIC AVIATION 122.95 OR 915-779-2831.
E147TPA: 1038 FT AGL SMALL ACFT, 1542 FT AGL TURBOJET, 2042 FT AGL OVERHEAD APCH.
EL PASO INTL (ICAO: KELP, IATA: ELP) is a public airport located in EL PASO, TX, US.
