1/22/24 1912Z | 1/22/26 1912Z | | !FDC 4/6586 GVL PART 1 OF 5 ODP LEE GILMER MEML, GAINESVILLE, GA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 5, TRAVERSE WAY 7 FT FROM DER, 489 FT
LEFT OF CENTERLINE, 1241 FT MSL.
BUILDINGS, VERTICAL POINT BEGINNING 38 FT FROM DER, 358 FT RIGHT OF
CENTERLINE, UP TO 33 FT AGL/1266 FT MSL.
POLES, TREE BEGINNING 303 FT FROM DER, 118 FT LEFT OF CENTERLINE,
UP TO 28 FT AGL/1256 FT MSL.
TREES, POLE BEGINNING 543 FT FROM DER, 290 FT LEFT OF CENTERLINE,
UP TO 1271 FT MSL.
TREES BEGINNING 560 FT FROM DER, 30 FT RIGHT OF CENTERLINE, UP TO
1325 FT MSL.
TREES BEGINNING 823 FT FROM DER, 14 FT LEFT OF CENTERLINE, UP TO
1275 FT MSL.
TREES BEGINNING 1000 FT FROM DER, 220 FT LEFT OF CENTERLINE, UP TO
1276 FT MSL.
TREES BEGINNING 1040 FT FROM DER, 44 FT LEFT OF CENTERLINE, UP TO
1281 FT MSL.
TREES BEGINNING 1166 FT FROM DER, 69 FT LEFT OF CENTERLINE, UP TO
1289 FT MSL.
TREES BEGINNING 2008 FT FROM DER, 98 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2401221912-2601221912EST
END PART 1 OF 5
!FDC 4/6586 GVL PART 2 OF 5 ODP LEE GILMER MEML, GAINESVILLE, GA.
1330 FT MSL.
SMOKESTACK, TRANSMISSION LINES BEGINNING 2302 FT FROM DER, 616 FT
LEFT OF CENTERLINE, UP TO 156 FT AGL/1349 FT MSL.
TREES BEGINNING 2830 FT FROM DER, 610 FT RIGHT OF CENTERLINE, UP TO
1340 FT MSL.
TREES BEGINNING 3063 FT FROM DER, 210 FT RIGHT OF CENTERLINE, UP TO
1341 FT MSL.
TREE 3935 FT FROM DER, 873 FT RIGHT OF CENTERLINE, 1350 FT MSL.
TREES, TRANSMISSION LINE BEGINNING 3960 FT FROM DER, 1077 FT RIGHT
OF CENTERLINE, UP TO 1361 FT MSL.
TRANSMISSION LINES, TREES BEGINNING 4107 FT FROM DER, 453 FT RIGHT
OF CENTERLINE, UP TO 89 FT AGL/1371 FT MSL.
BUILDING 4422 FT FROM DER, 371 FT LEFT OF CENTERLINE, 154 FT
AGL/1355 FT MSL.
ELEVATORS, BUILDING BEGINNING 4445 FT FROM DER, 283 FT LEFT OF
CENTERLINE, UP TO 162 FT AGL/1361 FT MSL.
RWY 11, FENCE 36 FT FROM DER, 301 FT RIGHT OF CENTERLINE, 1269 FT
MSL.
TREE, POLE BEGINNING 73 FT FROM DER, 387 FT RIGHT OF CENTERLINE, UP
TO 1296 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2401221912-2601221912EST
END PART 2 OF 5
!FDC 4/6586 GVL PART 3 OF 5 ODP LEE GILMER MEML, GAINESVILLE, GA.
TREES, POLES, BUILDING, TRANSMISSION LINE BEGINNING 199 FT FROM
DER, 30 FT RIGHT OF CENTERLINE, UP TO 1348 FT MSL.
TREE 240 FT FROM DER, 505 FT LEFT OF CENTERLINE, 1300 FT MSL.
TREES, POLE BEGINNING 298 FT FROM DER, 59 FT LEFT OF CENTERLINE, UP
TO 1308 FT MSL.
