1/18/241843Z
|
!FDC 4/5087 FWQ PART 1 OF 2 ODP ROSTRAVER, MONONGAHELA, PA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1A...
TAKEOFF OBSTACLE NOTES: RWY 08: NAVAID 6 FT FROM DER, 77 FT LEFT OF
CENTERLINE, 4 FT AGL/1225 FT MSL. NAVAID 7 FT FROM DER, 76 FT RIGHT
OF CENTERLINE, 3 FT AGL/1225 FT MSL. TREE 64 FT FROM DER, 438 FT
RIGHT OF CENTERLINE, 1274 FT MSL. TREES BEGINNING 245 FT FROM DER,
419 FT LEFT OF CENTERLINE, UP TO 1245 FT MSL. TREE 2128 FT FROM
DER, 27 FT RIGHT OF CENTERLINE, 1284 FT MSL. TREE 2231 FT FROM DER,
19 FT LEFT OF CENTERLINE, 1280 FT MSL. TREES BEGINNING 2346 FT FROM
DER, 204 FT RIGHT OF CENTERLINE, UP TO 1285 FT MSL. TREE 3402 FT
FROM DER, 779 FT RIGHT OF CENTERLINE, 1315 FT MSL. TREE 4187 FT
FROM DER, 814 FT LEFT OF CENTERLINE, 1342 FT MSL.
NOTE: RWY 26: SIGN 1 FT FROM DER, 172 FT LEFT OF CENTERLINE, 2 FT
AGL/1229 FT MSL. NAVAID, LIGHT POLES BEGINNING 6 FT FROM DER, 77 FT
RIGHT OF CENTERLINE, UP TO 3 FT AGL/1230 FT MSL. NAVAID 7 FT FROM
DER, 77 FT LEFT OF CENTERLINE, 2 FT AGL/1230 FT MSL. TREE, POLE
BEGINNING 114 FT FROM DER, 374 FT RIGHT OF CENTERLINE, UP TO 54 FT
AGL/1262 FT MSL. TRANSMISSION LINE, TREE BEGINNING 117 FT FROM DER,
199 FT LEFT OF CENTERLINE, UP TO 34 FT AGL/1254 FT MSL. POLE,
TRANSMISSION LINE, TREE BEGINNING 265 FT FROM DER, 207 FT LEFT OF
CENTERLINE, UP TO 49 FT AGL/1268 FT MSL. TREES BEGINNING 403 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2401181843-2408291843EST
END PART 1 OF 2
!FDC 4/5087 FWQ PART 2 OF 2 ODP ROSTRAVER, MONONGAHELA, PA.
FROM DER, 551 FT RIGHT OF CENTERLINE, UP TO 1264 FT MSL. TREES
BEGINNING 698 FT FROM DER, 94 FT LEFT OF CENTERLINE, UP TO 1271 FT
MSL. TREES BEGINNING 978 FT FROM DER, 98 FT LEFT OF CENTERLINE, UP
TO 65 FT AGL/1273 FT MSL. TREES BEGINNING 1186 FT FROM DER, 259 FT
LEFT OF CENTERLINE, UP TO 69 FT AGL/1276 FT MSL. TREE 2332 FT FROM
DER, 718 FT LEFT OF CENTERLINE, 65 FT AGL/1292 FT MSL. TREES
BEGINNING 2380 FT FROM DER, 603 FT LEFT OF CENTERLINE, UP TO 1294
FT MSL. TREES BEGINNING 2473 FT FROM DER, 725 FT LEFT OF
CENTERLINE, UP TO 68 FT AGL/1307 FT MSL. TREE 2733 FT FROM DER, 958
FT LEFT OF CENTERLINE, 66 FT AGL/1325 FT MSL. TREE 2780 FT FROM
DER, 1203 FT LEFT OF CENTERLINE, 1327 FT MSL. TREES BEGINNING 2808
FT FROM DER, 390 FT LEFT OF CENTERLINE, UP TO 1336 FT MSL. TREES
BEGINNING 3436 FT FROM DER, 207 FT LEFT OF CENTERLINE, UP TO 1344
FT MSL. TREE, POLE, TOWER, TRANSMISSION LINE BEGINNING 3729 FT FROM
DER, 243 FT LEFT OF CENTERLINE, UP TO 1355 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2401181843-2408291843EST
END PART 2 OF 2
|
