9/4/24 1238Z | 9/4/26 1238Z | | !FDC 4/9754 FYE PART 1 OF 3 ODP FAYETTE COUNTY, SOMERVILLE, TN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 1: TREE 198 FT FROM DER, 503 FT RIGHT
OF CENTERLINE, 446 FT MSL.
TREE 229 FT FROM DER, 498 FT RIGHT OF CENTERLINE, 488 FT MSL.
TREE 397 FT FROM DER, 585 FT LEFT OF CENTERLINE, 493 FT MSL.
TREE 593 FT FROM DER, 515 FT RIGHT OF CENTERLINE, 497 FT MSL.
TREE 619 FT FROM DER, 568 FT RIGHT OF CENTERLINE, 499 FT MSL.
TREE 733 FT FROM DER, 591 FT LEFT OF CENTERLINE, 502 FT MSL.
TREE 771 FT FROM DER, 646 FT RIGHT OF CENTERLINE, 500 FT MSL.
TREE 858 FT FROM DER, 607 FT LEFT OF CENTERLINE, 504 FT MSL.
TREE, POLE, TRANSMISSION LINE BEGINNING 890 FT FROM DER, 197 FT
LEFT OF CENTERLINE, UP TO 508 FT MSL.
TREE, POLE, TRANSMISSION LINE BEGINNING 899 FT FROM DER, 238 FT
RIGHT OF CENTERLINE, UP TO 504 FT MSL.
TREES BEGINNING 1689 FT FROM DER, 585 FT RIGHT OF CENTERLINE, UP TO
507 FT MSL.
TREES BEGINNING 2157 FT FROM DER, 31 FT LEFT OF CENTERLINE, UP TO
513 FT MSL.
TREES BEGINNING 2194 FT FROM DER, 22 FT RIGHT OF CENTERLINE, UP TO
512 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2409041238-2609041238EST
END PART 1 OF 3
!FDC 4/9754 FYE PART 2 OF 3 ODP FAYETTE COUNTY, SOMERVILLE, TN.
TREES BEGINNING 2920 FT FROM DER, 150 FT LEFT OF CENTERLINE, UP TO
519 FT MSL..
RWY 19: FENCE 85 FT FROM DER, 395 FT RIGHT OF CENTERLINE, 4 FT
AGL/439 FT MSL.
TREES BEGINNING 106 FT FROM DER, 492 FT RIGHT OF CENTERLINE, UP TO
507 FT MSL.
TREE 537 FT FROM DER, 252 FT LEFT OF CENTERLINE, 464 FT MSL.
TREES BEGINNING 576 FT FROM DER, 290 FT LEFT OF CENTERLINE, UP TO
466 FT MSL.
TREES BEGINNING 638 FT FROM DER, 25 FT RIGHT OF CENTERLINE, UP TO
509 FT MSL.
TREES BEGINNING 741 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO 507
FT MSL.
TREES BEGINNING 1493 FT FROM DER, 253 FT LEFT OF CENTERLINE, UP TO
511 FT MSL.
TREES BEGINNING 1796 FT FROM DER, 218 FT LEFT OF CENTERLINE, UP TO
516 FT MSL.
TREES BEGINNING 1833 FT FROM DER, 5 FT LEFT OF CENTERLINE, UP TO
522 FT MSL.
TREE 1900 FT FROM DER, 425 FT RIGHT OF CENTERLINE, 510 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2409041238-2609041238EST
END PART 2 OF 3
!FDC 4/9754 FYE PART 3 OF 3 ODP FAYETTE COUNTY, SOMERVILLE, TN.
TREES BEGINNING 1929 FT FROM DER, 198 FT RIGHT OF CENTERLINE, UP TO
518 FT MSL.
TREES BEGINNING 2135 FT FROM DER, 30 FT RIGHT OF CENTERLINE, UP TO
524 FT MSL.
TREES BEGINNING 2547 FT FROM DER, 1125 FT LEFT OF CENTERLINE, UP TO
528 FT MSL.
TREE 3783 FT FROM DER, 256 FT LEFT OF CENTERLINE, 531 FT MSL.
TREE 3807 FT FROM DER, 258 FT LEFT OF CENTERLINE, 539 FT MSL..
ALL OTHER DATA REMAINS AS PUBLISHED. 2409041238-2609041238EST
END PART 3 OF 3
|