TREES BEGINNING 864 FT FROM DER, 34 FT LEFT OF CENTERLINE, UP TO
1326 FT MSL.
TREES, POLES, SIGN BEGINNING 1216 FT FROM DER, 3 FT LEFT OF
CENTERLINE, UP TO 1344 FT MSL.
TREES, POLES BEGINNING 1853 FT FROM DER, 35 FT RIGHT OF CENTERLINE,
UP TO 1350 FT MSL.
TREES BEGINNING 1929 FT FROM DER, 6 FT LEFT OF CENTERLINE, UP TO
1359 FT MSL.
RWY 23, TREE 91 FT FROM DER, 409 FT LEFT OF CENTERLINE, 1277 FT
MSL.
TREES BEGINNING 233 FT FROM DER, 493 FT RIGHT OF CENTERLINE, UP TO
1301 FT MSL.
TREE 374 FT FROM DER, 593 FT RIGHT OF CENTERLINE, 1307 FT MSL.
TREES BEGINNING 2995 FT FROM DER, 1169 FT LEFT OF CENTERLINE, UP TO
1377 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2401221912-2601221912EST
END PART 3 OF 5
!FDC 4/6586 GVL PART 4 OF 5 ODP LEE GILMER MEML, GAINESVILLE, GA.
TREE 2997 FT FROM DER, 1074 FT RIGHT OF CENTERLINE, 1358 FT MSL.
TREES BEGINNING 3279 FT FROM DER, 822 FT LEFT OF CENTERLINE, UP TO
1381 FT MSL.
TREE 3992 FT FROM DER, 894 FT LEFT OF CENTERLINE, 1383 FT MSL.
RWY 29, BUILDING 97 FT FROM DER, 375 FT LEFT OF CENTERLINE, 17 FT
AGL/1289 FT MSL.
TREES BEGINNING 127 FT FROM DER, 68 FT RIGHT OF CENTERLINE, UP TO
1294 FT MSL.
POLES, TREES BEGINNING 287 FT FROM DER, 40 FT LEFT OF CENTERLINE,
UP TO 47 FT AGL/1313 FT MSL.
TREES BEGINNING 642 FT FROM DER, 54 FT RIGHT OF CENTERLINE, UP TO
1301 FT MSL.
TREE 993 FT FROM DER, 95 FT RIGHT OF CENTERLINE, 1307 FT MSL.
TREE 1059 FT FROM DER, 14 FT RIGHT OF CENTERLINE, 1310 FT MSL.
TREES BEGINNING 1193 FT FROM DER, 87 FT RIGHT OF CENTERLINE, UP TO
1331 FT MSL.
TREE 1334 FT FROM DER, 69 FT LEFT OF CENTERLINE, 1315 FT MSL.
TREES BEGINNING 1358 FT FROM DER, 254 FT RIGHT OF CENTERLINE, UP TO
1352 FT MSL.
TREES BEGINNING 1431 FT FROM DER, 36 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2401221912-2601221912EST
END PART 4 OF 5
!FDC 4/6586 GVL PART 5 OF 5 ODP LEE GILMER MEML, GAINESVILLE, GA.
1354 FT MSL.
TREES BEGINNING 1461 FT FROM DER, 46 FT LEFT OF CENTERLINE, UP TO
1331 FT MSL.
TREES BEGINNING 1514 FT FROM DER, 26 FT RIGHT OF CENTERLINE, UP TO
1355 FT MSL.
TREES BEGINNING 1739 FT FROM DER, 82 FT LEFT OF CENTERLINE, UP TO
1335 FT MSL.
TREE 1895 FT FROM DER, 215 FT LEFT OF CENTERLINE, 1342 FT MSL.
TREES BEGINNING 1964 FT FROM DER, 95 FT LEFT OF CENTERLINE, UP TO
1349 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2401221912-2601221912EST
END PART 5 OF 5
|
