KGDW
GLADWIN ZETTEL MEML
PublicPUB

1 miles SE of GLADWIN, MI
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
43° 58' 14"N 84° 28' 30"W
774' MSL
1774' MSL
04W
JET A (FSII), 100LL
LANSING (LAN)
DETROIT
MINNEAPOLIS (ZMP)
10/3/24-10/31/24
KIKW (21nm) VFR
2:15 PM EDT
Clear
10sm
75°F
41°F
30.03"Hg
190° 9kts
AO2
KIKW 221815Z AUTO 19009KT 10SM CLR 24/05 A3003 RMK AO2
Add Your Business

KGDW FBOs

Promote Listing
Gladwin Zettel Memorial Airport
UNICOM: 122.8
Phone: (989) 426-4201
No Rating Available
0 Reviews (Read | Sign In To Write)
Phillips 66
As of 10/22
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 5.25
Full Serve 5.25 6.18
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KMBS (32nm)
Tue, 10/22 1:20 PM EDT
Tue, 10/22 2:00 PM EDT - Wed, 10/23 2:00 PM EDT
VFR
2:00 PM EDT - 6:00 PM EDT
Scattered 25,000'
6sm
200° 13kts
Gusts 20kts
VFR
6:00 PM EDT - 10:00 PM EDT
Broken 25,000'
6sm
180° 7kts
VFR
10:00 PM EDT - 10:00 AM EDT
Broken 7,000'
6sm
210° 11kts
Gusts 20kts
MVFR
10:00 AM EDT - 2:00 PM EDT
Overcast 3,000'
6sm
300° 12kts
Gusts 22kts
KMBS 221720Z 2218/2318 20013G20KT P6SM SCT250
   FM222200 18007KT P6SM BKN250
   FM230200 21011G20KT P6SM BKN070
   FM231400 30012G22KT P6SM OVC030
KGDW
Domestic
10/17/241700Z !LAN 10/256 GDW AIRSPACE UAS WI AN AREA DEFINED AS .25NM RADIUS OF GDW SFC-400FT AGL DLY 1700-2359 2410171700-2410202359
10/13/241700Z !LAN 10/112 GDW AIRSPACE UAS WI AN AREA DEFINED AS .25NM RADIUS OF GDW SFC-400FT AGL 2410131700-2410132359
10/12/241700Z !LAN 10/177 GDW AIRSPACE UAS WI AN AREA DEFINED AS .25NM RADIUS OF GDW SFC-400FT AGL 2410121700-2410122359
10/10/241700Z !LAN 10/148 GDW AIRSPACE UAS WI AN AREA DEFINED AS .25NM RADIUS OF GDW SFC-400FT AGL 2410101700-2410102359
10/8/241700Z !LAN 10/111 GDW AIRSPACE UAS WI AN AREA DEFINED AS .25NM RADIUS OF GDW SFC-400FT AGL 2410081700-2410082359
10/7/240923Z !LAN 10/097 GDW OBST TOWER LGT (ASR 1326492) 440115.20N0843509.30W (5.6NM WNW GDW) 1152FT (260FT AGL) U/S 2410070923-2411060001
10/3/241800Z !LAN 10/031 GDW AIRSPACE UAS WI AN AREA DEFINED AS .25NM RADIUS OF GDW SFC-400FT AGL DLY 1800-2359 2410031800-2410062359
No
0900-1700
UNATNDD MAJOR HOLS. FOR SVC AFT HRS CALL AMGR CELL.
CITY/CO OF GLADWIN
1000 W CEDAR AVE
GLADWIN, MI 48624-1814
Phone: 989-426-9231
MICHAEL HARGRAVE
735 S STATE ST
GLADWIN, MI 48624-2258
Phone: 989-426-4201
LANSING FSS (LAN)
Toll Free: 1-800-WX-BRIEF
LAN
--
ACTVT REIL RWY 09 & 27; PAPI RWY 09 & 27; MIRL RWY 09/27 - CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 09/27

4699 ft. x 75 ft.
ASPH
Good
NONE
MED

44,000lbs
60,000lbs
90,000lbs
--
  Runway 09 Runway 27
True Heading 88°268°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 43° 58' 18"N 43° 58' 20"N
Longitude 84° 28' 58"W 84° 27' 54"W
Elevation 771' 773'
Threshold Crossing Height 42 ft. AGL 42 ft. AGL
Visual Glide Path Angle 3.75° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 15/33

2580 ft. x 150 ft.
TURF
Fair
NONE


--
--
--
--
  Runway 15 Runway 33
True Heading 157°337°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 43° 58' 17"N 43° 57' 53"N
Longitude 84° 28' 44"W 84° 28' 30"W
Elevation 773' 764'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1DEER & LRG BIRDS ON & INVOF ARPT.
A110-2UAS OPR WEST OF RWY 15/33.
A110-3TRML BLDG ACES: 5-3-2-1-*.
A110-4FOR CD CTC GREAT LAKES APCH AT 269-459-3345, WHEN APCH CLSD CTC CLEVELAND ARTCC AT 440-774-0224/0490.
GLADWIN ZETTEL MEML (ICAO: KGDW, IATA: GDW) is a public airport located in GLADWIN, MI.
